ASSEMBLY INSTRUCTIONS
Quadro Square
Quadro Square
Counter Frame
Counter table
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Sizes:
1000x1000
1200x700
1200x1200
1400x700
1600x700
1800x700
2000x700
2400x1200
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
www.jasonl.com.au
Call us on
1300 527 665
Page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jason.L Quadro Square
Summary of Contents for Jason.L Quadro Square
- Page 1 ASSEMBLY INSTRUCTIONS Quadro Square Quadro Square Need help! Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm Sizes: 1000x1000 1200x700 1200x1200 1400x700 1600x700 1800x700 2000x700 2400x1200 Tools Required: Power screwdriver; Allen key set (provided)
- Page 2 Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm COMPONENTS Table top x1 Legs Quadro Square x2 Beam x1 Plastic bracket x4 Feet x4 SCREWS M8x20MM CSK x2 M8x20MM Socket head x2 M6x20MM Socket head x4...
- Page 3 ASSEMBLY INSTRUCTIONS Quadro Square Quadro Square Need help! Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 01 STEP 02 TOP VIEW Using Allen Key provided, attach 2 plastic brackets per leg (D) Using Allen Key provided, attach M8x20MM Socket head (G)- (as per picture above) using M6x20MM (H) Socket head screw.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro Square Quadro Square Need help! Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro Square Quadro Square Need help! Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 04 TOP VIEW STEP 05 Attach beam (C) to legs (B) using nut insert in legs.
- Page 6 ASSEMBLY INSTRUCTIONS Quadro Square Quadro Square Need help! Counter table Counter Frame Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 06 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame. Nut inserts in top will align with plastic Place desktop on top of frame.
