APsystems Microinverter User Manual
ALTENERGY POWER SYSTEM Inc.
emea.APsystems.com
APsystems
Karspeldreef 8, 1101 CJ Amsterdam, The Netherlands
EMAIL: info.emea@APsystems.com
APsystems
22 Avenue Lionel Terray, 69330 Jonage, France
EMAIL:info.emea@APsystems.com
© All Rights Reserved
APsystems EZ1D Microinverters
(For EMEA)
Please scan this QR code to have
access to our APPs and Products
Information.
2024/04/09 Rev1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for APsystems EZ1D Series
Summary of Contents for APsystems EZ1D Series
- Page 1 APsystems Microinverter User Manual APsystems EZ1D Microinverters (For EMEA) ALTENERGY POWER SYSTEM Inc. emea.APsystems.com APsystems Karspeldreef 8, 1101 CJ Amsterdam, The Netherlands EMAIL: info.emea@APsystems.com Please scan this QR code to have access to our APPs and Products APsystems Information. 22 Avenue Lionel Terray, 69330 Jonage, France EMAIL:info.emea@APsystems.com...
-
Page 2: Table Of Contents
1.2 Radio Interference Statement ........................ 3 1.3 Symbols in Lieu of Words ........................4 2. APsystems Microinverter System Introduction ............5 3. APsystems Microinverter EZ1D Introduction ............7 4. APsystems Microinverter System Installation ............8 4.1 Installation Procedures ..........................8 5.Install and Use AP EasyPower ..................10 5.1 Install APP ..............................10... -
Page 3: Important Safety Instructions
Do NOT disconnect the PV module from the APsystems Microinverter without first disconnecting the AC power. Be aware that the body of the APsystems Microinverter is the heat sink and can reach a temperature of 80°C. To reduce risk of burns, do not touch the body of the Microinverter. -
Page 4: Radio Interference Statement
1. Important Safety Instructions 1.2 Radio Interference Statement EMC Compliance：The APsystems Microinverter can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communication. APsystems Microinverter complies with EMC regulations, which are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Symbols In Lieu Of Words
EMC and is authorized to energize, ground, and tag equipment, systems, and circuits in accordance with established safety procedures. The inverter and photovoltaic system may only be commissioned and operated by qualified personnel. APsystems Microinverter EZ1D User manual... -
Page 6: Apsystems Microinverter System Introduction
Besides direct connection, EZ1D could also connect to a router through Wi-Fi and send data to cloud servers for remote monitoring. 1. Please follow the local regulations and laws regarding the method and capacity of grid connection. APsystems does not assume any legal responsibility arising from this. - Page 7 When using an APsystems microinverter, PV modules are connected in parallel. Voltage at the back of each PV module never exceeds PV modules Voc, which is lower than 118Vdc for most of PV modules used with APsystems microinverters. This low voltage negates the risk of electrical shock, electrical arcs and fire hazards.
-
Page 8: Apsystems Microinverter Ez1D Introduction
3. APsystems Microinverter EZ1D Introduction Key Product Feature: One microinverter connects to four modules Max output power reaching 2000VA for different models High Input current to adapter to large modules Maximum reliability, IP67 Built in Wi-Fi and Bluetooth ... -
Page 9: Apsystems Microinverter System Installation
Customer using fixing bolts or cable ties, please prepare them by yourself. 4.1.3 Step 3 - Connect APsystems Microinverters to the PV Modules When plugging in the DC cables, the microinverter should immediately blink green ten times. This will happen as soon as the DC cables are plugged in and will show that the microinverter is functioning correctly. - Page 10 Make sure to not split positive and negative DC cables into two different input channels: microinverter will become damaged and warranty will not apply. 2.Please ensure each DC cable's length within 3 meters. 4.1.4 Step 4 - Connect the APsystems Microinverter The Betteri connector above are not included in the package and should be purchased separately.
-
Page 11: Install And Use Ap Easypower
Android: 7.0 and up. 5.2 Connect the APsystems Microinverters AP EasyPower offers two modes “Direct Connect Mode”and “Remote Mode” to monitor the device. Direct Connect Mode: APP connects to Bluetooth of the device, so that users can realize local monitoring and control of the device. -
Page 12: Monitor & Control
By pressing “ alarm icon ” to check the alarm information if the device status is alarm. By pressing “ setting icon ” to set the device. The setting page is shown below. For Connection and monitoring operation mode, please refer to the AP EasyPower User Manual. APsystems Microinverter EZ1D User manual... -
Page 13: Troubleshooting
APsystems Technical Support. 6.2 Trouble Shooting Guide Professional Users can also refer to our Troubleshooting Guide (https://emea.apsystems.com/resources/library/, section libraries)for more in depth guidelines on how to troubleshoot and fix PV installations powered by APsystems microinverters. 6.3 APsystems Technical Support The APsystems local Technical Support team is available to support professional installers in becoming familiar with our products and to troubleshoot installations when needed. -
Page 14: Replace A Microinverter
7. Replace a Microinverter Follow the procedure to replace a failed APsystems Microinverter A. Disconnect the APsystems Microinverter from the PV Module, in the order shown below: 1. Disconnect the inverter from grid 2. Disconnect the PV module DC wire connectors from the microinverter. -
Page 15: Technical Data
Z1.html?area=EMEA&flag=English ②. DC operating voltage range of the PV module must be within allowable input voltage range of the APsystems Microinverter. ③. The maximum open circuit voltage of the PV module must not exceed the specified maximum input voltage of the APsystems. -
Page 16: Ez1D Microinverter Datasheet
Specifications subject to change without notice please ensure you are **The EasyPower App only supports monitoring of 1 unit of product from the EZ1D using the most recent update found at web : emea.APsystems.com series. APsystems Microinverter EZ1D User manual... -
Page 17: Ez1D Pv Capacity Expansion Introduction
Sometimes it can be less than half of the rated output power. Many customers would like to increase the system power by connecting more PV modules. APsystems DIY microinverters EZ1D, with large input current of 20A, offer a safe and reliable solution.
