McFarlane INCITE Universal Tillage 5000 Series Operation And Parts Manual

Universal tillage
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INCITE Universal Tillage 5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McFarlane INCITE Universal Tillage 5000 Series

Summary of Contents for McFarlane INCITE Universal Tillage 5000 Series

  • Page 3: Table Of Contents

    Tow Chain ..... 19 Connecting to the Tractor ... . . 19 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 4 REPORT ........85 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 5: Introduction

    Introduction The “Incite 5000 Series Universal Tillage™ tool” from McFarlane Mfg. is our latest development in vertical tillage. With its unique ability to run in diff erent fi eld types, spring or fall, the Incite™ has one-of-a-kind adjustability not found anywhere else on the market. This new tool has the fl...

  • Page 6: Safety

    CAUTION McFarlane cannot anticipate every possible circumstance that might involve a potential hazard. The warnings Indicates a potentially hazardous situation which, if in this manual and on the product are, therefore, not not avoided, may result in minor or moderate injury.

  • Page 7: Safety Icons Nomenclature

    Damaged hazard label Entanglement hazard Set parking brake Explosive separation hazard Slow vehicle placard Falling hazard Stop engine STOP High-pressure fluid hazard Support stand usage Hose damage Use proper tools Maintain safe distance Visually inspect 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 8: General Operating Safety

    5. Relieve hydraulic fl uid pressure. Maintenance Safety 6. If parking the unit, make sure jack stand is lowered and retaining pin is installed. For maintenance safety information, refer to “Maintenance” on page 32. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 9: Component Nomenclature

    Adjusting the angle and depth of the disk gangs is #3 (9°). the fi rst step in sizing and incorporating the residue. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 10: Walking Dual Wing Wheels (If Equipped)

    The spiral reels have a hydraulic height adjustment. They can be run from even with the bottom of the disk blades up to completely out of the ground. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 11: Trailing Disk Gangs (3)

    fl exible enough to allow residue to fl ow through it. It also breaks up large pieces of soil and disperses the residue evenly across the tillage area. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 12: Specifications

    IC-5024 — 19,700 IC-5027 — 20,920 IC-5032 — 25,220 IC-5040 — 30,730 Transport Width IC-5012 — 13’9” IC-5014 — 14’10” IC-5020 — 13’8” IC-5024 — 13’8” IC-5027 — 15’7” IC-5032 — 15’7” IC-5040 — 17’10” Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 13: Safety Signs And Decals

    Replace safety signs that are missing or have become illegible. • Do not paint over, remove, or deface any safety signs or instructional decals on your equipment. Observe all safety signs and follow the instructions on them. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 14 PINS MUST BE USED DURING TRANSPORT. DO NOT RUN THE DISK GANGS TO A DEPTH GREATER THAN 6 (SIX) INCHES. DC-225 MAXIMUM FIELD TRAVEL SPEED IS 9 MPH. DC-231 DC-297 (LH) — DC-298 (RH) Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 15: Assembly

    Do not allow anyone to stand between the tongue or hitch and the towing vehicle when backing up to the unit. Make sure that the area is clear of children, animals, and other obstacles before moving the unit. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 16: Safety Chain

    NO MORE THAN 20 maximum visibility at all times. Make allowances for mph. Do not exceed the maximum speed or increased length and weight of the equipment when tire failure may occur. making turns, stopping, etc. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 17: Pre-Towing Checklist

    7. Prior to towing, have an observer confi rm all running lights, brake lights, turn signals, and hazard lights are working on both the tow vehicle and the unit. 8. Verify the brakes on the tow vehicle are operating correctly. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 18: Hook-Up To Tractor

    11. Make sure the wing lock pins are in place. Refer to Step “4. Install the wing fold lock pins and bridge pins.” on page 31. Transport lock secured over cylinder rod. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 19: Tow Chain

    1-1/2” (38 mm) pin. On Category doctor familiar with this type of injury. 3 clevis hitches use a 1-1/4” (32 mm) pin. On Category 4 pintle hitches use a 2” (51 mm) pin. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 20 2. Connect the hitch of the unit to the tractor. Attach the safety chain to the tractor’s draw bar cage. Note: When connected, make sure the retaining plate securely locks the chain link in place. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 21 Note: The most commonly used function of the unit is the “main lift” cylinders, which raises and lowers the wheels. Connect the hydraulic hoses for this function into the port (control lever) used most commonly. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 22: Operation

    9. Move the unit to the desired location and position it for operation following the towing recommendation provided in this manual and/or any other local, State, or Federal regulations that may apply. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 23: Initial Setup

    2. Place the transport locks on their storage brackets and fasten the retaining pins. The McFarlane Incite™ Universal Tillage™ tool is designed to handle a wide variety of fi eld conditions. It has many adjustments that can be made to optimize the effi...
  • Page 24 6. Lower disk gang close to the ground but not touching. 7. Stop the tractor, and set the parking brake. Block the wheels of the unit to prevent unwanted movement while repositioning the disk gangs. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 25 To prevent ridging, it may be necessary to reduce the travel speed with more aggressive disk angles. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 26 – Reel height should be all the way up (out of the ground) to set initial disk gang depth. Once disk gang depth is set, lower the reel so it is running at a depth of approximately 2”. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 27 22. Continue pulling the unit through the fi eld and raise and lower the wheels to allow the hydraulic control valve to stop the unit at the set depth. Stop the tractor and check the depth of the disks and the reel 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 28 Remove the locking bar retainer clip. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 29 fi ve links hanging (front bar higher than b. Remove the lynch pin and raise the turnbuckle lock rear bar). (release the turnbuckle to rotate). Note: Make sure the chains are not twisted when inserting into the slot. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 30: Preparing For Transport

    Failure to do so will result in uneven seedbed conditions and could damage the rolling basket arms and/or bearings. The unit should now be ready. Preparing for Transport 1. Lower the wheels and lift the unit off of the ground. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 31 The weight of the unit will easily cause serious bodily injury. Crush Hazard When folding the wings, make sure both wings are resting on the pads before releasing hydraulic pressure. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 32: Maintenance

    fl uid penetrates the surface of the skin. Entanglement Hazard Keep hands, feet, clothing, jewelry, and long hair away from any moving parts to prevent them from getting caught. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 33: Tire Safety

    The manufacturer will not accept responsibility for damages as a result of the use of unapproved parts. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 34: Tire And Lug Torque Specifi Cations

    3/8" (20) (33) (45) 7/16" (30) (53) (75) 1/2" (45) (80) (115) 9/16" (70) (115) (165) 5/8" (95) (160) (220) 3/4" (165) (290) (400) 7/8" (170) (420) (650) 1" (225) (630) 1320 (970) Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 35: Maintenance Schedule

    Cotter pin. Wire retainer pin. b. Check the gang arbor nut torque which is described in ”Disk Gang Disk Blades” on page 39. Wheel retainer bolts. Hinge pin and hitch pin retainer bolts. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.
  • Page 36 3. Grease all hinge pins every 15 hours of service. Refer to “Lubrication Points” on page 38. 6. Spiral reel bearings should be lubricated annually. 4. Grease the tandem pivot every 15 hours of service. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 37 8. Inspect the rubber bumper pads on the wing support arms. Replace the pads if they are worn or missing. 9. Refer to the parts illustrations and listings for service and repair parts. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 38: Lubrication Points

    Lubrication Points Add grease to the locations shown in the illustration. When greasing a pin and bushing, add grease until it is visibly forced out of the joint. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 39: Maintenance Procedures

    Use a bar or lifting device to raise the hub upwards. d. The reading should not exceed 0.002” (0.05mm). Repair or replace hubs with excessive end play. 1. Support the reel assembly. 2. Remove one reel blade (1). 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 40: Spiral Reel Blades

    3. Remove bearing retainer caps (1) (center bearings) and end caps (2) (outer bearings). 4. Insert four new bearing wear sleeves. Do not replace just one sleeve. 5. Reinstall the retainers and caps. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 41: Storage

    FULL ONE YEAR WARRANTY If within one year from the date of purchase, this unit fails due to a defect in material or workmanship, McFarlane Mfg. Co., Inc. will repair it, free of charge. Warranty service is available at dealer locations by simply contacting the nearest McFarlane dealership throughout the United States or Canada.

  • Page 42: Troubleshooting

    Level the wing frames using the wing Outside disk gang gouges. Wing frames are not level. lift cylinders to raise the outside of the disk gang. Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 43: Parts Section

    For replacement decals, questions, or to order parts, contact your dealer: To ensure the greatest level of safety, all decals must be in place and legible at all times. Remember, it is the users’ responsibility to maintain these decals. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 44: Parts Drawings

    NUT, HEX, 1/4-20 PB-0009 PIN, BRIDGE, #9 PH-8860 PIN, HITCH, 7/8 X 6 w/ #6 BRIDGE PIN 10273 WRENCH, TURNBUCKLE RT-2416 WRENCH, TURNBUCKLE, 1-1/4" LB-1110 BRACKET, LIGHT PLUG BH-2510 BOLT, HEX, 1/4-20 X 1 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 45: Hitch For Ic-5012, And Ic-5014 (Cat. Iii)

    NUT, TOP LOCK, 3/4 (CAT. III only) RD-4612 WING FRAME WING LOCK (ALL SIZES) BU-5867 U-BOLT, 5/8 X 6 X 7-1/2 LW-0063 WASHER, LOCK, 5/8 NH-6311 NUT, HEX, 5/8-11 NLT-6311 NUT, TOP LOCK, 5/8-11 (5024) 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 46: Level Lift For Incite™ 5000 Series

    BRACKET, DEPTH INDICATOR 10260 PLATE, PIVOT 11374 POINTER, DEPTH INDICATOR RD-4914 HANDLE, THREADED BH-3810 BOLT, HEX, 3/8-16 x 1 RD-5060 COLLAR, SPRING NLT-3816 NUT, TOP LOCK, 3/8-16 RD-4355 SPRING, COMPRESSION, 1 X 3.5 X 0.162 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 47: Wing Rest For Ic-5020, Ic-5024, Ic-5027, Ic-5032, And Ic-5040

    NUT, TOP LOCK, 1/2-13 11302 BRACKET, WING REST (5020) 11305 BRACKET, WING REST (5024) 10767 BRACKET, WING REST (5027) 10336 BRACKET, WING REST (5032) 10266 BRACKET, WING REST (5040) RT-3415 BUMPER, WING REST 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 48: Main Frame And Axle For Ic-5012, Ic-5014, Ic-5027, Ic-5032, And Ic-5040

    RD-4580 HUB ASSEMBLY, 8 BOLT, 7500 LB (5027, 5032, LP-3825 PIN, LYNCH, 3/8” x 2-1/2” 5040) BH-5040 BOLT, HEX, 1/2-13 X 4 (5012, 5014) BH-5050 BOLT, HEX, 1/2-13 X 5 (5027, 5032, 5040) Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 49: Main Frame And Axle For Ic-5020 And Ic-5024

    BOLT, HEX, 3/8-16 X 1.25 HYS-1212 LOCK, CYLINDER, 12” NLT-3816 NUT, TOP LOCK, 3/8-16 LP-3825 PIN, LYNCH, 3/8” x 2-1/2” WN-0063 WHEEL NUTS 5/8 RT-3185 HUB ASSEMBLY, 8 BOLT, 6000 LB BH-5050 BOLT, HEX, 1/2-13 X 5 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 50: Wing Frame For Ic-5020, Ic-5024, Ic-5027, And Ic-5032

    PIN, SPRING ROLL, 1/2 X 3-1/2 10696 PIVOT POST, ADJUSTABLE BHY-5035 BOLT, HEX, 1/2-13 X 3-1/2 GRADE 8 RD-5061 PIN, STRAIGHT NLT-5013 NUT, TOP LOCK, 1/2-13 10177 AXLE LINK ASSEMBLY, DUAL (all models) WDL-2505 SPINDLE, 1-3/4 X 9-1/2 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 51: Wing Frame, Inside, For Ic-5040

    WING FRAME ASSEMBLY, RIGHT INSIDE FW-0100 1” PLAIN FLAT WASHER BHY-5035 BOLT, HEX, 1/2-13 X 3-1/2 GRADE 8 10177 AXLE, LINK, DUAL NLT-5013 NUT, TOP LOCK, 1/2-13 RD-5062 PIN, SPRING ROLL, 1/2 X 2.50 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 52: Wing Frame, Outside, For Ic-5040

    NUT, JAM, HEAVY HEX, 2-5 RD-5062 ROLL PIN, 1/2 X 2-1/2 10696 PIVOT POST, ADJUSTABLE RD-5061 PIN, STRAIGHT BHY-5035 BOLT, HEX, 1/2-13 X 3-1/2 GRADE 8 WDL-2505 SPINDLE NLT-5013 NUT, TOP LOCK, 1/2-13 HD-1371 6-HOLE HUB ASSEMBLY Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 53: Hub Components For Wdl-2507

    WHEEL BOLTS, 9/16-18 X 1-11/16 RT-2174 HUB WITH RACES, 8 HOLE HUB RT-2178 DUST CAP GZ-0601 GREASE ZERK — RT-2171 8-HOLE HUB ASSEMBLY (includes items 2, 3, 5, 6, 8, 12, and 13). HD-1171 OUTER RACE 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 54: Hub Components For Rt-3185

    GZ-0601 GREASE ZERK RT-3192 OUTER RACE RT-3186 OUTER BEARING RT-3190 SPINDLE FLAT WASHER RT-3187 SPINDLE HEX CASTLE NUT CP-7320 COTTER PIN (0.207 X 2) RT-3188 DUST CAP — RT-3181 8-BOLT HUB ASSEMBLY, 6000LB Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 55: Hub Components For Rd-4417

    COTTER PIN (0.207 X 2) WN-0063 WHEEL NUTS, 5/8 RT-3187 SPINDLE HEX CASTLE NUT, 1-14 RT-3188 DUST CAP — RD-4580 8-BOLT HUB ASSEMBLY, 7500 LB (includes items 2, 3, 4, 6, 7, 9, 12, and 14). 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 56: Disk Gang For Incite™ 5000 Series

    BLADE, DISK, 28 WAVE, 18” (OUTSIDE OF 10727 TUBE, ROUND UNIT ONLY) 10728 TUBE, ROUND * On outside of unit only. All other disk gangs have all 10597 BLADE, DISK, 28 WAVE, 22” 10597 blades. 10319 SPOOL, DISK, STRAIGHT Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 57: Center Wavy Disk For Incite™ 5000 Series

    (includes items 7 and 12) DISK ASSEMBLY, CENTER RD-5093 (includes items 13, 8, 9, 10, and 11) HD-1160 GREASE SEAL HD-1162 BEARING, INNER Items 14 - 24 are part of HD-1170 Hub Assembly, Item 12. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 58: Disk Mount And Scrapers For Incite™ 5000 Series

    Disk Mount and Scrapers for Incite™ 5000 Series MFM-00189a Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 59 SCRAPER TUBE, MAIN (5014, 5027, 5032, 5040); WING (5024) 10477 SCRAPER TUBE, WING (5032) 10547 SCRAPER TUBE, MAIN (5020, 5024); WING (5020) RD-4968 SCRAPER TUBE, MAIN (5012); WING (5027, 5040) RD-4974 SCRAPER TUBE, WING (5032) 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 60: Spiral Reel For Incite™ 5000 Series

    Spiral Reel for Incite™ 5000 Series 32 33 34 19 18 MFM-00187 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 61 NLT-2520 NUT, LOCK, TOP, 1/4-20 RD-4855 HUB ASSEMBLY, REEL, 5 BOLT RD-5001 BRACKET,SPIRAL BLADE,HUB 10965 DECAL, REEL DEPTH NL-5020 NUT, 1/2-20 1 Refer to layout diagram for position and size on each unit. 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 62: Lift Arm For Incite™ 5000 Series

    RD-5074 BRACE ANGLE, 68 – 3/8” NH-5013 NUT, HEX, 1/2-13 BC-6340 BOLT, CARRIAGE, 5/8 X 4 NLT-6311 NUT, TOP LOCK, 5/8-11 FA-4105 PULL POINT ASSEMBLY BH-5018 BOLT, HEX, 1/2-13 X 1-3/4 GRADE 5 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 63: Fa Harrow Section For Incite™ 5000 Series

    NUT, TOP LOCK, 3/8-16 FA-857 NUMBER THREE HARROW BAR (FA-800-3) FA-957 NUMBER THREE HARROW BAR (FA-900-3) FA-4110 TOOTH, 3/4” X 10” BH-5018 BOLT, HEX, 1/2-13 X 1-3/4 GRADE 5 HDD-016 WASHER, SQUARE, 1/2” 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 64: Rolling Basket For Incite™ 5000 Series

    BASKET MOUNT TUBE – 63” RD-5078 BASKET MOUNT TUBE – 74” RD-5077 BASKET MOUNT TUBE – 85” BC-7540 BOLT, CARRIAGE, 3/4-10 X 4, GRADE 5 BH-5018 BOLT, HEX, 1/2-13 X 1-3/4 GRADE 5 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 65: Lighting Diagram For Incite™ 5000 Series

    NUT, TOP LOCK, 3/8-16 RD-5058 BRACKET, LIGHT, SINGLE, RT BH-2513 BOLT, 1/4-20 x 1-1/4” LB-1106 LIGHT, AMBER BU-1278 U-BOLT, 1/2-13 x 7” x 8-1/4” LB-1203 BRACKET, SMV MOUNT NLT-5013 NUT, TOP LOCK, 1/2-13 MM-1300 SIGN, SMV 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 66: Axle Hydraulics For Ic-5012 And Ic-5014

    HYD ELBOW, 9/16 M - 3/4 MORB 10796 BODY, HYD CLAMP HYH-8076 HOSE, HYDRAULIC HYO-1206 PLATE, HYD CLAMP HYH-8036 HOSE, HYDRAULIC RD-4915 PLATE, OFFSET BH-3815 BOLT, HEX, 3/8-16 x 1-1/2” LW-0038 WASHER, LOCK, 3/8” Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 67: Axle Hydraulics For Ic-5020, Ic-5024, Ic-5027, And Ic-5032

    BOLT, HEX, 5/16-18 X 1-3/8 and 5032) 10324 HYD CYLINDER, REPHASING, 3.75 X 10 (5020 HYO-1004 COVER, HYD CLAMP and 5024) 10796 BODY, HYD CLAMP HYO-2103 CYLINDER CLEVIS PIN, 1 X 3-1/2 HYO-1206 PLATE, HYD CLAMP 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 68: Axle Hydraulics For Ic-5040

    COVER, HYD CLAMP HYF-3220 HYD ADAPTER, 3/4 F - 3/4 ORB 10796 BODY, HYD CLAMP HYF-2220 HYD ELBOW, 3/4 F - 3/4 ORB HYO-1206 PLATE, HYD CLAMP HYH-2086 HOSE, HYDRAULIC 10847 HOSE, HYDRAULIC Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 69: Wing Fold Hydraulics For Ic-5020

    HYD ELBOW, 9/16 M - 3/4 MORB 10979 HOSE, HYDRAULIC HYF-1888 HYD TEE, 9/16 M - 9/16 M - 9/16 M 10978 HOSE, HYDRAULIC 10980 HOSE, HYDRAULIC CP-3620 PIN, COTTER, 3/16 x 2.00 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 70: Wing Fold Hydraulics For Ic-5024, Ic-5027, And Ic-5032

    HOSE, HYDRAULIC (5024) CP-3620 PIN, COTTER, 3/16 x 2.00 HYH-8096 HOSE, HYDRAULIC (5027 and 5032) 10979 HOSE, HYDRAULIC (5024) CL-1307 PIN, CLEVIS, 1-1/4 x 7.0 10874 HOSE, HYDRAULIC (5027 and 5032) FW-0125 WASHER, FLAT, 1-1/4 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 71: Wing Fold Hydraulics For Ic-5040

    HYD COVER, HOSE, 60” 10857 HOSE, HYDRAULIC HYS-2005 HYD COVER, HOSE, 42” 10707 BOLT, HEX, 1-1/4-7 X 7.5,GRADE 8, SPECIAL HYF-3220 HYD ADAPTER, 3/4 M - 3/4 MORB NY-1307 NUT, LOCK, NYLON, 1-1/4-7 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 72: Spiral Reel Lift Hydraulics For Ic-5012 And Ic-5014

    PIN, CYLINDER CLEVIS, 1 X 3-1/2 10809 HOSE, HYDRAULIC HYF-3820 HYD ADAPTER, 9/16 M - 3/4 MORB HYF-2820 HYD ELBOW, 3/8 M - 1/2 MORB 10810 HOSE, HYDRAULIC 135995 PIN, COTTER 10327 HYD CYLINDER, REPHASING, 3 X 4 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 73: Spiral Reel Lift Hydraulics For Ic-5020, Ic-5024, Ic-5027, And Ic-5032

    PIN, CYLINDER CLEVIS, 1 X 3-1/2 10986 HOSE, HYDRAULIC (5020 and 5024) 10803 HOSE, HYDRAULIC (5020) 10806 HOSE, HYDRAULIC (5027 and 5032) 10868 HOSE, HYDRAULIC (5024) 135995 PIN, COTTER 10902 HOSE, HYDRAULIC (5027) 10869 HOSE, HYDRAULIC (5032) 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 74: Spiral Reel Lift Hydraulics For Ic-5040

    HOSE, HYDRAULIC 10865 HOSE, HYDRAULIC HYF-1888 HYD TEE, 9/16 M - 9/16 M - 9/16 M 10864 HOSE, HYDRAULIC HYF-2820 HYD ELBOW, 9/16 M - 3/4 MORB 10806 HOSE, HYDRAULIC 135995 PIN, COTTER Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 75: Disk Gang Angle Hydraulics For Ic-5012 And Ic-5014

    HYD ADAPTER, 9/16 M - 3/4 MORB HYO-1004 COVER, HYD CLAMP 10804 HOSE, HYDRAULIC 10796 BODY, HYD CLAMP 10801 HOSE, HYDRAULIC HYO-1206 PLATE, HYD CLAMP 10800 HOSE, HYDRAULIC HYF-1888 HYD TEE, 9/1 6M - 9/16 M - 9/16 M 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 76: Disk Gang Angle Hydraulics For Ic-5020, Ic-5024, Ic-5027, And Ic-5032

    HYD TEE, 9/16 M - 9/16 M - 3/4 MORB HYO-1004 COVER, HYD CLAMP 10989 HOSE, HYDRAULIC (5020) 10796 BODY, HYD CLAMP 10868 HOSE, HYDRAULIC (5024) 10901 HOSE, HYDRAULIC (5027) HYO-1206 PLATE, HYD CLAMP 10861 HOSE, HYDRAULIC (5032) Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 77: Disk Gang Angle Hydraulics For Ic-5040

    BH-3120 BOLT, HEX, 5/16-18 X 2” 10804 HOSE, HYDRAULIC HYO-1004 COVER, HYD CLAMP 10800 HOSE, HYDRAULIC 10796 BODY, HYD CLAMP 11134 HOSE, HYDRAULIC HYO-1206 PLATE, HYD CLAMP 10862 HOSE, HYDRAULIC 10801 HOSE, HYDRAULIC 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 78: Layout Diagram For Ic-5012

    Layout Diagram for IC-5012 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 79: Layout Diagram For Ic-5014

    Layout Diagram for IC-5014 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 80: Layout Diagram For Ic-5020

    Layout Diagram for IC-5020 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 81: Layout Diagram For Ic-5024

    Layout Diagram for IC-5024 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 82: Layout Diagram For Ic-5027

    Layout Diagram for IC-5027 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 83: Layout Diagram For Ic-5032

    Layout Diagram for IC-5032 800-627-8569 Incite™ Universal Tillage™ from McFarlane Mfg.

  • Page 84: Layout Diagram For Ic-5040

    Layout Diagram for IC-5040 Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...

  • Page 85: Warranty Registration Form And Inspection

    WARRANTY REGISTRATION FORM & INSPECTION REPORT This form must be filled out by the dealer and buyer and the initialed and signed copy sent to: McFarlane Mfg. Co., Inc., 1259 South Water Street, P.O. Box 100, Sauk City, WI 53583. WARRANTY REGISTRATION This form must be filled out by the dealer and signed by both the dealer and customer at the time of delivery.
  • Page 86 Notes Incite™ Universal Tillage™ from McFarlane Mfg. 800-627-8569...
  • Page 88 Last Revised 07-12-2016...

This manual is also suitable for:

Incite universal tillage ic-5012Incite universal tillage ic-5014Incite universal tillage ic-5020Incite universal tillage ic-5024Incite universal tillage ic-5027Incite universal tillage ic-5032 ... Show all

Table of Contents
