Icom IC-M424 Service Manual page 23

[DIAL UNIT]
REF ORDER
NO. NO.
S1 2250000730 TP90N245AE20PY-14.5F-3338
W1** 8900020410 OPC-2217
[CONNECT UNIT]
REF ORDER
NO. NO.
J1 6510022440 LTW-8MP-C NUTGASKET <LIA>
J2* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
[VCO UNIT]
REF ORDER
NO. NO.
J1* 6910003831 IMSA-9230B-1-04Z003-PT1
J2* 6910003831 IMSA-9230B-1-04Z003-PT1
MP1 8510020510 3338 VCO CASE Y1269
MP2 8510020520 3338 VCO COVER Y1270
[ACCESSORIES]
REF ORDER
NO. NO.
W1 8900009041 OPC-891A
MP1 8950007250 3054 MIC HANGER
MP2 8010022290 3338 MOBILE BRACKET (PE)
8010022310 3338 MOBILE BRACKET (A) PE
8010022290 3338 MOBILE BRACKET (PE)
8010022290 3338 MOBILE BRACKET (PE)
8010022290 3338 MOBILE BRACKET (PE)
8010022290 3338 MOBILE BRACKET (PE)
8010022310 3338 MOBILE BRACKET (A) PE
8010022310 3338 MOBILE BRACKET (A) PE
8010022310 3338 MOBILE BRACKET (A) PE
8010022310 3338 MOBILE BRACKET (A) PE
MP3 8820001460 3054 KNOB BOLT
8820001500 3054 KNOB BOLT(A)
8820001460 3054 KNOB BOLT
8820001460 3054 KNOB BOLT
8820001460 3054 KNOB BOLT
8820001460 3054 KNOB BOLT
8820001500 3054 KNOB BOLT(A)
8820001500 3054 KNOB BOLT(A)
8820001500 3054 KNOB BOLT(A)
8820001500 3054 KNOB BOLT(A)
MP4 8810010710 PHBT A0 3X16 SUS
MP5 8810010720 PHBT A0 5X20 SU
MP6 8850002850 PLAIN WASHER M5 SUS
MP7 8850002860 SPRING WASHER M5 SUS
MP2
W1
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[Black]
[Super white]
[Black]
[Black]
[Black]
[Black]
[Super white]
[Super white]
[Super white]
[Super white]
[Black]
[Super white]
[Black]
[Black]
[Black]
[Black]
[Super white]
[Super white]
[Super white]
[Super white]
MP6
MP3
MP5
MP7
MP4
MP1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
6 - 2
