Contec BX-M4600P2 Series Reference Manual

Box computer

Quick Links

Download this manual

Reference Manual

BOX Computer

BX-M4600P2 Series

CONTENTS

Introduction .................................................................. 5

Safety Precautions .................................................... 14

Product Nomenclature and Function ............... 20

Hardware Setup ........................................................ 37

BIOS Setup .................................................................. 51

Appendix ................................................................... 944

List of Optional Products .................................... 117

Customer Support and Inquiry ......................... 119

Table of Contents

Need help?

Do you have a question about the BX-M4600P2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Contec BX-M4600P2 Series

Page 1 Reference Manual BOX Computer BX-M4600P2 Series CONTENTS Introduction ..............5 Safety Precautions ............ 14 Product Nomenclature and Function ....20 Hardware Setup ............37 BIOS Setup ..............51 Appendix ..............944 List of Optional Products ........117 Customer Support and Inquiry ......119...
Page 2: Table Of Contents
Table of Contents Introduction ..............5 1. Related Manuals ..............................6 2. About the Product ..............................7 3. Product Lineup ................................8 4. Features ..................................9 5. Supported OS ................................ 11 6. Product Configuration List ..........................12 Safety Precautions ............14 1. Safety Information ............................... 15 2.
Page 3 Table of Contents 5. Fastening the Audio Cable,USB Cable ....................45 6. Installation Requirements .......................... 47 BIOS Setup ..............51 1. Before Configuring BIOS Settings ......................... 52 1. Using Aptio Setup Utility ..........................53 2. Setup Main Menu ..............................56 1.
Page 4 Table of Contents List of Optional Products ..........117 1. Optional Product ...............................118 Customer Support and Inquiry ........119 1. Services ..................................120 - 4 -...
Page 5: Introduction
Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. - 5 -...
Page 6: Related Manuals
— — Introduction BX-M4600P2 Series Reference Manual 1. Related Manuals The manuals related to the product are listed below. Read them as necessary along with this document. ◆ Must Read the Following Manuals. Name Purpose Contents How to get Read this when operating...
Page 7: About The Product
An embedded-type CPU has been adopted. The use of readily available parts ensures the product is easy to apply. Additionally, CONTEC- customized BIOS allows support to be provided at the BIOS level. The product also includes a built-in TPM chip to enhance information security.
Page 8: Product Lineup
— — Introduction BX-M4600P2 Series Reference Manual 3. Product Lineup The product has three models. Optional OS*¹ Model Expansion Slots Memory BX-M4600P2- 2 x PCIe(x8) G3200000 Intel® Core™ i3-13100TE BX-M4600P2A- 2 x PCI(3,3V) G3200000 (DDR5 NON-ECC BX-M4600P2- SODIMM) 2 x PCIe(x8)
Page 9: Features
15 seconds. The "Disk Copy" function provides secure disk backup at the BIOS level, and also supports backup in file format or compressed file format. We also offer the CONTEC tools “BIOS update tool” for updating BIOS. ◼ Fan-less design reduces maintenance work The product is fan-less to ensure a totally spindle-less design that simplifies maintenance, relieving the concern about dust or foreign matter to get into the product.
Page 10 *2 It is the actual measured value when Windows 10 and HORM function are enabled at the factory. Time may vary depending on configuration. Note that Network Stack, and SMART Self-Test are not supported when the CONTEC Fast Boot is enabled. *3 Contact your retailer for more information.
Page 11: Supported Os
— — Introduction BX-M4600P2 Series Reference Manual 5. Supported OS Windows®10 IoT Enterprise LTSC 2021 64 bit - 11 -...
Page 12: Product Configuration List
*1 The configuration and parts of this product are shown below. *2 The user manual for this product is available as a PDF file through CONTEC’s website. *3 We highly recommend using a wide temperature HDD. Otherwise, the operation temperature should under 40℃, 24 hours...
Page 13 — — Introduction BX-M4600P2 Series Reference Manual Production Configuration Drawings BX-M4600G-G3 Series Main Body BX-M4600G -G5 / -G7 Series Main Body The Main Body The Attachment Fittings USB Removal DVI-Angle RBG Con The Attachment Prevention Fitting version Adapter Rubbers Washer Assembled...
Page 14: Safety Precautions
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 14 -...
Page 15: Safety Information
— — Safety Precautions BX-M4600P2 Series Reference Manual 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.
Page 16: Handling Precautions
— — Safety Precautions BX-M4600P2 Series Reference Manual 2. Handling Precautions WARNING Always check that the power supply is turned off before connecting or disconnecting power ⚫ cables. Do not modify the product. ⚫ Always turn off the power before inserting or removing circuit boards or cables.
Page 17 To prevent corruption of files, always shutdown the OS before turning off this product. ⚫ CONTEC reserves the right to refuse to service a product modified by the user. ⚫ In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ⚫...
Page 18: Fcc Part 15 Class A Notice
— — Safety Precautions BX-M4600P2 Series Reference Manual 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 19: Security Warning
— — Safety Precautions BX-M4600P2 Series Reference Manual 3. Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1. Information security risks Unauthorized access from the outside through a network could cause the system halt, data ⚫...
Page 20: Product Nomenclature And Function
Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 20 -...
Page 21: Nomenclature Of Product Components
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 1. Nomenclature of Product Components Component names of the product are shown in the figure below. (Heat sink shape will vary based on SKU) ◆ Front View ◆ Rear View...
Page 22 — — Product Nomenclature and Function BX-M4600P2 Series Reference Manual Item Name Function Front DC-IN DC power input connector POWER SW Power switch USB3.0 USB3.2 (Gen 2×1) port TYPE-A connector x 4 USB2.0 USB2.0 port TYPE-A connector x 2 DVI-I...
Page 23: Description Of Product Components
ON (Red) You can control the behavior of LED from the used application. *1 *1 CONTEC Manager that controls STATUS LED is available. (It is already installed for the product OS pre- installed type when shipped from the factory) CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer.
Page 24: Power Switch: Power Sw
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual Rise time of power supply Voltage 3. Power Switch: POWER SW Power SW is provided. The power of the product can be turned on or turned off with this switch.
Page 25: Serial-Ata: Sata 1, Sata 2
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 6. Serial-ATA: SATA 1, SATA 2 The product has two ports of serial ATA 3.0 compliant controllers. Connector used on the product SATA connector Pin No. Signal name Pin No.
Page 26: Dvi-I Interface
7. DVI-I Interface A DVI-I interface is provided. A CRT display (or a 15-pin D-SUB CRT when the included DVI–Analog RGB conversion adapter is used) or a flat-panel display from CONTEC can be connected. The connector name is DVI (DVI-I 29 pin).
Page 27 — — Product Nomenclature and Function BX-M4600P2 Series Reference Manual DVI-analog RGB conversion adapter Connector type DVI-I Analog RGB signals Pin No. Signal name Pin No. Signal name GREEN BLUE N.C. N.C. DDC DATA HSYNC VSYNC DDC CLK CAUTION If the OS is booted without connecting the display cable to the DVI interface, and then the ⚫...
Page 28: Display Port Interface
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 8. Display Port Interface A display port interface is provided. As such, a display equipped with a Display Port can be connected. Connector used on the product Display Port 20 Pin...
Page 29: Usb3.2 (Gen 2×1) Port
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 9. USB3.2 (Gen 2×1) Port This product is equipped with 4 channels for USB 3.0 TYPE-A interface. USB3.2 Connector Pin No. Signal Name USB_VCC DATA- DATA+ USB_GND SSRX- SSRX+ USB_GND...
Page 30: Gigabit-Ethernet
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 11. Gigabit-Ethernet This product is equipped with 2 ports for gigabit. Network Type: 2500/1000 BASE-T/ 100 BASE-TX/ 10 BASE-T Transmission Speed : 2500M/1000M/ 100M/ 10M bps Max. network path length: 100m/ segment ®...
Page 31: Serial Port Interface: Serial 1, 2, 3, 4
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 12. Serial Port Interface: Serial 1, 2, 3, 4 The product has 3 channels of RS-232C and 1 channel of RS-232C/422/485 compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer.
Page 32 — — Product Nomenclature and Function BX-M4600P2 Series Reference Manual Serial B, C, D port connector Connector used on the product 9-pin D-SUB (MALE) Pin No. Signal Name Description Direction Carrier detect Input Received data Input Transmitted data Output Data terminal ready...
Page 33: Dio Port
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 13. DIO Port The product is equipped with an interface to which you can connect a remote switch and a GPIO device. GPIO is not isolated. Connector type 9-pin D-SUB (FEMALE)
Page 34 — — Product Nomenclature and Function BX-M4600P2 Series Reference Manual Input equivalent circuit When selecting inputs (an example of connecting the product to a switch) When the switch is “ON”, the relevant bit indicates “0”. When the switch is “OFF”, the relevant bit indicates “1”.
Page 35: Expansion Slots
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 14. Expansion slots BX-M4600P2 has two PCI-Express(x8) slots and two expansion slots for the implementation of PCI bus type card. BX-M4600P2A has two expansion slots for the implementation of PCI bus type card.
Page 36: Jumper List
— — Product Nomenclature and Function BX-M4600P2 Series Reference Manual 3. Jumper List For users to customize BX-M4600 series features. In the following sections, short means covering a jumper cap over jumper pins; Open or N/C (not connected) means removing a jumper cap from jumper pins.
Page 37: Hardware Setup
Hardware Setup This section describes how to install, connect, and set up the product. - 37 -...
Page 38: Before Using The Product For The First Time
— — Hardware Setup BX-M4600 Series Reference Manual 1. Before Using the Product for the First Time Follow the next steps to set up this product: STEP1 By referring to the information in this section, install, connect and set up this product. STEP2 Connect cables.
Page 39: Hardware Setup
— — Hardware Setup BX-M4600 Series Reference Manual 2. Hardware Setup Before you start, be sure that the power is turned off. ⚫ Remove only those screws that are explained. Do not move any other screws. ⚫ You can equip the product with slot-in type 2.5-inch SATA storage. ⚫...
Page 40 — — Hardware Setup BX-M4600 Series Reference Manual CAUTION When tightening the screws to fasten the HDD / SSD to the bracket or the HDD mounted ⚫ bracket to the product, do not use any tool such as an electric screwdriver, which vibrates the HDD / SSD.
Page 41: Attaching The Attachment Fittings
— — Hardware Setup BX-M4600 Series Reference Manual 2. Attaching the Attachment Fittings Use the screws to attach the bundled attachment fittings with a screw. Do not tighten screws with excess force. CAUTION Screw holes may be damaged if screws are tightened with a torque greater than the specified ⚫...
Page 42 — — Hardware Setup BX-M4600 Series Reference Manual Remove the brackets holding the PCB. Remove the screws toward the top and pull the bracket forward to remove. - 42 -...
Page 43 — — Hardware Setup BX-M4600 Series Reference Manual Insert the card into the slot and secure it with the screws. Attach the bracket that holds the slot cover - 43 -...
Page 44 — — Hardware Setup BX-M4600 Series Reference Manual Attach the brackets that hold the PCB Attach the top cover. CAUTION Make sure the expansion card is securely attached. ⚫ Screw holes may be damaged if screws are tightened with a torque greater than the ⚫...
Page 45: Attaching The Fg
— — Hardware Setup BX-M4600 Series Reference Manual 4. Attaching the FG Use screws to attach the FG. CAUTION The FG pin of this product is connected to the GND signal of the DC power connector (DC- ⚫ IN). Note that the connection cannot be cut off. ⚫...
Page 46 — — Hardware Setup BX-M4600 Series Reference Manual Bunch the audio cables together using the audio cable tie, and attach the cable tie to the main unit. - 46 -...
Page 47: Installation Requirements
— — Hardware Setup BX-M4600 Series Reference Manual 6. Installation Requirements The product can be installed in any orientation (1) through (4). Increase the distance between the main unit and devices that generate heat or exhaust air or take other measures to ensure the ambient temperature falls within the range specified in the installation environment requirements.
Page 48 — — Hardware Setup BX-M4600 Series Reference Manual Distances between the BOX-PC and its vicinity (Exemplar) CAUTION Wall temperatures should be within the guaranteed operating temperature range of the ⚫ product. Adjust the air flow so as not to allow waste heat from the product to accumulate around the ⚫...
Page 49 — — Hardware Setup BX-M4600 Series Reference Manual Minimum distance for removing the SATA disk Maintain a wall temperature that is less than or equal to the product's guaranteed temperature. ⚫ Please adjust the air current to prevent the reject heat from the product staying around the ⚫...
Page 50: Ambient Temperature
— — Hardware Setup BX-M4600 Series Reference Manual Ambient temperature In this product, the ambient temperature is decided from the multiple measurement points as shown below. When making use of the product, the air current should be adjusted to prevent all the temperatures measured at the measurement points exceed the specified temperature.
Page 51: Bios Setup
BIOS Setup This section describes how to configure, change. and check BIOS setting used to manage basic computer information - 51 -...
Page 52: Before Configuring Bios Settings
— — BIOS Setup BX-M4600P2 Series Reference Manual 1. Before Configuring BIOS Settings The BIOS software controls the hardware required for booting the system. The default BIOS settings are configured for optimal performance under normal use. These default settings are recommended under the following circumstances.
Page 53: Using Aptio Setup Utility
— — BIOS Setup BX-M4600P2 Series Reference Manual 1. Using Aptio Setup Utility This section explains how to use Aptio Setup Utility. ◆ Starting the Setup Utility Aptio Setup Utility can be started by any of the following methods. By pressing <Del> or <Esc> key immediately after turning on the pc.
Page 54: Key Operations
— — BIOS Setup BX-M4600P2 Series Reference Manual ◆ Key Operations Use the following keys to operate the setup utility. Function Up Arrow Move to the previous item Down Arrow Move to the next item Left Arrow Move to the item on the left (menu bar)
Page 55: Discard Changes And Exit
— — BIOS Setup BX-M4600P2 Series Reference Manual Discard Changes and Exit Exit Aptio Setup Utility without saving the changed settings. Press the <Esc> key or select “Discard Changes and Exit” in the “Save & Exit” menu screen. The following message will be displayed Select [Yes], and press the <Enter>...
Page 56: Setup Main Menu
— — BIOS Setup BX-M4600P2 Series Reference Manual 2. Setup Main Menu The six menu options in Aptio Setup Utility are shown below. Use the right or left arrow key to navigate between menus, and use the up or down arrow key to access the settings.
Page 57: Menu Items
— — BIOS Setup BX-M4600P2 Series Reference Manual 1. Menu Items The selectable tabs are as follows. Main View the basic system structure and configure the language settings and the date and time settings. Advanced Use this menu to specify the detailed functions that can be set on the system in use.
Page 58: Main
— — BIOS Setup BX-M4600P2 Series Reference Manual 3. Main View the basic system structure. The following items are displayed. Indication item of the main menu Item Indication Example Explanation Project Version M4600C 1.03 x64 Displays the BIOS version. Build Date and Time...
Page 59: Advanced
— — BIOS Setup BX-M4600P2 Series Reference Manual 4. Advanced This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. (Actual display may differ) CPU Configuration Configure the CPU settings. PCH-FW Configuration Configure the management engine technology parameters.
Page 60 — — BIOS Setup BX-M4600P2 Series Reference Manual Network Stack Configuration Network Stack settings. NVMe Configuration NVMe Device Options settings. Intel® Rapid Storage Technology (This form set allows the user to manage RAID volumes on the intel® RAID Controller). Intel® Ethernet Controller I226-IT- ( LAN_A MAC ADDRS.)
Page 61: Cpu Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 1. CPU Configuration Efficient-core Information (Efficiency core messages that will be displayed when the CPU SKU supports) Displays the E-core Information. Performance-core Information Displays the E-core Information. Item Options Description When enabled, a VMM can utilize the...
Page 62 — — BIOS Setup BX-M4600P2 Series Reference Manual Item Options Description Enabled Enable or Disable Hyper-Threading Hyper-Threading Disabled Technology Max Battery Select th performance State that the Max Non-Turbo Boot performance mode Performance BIOS will set staring from reset vector.
Page 63: Pch-Fw Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 2. PCH-FW Configuration PCH-FW Configuration Item Options Description Enabled When disabled ME will be put into ME Temporarily ME State Disabled Disabled mode. - 63 -...
Page 64: Trusted Computing
— — BIOS Setup BX-M4600P2 Series Reference Manual 3. Trusted Computing TRUSTED Configuration Item Options Description Enables or Disables BIOS support for security Device. Enable Security Device Support TCG EFI protocol. And INT1A interface will not be Disable available. Enabled...
Page 65: Acpi Setting
— — BIOS Setup BX-M4600P2 Series Reference Manual 4. ACPI Setting ACPI Setting Item Options Description Enables or Disables system ability to Hibernation (OS/S4 Sleep State).this Enabled Enable Hibernation Disabled option may not be effective with some operation systems. Select the highest ACPI sleep state the...
Page 66 — — BIOS Setup BX-M4600P2 Series Reference Manual Item Options Description Set the minute at which the system will RTC Wake up Minute 0 - 59 automatically turn on. Set the second at which the system will 0 - 59 RTC Wake up Second automatically turn on.
Page 67: Ras Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 5. RAS Configuration RAS Configuration Item Options Description Enabled Enables or Disables WDT function during boot of WDT during Boot of BIOS Disabled BIOS Enabled Enables or Disables WDT function during boot of...
Page 68: Nct6126D Super Io Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 6. NCT6126D Super IO Configuration Super IO Configuration default Item Options Description Serial Port 1 Configuration -IO=3F8h; IRQ=4; Refer to Serial Port 1 Configuration Serial Port 2 Configuration - IO=2F8h; IRQ=3; Refer to Serial Port 2 Configuration Serial Port 3 Configuration - IO=3E8h;...
Page 69: Digital I/O Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual Item Options Description performed, and it eliminates software controlling. This function is only available when "RS- 485" is selected for Mode Select. It is only performed with the sets listed below. 8bits data + 1bit parity + 1bit stop...
Page 70: Hardware Monitor
— — BIOS Setup BX-M4600P2 Series Reference Manual 7. Hardware Monitor View hardware monitor information such as the CPU temperature. (Actual display may differ) - 70 -...
Page 71: Usb Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 8. USB Configuration (Actual display may differ) USB Configuration Item Options Description USB Mass Storage Driver Configure the USB storage support settings with Enabled Support BIOS. Disabled Set the USB power (5 V) status when entering the S5 state after shutting down the OS.
Page 72: Netware Stack Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 9. Netware Stack Configuration Netware Stack configuration Item Options Description Enabled Netware Stack Enable /Disable UEFI network stack Disabled Netware Stack (Available only when Enabled is selected) Item Options Description Enabled Ipv4 PXE Support Enable IPv4 PXE boot.
Page 73: Nvme Configurations
— — BIOS Setup BX-M4600P2 Series Reference Manual 10. NVMe Configurations (Picture showing the display example after NVMe SSD installation) - 73 -...
Page 74: Intel(R) Rapid Storage Technology
— — BIOS Setup BX-M4600P2 Series Reference Manual 11. Intel(R) Rapid Storage Technology CAUTION If SATA Mode Selection is not set to Intel RST(RAID), Intel(R) Rapid Storage Technology will not be displayed Create RAID Volume Create RAID volume. - 74 -...
Page 75 — — BIOS Setup BX-M4600P2 Series Reference Manual Create RAID Volume Item Options Description Name Volume1 Set the volume name of RAID volume. RAID0 (Stripe) Set the type of RAID volume. Do not set other than RAID Level RAID1 (Mirror) Recovery RAID1(Mirror).
Page 76 The model, the serial number, capacity, and state of SATA 0.3, XXXXX, XXXGB SATA disk without RAID setting are displayed. CAUTION The CONTEC only supports mirroring. If you intend to create RAID volume other than ⚫ mirroring, we leave it as user’s option. - 76 -...
Page 77: Intel®Ethernet Controller I226-It-(Lan_A: Mac Addrs)
— — BIOS Setup BX-M4600P2 Series Reference Manual 12. Intel®Ethernet Controller I226-IT- (LAN_A: MAC addrs) - 77 -...
Page 78: Intel®Ethernet Controller I226-It-( Lan_B Mac Addrs)
— — BIOS Setup BX-M4600P2 Series Reference Manual 13. Intel®Ethernet Controller I226-IT- ( LAN_B MAC addrs) - 78 -...
Page 79: Driver Health
— — BIOS Setup BX-M4600P2 Series Reference Manual 14. Driver Health - 79 -...
Page 80: Chipset
— — BIOS Setup BX-M4600P2 Series Reference Manual 5. Chipset Use this menu to check the detailed features of chipset. The following items are available: System Agent (SA) Configuration Configure system agent (SA) settings. PCH-IO Configuration Configure the HD Audio subsystem.
Page 81: System Agent (Sa) Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 1. System Agent (SA) Configuration (Actual display may differ) System Agent (SA) Configuration Item Options Description Use this menu to view the memory Memory Configuration information. Graphics Configuration Refer to Graphics Configuration...
Page 82 — — BIOS Setup BX-M4600P2 Series Reference Manual VDM setup menu ∙ RAID (VMD) Disabled: Display HDD information as plugging in status. ⚫ ∙ RAID (VMD) Enabled: Display "Not Present" only ⚫ - 82 -...
Page 83: Pch-Io Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual 2. PCH-IO Configuration Configure how memory will be used when using the graphic function. Leave these settings as configured before shipment. SATA Configuration - 83 -...
Page 84: Hd Audio Configuration
— — BIOS Setup BX-M4600P2 Series Reference Manual Item Options Description Enabled SATA Controller(s) Enable / Disable SATA Device Disabled SATA Mode Selection AHCI Determine how SATA controller(s) operate. Enabled Port 1 Enable or Disable SATA Port Disabled Enabled Port 2...
Page 85: Security
— — BIOS Setup BX-M4600P2 Series Reference Manual 6. Security Administrator Password Set the Administrator Password. Press Enter to display the following screen for entering the password. Administrator Password Create New Password **** Confirm New Password [ **** Enter a password at least 3 characters long twice.
Page 86 — — BIOS Setup BX-M4600P2 Series Reference Manual Logging Boot Logging Boot menu Configure the Logging Boot settings. Use these settings to save self-diagnosis logs to a USB memory device at startup. The USB memory device must be in FAT32 format. The log will be saved as a .csv file.
Page 87: Boot
— — BIOS Setup BX-M4600P2 Series Reference Manual 7. Boot Configurate the settings boot devices and other devices Boot Configuration Item Options Description Set the standby time for BIOS Setup Setup Prompt Timeout <DEL> or <F2> input. Unit : [second] Set the NumLock status when the system starts.
Page 88: Save And Exit
— — BIOS Setup BX-M4600P2 Series Reference Manual 8. Save and Exit Load/ Save setup items and exit the setup menu. Save Changes and Exit Save the changed settings and exit. Restart the system if settings that require a restart have been changed.
Page 89 — — BIOS Setup BX-M4600P2 Series Reference Manual Restore User Defaults Return the settings to the user default values. Boot Override Specify this setting when you want to temporarily start the system from a connected device other than those that have been set with the Boot Configuration menu. The bootable connecting devices are displayed.
Page 90 — — BIOS Setup BX-M4600P2 Series Reference Manual (Actual display may differ) Disk copy Item Options Description USBx: xxx Displays the names of the connected USB and SATA Slotx:xxx Erase devices. Select the copy source disk. Select Source Disk When Erase is selected, the entire disk selected as the copy destination is filled with 0x00.
Page 91 — — BIOS Setup BX-M4600P2 Series Reference Manual Item Options Description FAT32 format. Copying ends when the size limit for the copy destination disk is reached, even if the copy has not yet been completed. File to Disk: The copy source disk file data is copied to the copy destination disk.
Page 92 — — BIOS Setup BX-M4600P2 Series Reference Manual Self Inspection Use this menu item to perform self-inspection. (Actual display may differ) Item Options Description PASS FAIL Checks whether the expected PCI devices are present. [PASS] is displayed if all devices are PCI Device Activity present.
Page 93 LAN EEPROM Check Checking will not be possible if no LAN device is FAIL found. PASS Check whether the MAC data from CONTEC has CONTEC MAC FAIL been written. PASS Check whether the MAC data is unique in the actual...
Page 94: Appendix
Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. - 94 -...
Page 95: System Reference
— — Appendix BX-M4600P2 Series Reference Manual 1. System Reference 1. Specifications Function Specifications Model Name BX-M4600P2x Series BX-M4600P2x-G7300000 Generation Raptor lake-S Intel® Core™ i7-13700TE Processor BX-M4600P2x-G5x00000 Processor Generation Raptor lake-S Intel® Core™ i5-13500TE Processor BX-M4600P2x-G3200000 Generation Raptor lake-S Intel® Core™ i3-13100TE Processor Chipset Intel®...
Page 96: Environment Requirements
— — Appendix BX-M4600P2 Series Reference Manual Rated Voltage Range 12 - 24VDC ±10% Input voltage range 9~36V Wide Rage DC Input BX-M46000P2-xxxxxxxxx : 12V 8.8A, 24V 4.7A Power consumption BX-M4600P2A-xxxxxxxxx : 12V 8.1A, 24V 4.3A SATA slot : +5V : 2.0A (1,000mA x 2 per slot) External device power USB3.2 Gen2x1 I/F : +5V : 3.6A (900mA x 4 per port)
Page 97: Power Management Features
— — Appendix BX-M4600P2 Series Reference Manual Grounding Class D Grounding, SG-FG/ Continuity VCCI Class A, FCC Class A, Certification CE Marking (EMC Directive Class A, RoHS Directive), UKCA 2. Power Management Features - Support both ACPI (Advanced Configuration and Power Interface).
Page 98: Physical Dimensions
— — Appendix BX-M4600P2 Series Reference Manual 2. Physical Dimensions All Dimensions shown in mm (millimeters.) * The length (L) from the tip of M4 boss to the M4 screw tip should be 5mm or less. If not doing so, it may be exactly fixed.
Page 99: Maintenance
— — Appendix BX-M4600P2 Series Reference Manual 3. Maintenance 1. Dispose of the Battery WARNING For battery replacement, contact your retailer as it must be performed as a process of repair. ⚫ Do not attempt to replace the battery as inappropriate battery replacement ⚫...
Page 100 — — Appendix BX-M4600P2 Series Reference Manual Remove the enclosure where the expansion slots are installed. Remove the battery from the battery holder. - 100 -...
Page 101: Post Codes
— — Appendix BX-M4600P2 Series Reference Manual 4. Post Codes Description POST (hex) < Security (SEC) phase > Power ON. The detection of the reset kind (Hard/Soft) Initialize the microcode load previous AP Initialize the microcode load previous North Bridge...
Page 102 — — Appendix BX-M4600P2 Series Reference Manual POST Description South Bridge runtime services installation (hex) CPU DXE installation start 64h - 67h CPU DXE installation start (Specific CPU module) PCI host bridge installation North Bridge DXE initialization starts North Bridge DXE SMM initialization starts...
Page 103 — — Appendix BX-M4600P2 Series Reference Manual Description POST Legacy boot event (hex) Boot Service event ends Virtual address maps run-time settings begin. Virtual address maps of runtime configuration exit Legacy option ROM initialization System reset USB hot plug PCI bus hot plug...
Page 104: Serial I/O Address And Register Function
— — Appendix BX-M4600P2 Series Reference Manual 5. Serial I/O Address and Register Function The following table lists the I/O addresses in case of SERIAL A. I/O Port Addresses I/O address DLAB Read/Write Register 03F8H Transmitter holding register Receiver buffer register...
Page 105 — — Appendix BX-M4600P2 Series Reference Manual DLH: Divisor Latch (MSB) [DLAB=1] 03F9H Baud rate setting register (MSB) I/O address Description IER: Interrupt Enable Register [DLAB=0] 03F9H IIR: Interrupt Identification Register 03FAH - 105 -...
Page 106 — — Appendix BX-M4600P2 Series Reference Manual LCR: Line Control Register 03FBH Description I/O address MCR: Modem Control Register 03FCH - 106 -...
Page 107: Baud Rate Settings
— — Appendix BX-M4600P2 Series Reference Manual LSR: Line Status Register 03FDH MSR: Modem Status Register 03FEH SCR: Scratchpad Register This is an 8-bit, readable/writable register which is available to the 03FFH user to allow data to be saved temporarily.
Page 108 — — Appendix BX-M4600P2 Series Reference Manual 134.5 0.099 1200 1800 2000 0.53 2400 3600 4800 7200 9600 14400 19200 28800 38400 57600 76800 115200 153600 230400 Example: To set 9,600 bps, write "00" to the (MSB) divisor latch register and "12 (decimal)" to the (LSB) divisor latch register.
Page 109: Watch-Dog-Timer
— — Appendix BX-M4600P2 Series Reference Manual 6. Watch-Dog-Timer The watchdog timer serves as a safeguard against possible system lock-up in your industrial computer system. In most industrial environments, there are heavy equipment, generators, high- voltage power lines, or power drops that have adverse effects on your computer system. For instance, when a power drop occurs, it could cause the CPU to come to a halt state or enter into an infinite loop, resulting in a system lock-up.
Page 110 — — Appendix BX-M4600P2 Series Reference Manual Example programming The following example is written in Intel8086 assembly language. ;=============== ;<WDT Initial> ;=============== ;------------------------------------------- ;Enter the extended function mode ;------------------------------------------- MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;---------------------------------------------- ;Select logical device WDT(number 8) ;----------------------------------------------...
Page 111 — — Appendix BX-M4600P2 Series Reference Manual MOV AL,00H OUT DX,AL ;------------------------------------------ ;Exit the extended function mode ;------------------------------------------ MOV DX,2EH MOV AL,AAH OUT DX,AL ;=============================== ;<WDT START: counter set and a start> ;=============================== ;--------------------------------------------- ;Enter the extended function mode ;---------------------------------------------...
Page 112 — — Appendix BX-M4600P2 Series Reference Manual ;---------------------------------------------------------------------------------- OUT DX,AL ;--------------------------------------- ;Exit the extended function mode ;--------------------------------------- MOV DX,2EH MOV AL,AAH OUT DX,AL ;============== ;<WDT STOP> ;============== ;----------------------------------------- ;Enter the extended function mode ;----------------------------------------- MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;-----------------------------------...
Page 113 MOV AL,AAH OUT DX,AL CONTEC Manager is necessary to use the watch-dog-timer. (It is already installed for the product OS pre- installed type when shipped from the factory.) CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer.
Page 114: Battery Disposal
— — Appendix BX-M4600P2 Series Reference Manual 7. Battery Disposal 1. Battery Specification The product contains one battery, and the details are as follows: Item Description Type Lithium primary battery Model BR-2032/BN Maker Panasonic Nominal Voltage Nominal capacity 200mAh Lithium content 1g or less 2.
Page 115 — — Appendix BX-M4600P2 Series Reference Manual Remove the screws from the cover of the main unit, and then remove the unit cover. Remove the six screws along the sides of the enclosure where the expansion slots are installed. - 115 -...
Page 116 — — Appendix BX-M4600P2 Series Reference Manual Remove the enclosure where the expansion slots are installed. Remove the battery from the battery holder. - 116 -...
Page 117: List Of Optional Products
List of Optional Products This section lists optional items that can be used along with the product. - 117 -...
Page 118: Optional Product
Optional product items are as follows, please acquire them as required. Accessory Parts Name Product Code Description AC Adaptor 43580760 Input: 100-240VAC, Output: 24VDC 5A 48452300 2.5-inch SATA HDD 1TB 48452050 2.5-inch SATA SSD 64GB Visit the CONTEC website for the latest optional products. https://www.contec.com/ Download - 118 -...
Page 119: Customer Support And Inquiry
Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 119 -...
Page 120: Services
— — Customer Support and Inquiry BX-M4500P2/P2A Series Reference Manual 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
Page 121: Revision History
—— BX-M4500P2/P2A Series Reference Manual Revision History MONTH YEAR Summary of Changes January 2025 The First Edition - 121 -...
Page 122 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. BX-M4500P2/P2A Series Reference Manual NA10448 (LXEC271) [01062025]...

This manual is also suitable for:

Bx-m4600p2- g3200000 Bx-m4600p2a-g3200000 Bx-m4600p2- g5200000 Bx-m4600p2a-g5200000 Bx-m4600p2- g5300000 Bx-m4600p2a-g5300000 ... Show all
