Summary of Contents for Xtool M1 Ultra
- Page 1 M1 Ultra Quick Start Guide...
- Page 2 List of items Meet your xTool M1 Ultra Preparations Use xTool M1 Ultra Indicator description...
-
Page 3: List Of Items
List of items Smoke exhaust xTool M1 Ultra Laser module USB cable module × 8 Power cable Fine-point blade Fine-point pen Pen holder and adapter × 4 × 10 Triangular Cutting mat Cutting mat Triangular prism prism holder (LightGrip) (FabricGrip) ×... - Page 4 Meet your xTool M1 Ultra...
- Page 5 Basic carriage Start/Stop button Power port Multi-function holder Rotary Attachment port Port for the key Wi-Fi antenna Thumb screw for the baseplate Extension port × 4 Camera viewfinder point Tube fitting for the air assist set USB port Indicator Tube fitting for the fire safety set Smoke outlet Point marking button Power switch...
- Page 6 Preparations Remove the screws that fix the x-axis and y-axis guide rails Install the laser module...
- Page 7 Install the smoke exhaust module Do not use the smoke exhaust module without the filter. Or it may absorb smoke and dust and get damaged.
- Page 8 Insert the key ■ Insert the key to unlock the processing and related functions. ■ You can remove the key to lock the processing and related functions. Connect to a power supply...
- Page 9 Turn on xTool M1 Ultra, connect it to a device, and then connect it on XCS. Connect device ■ For details about how to use the software to operate xTool M1 Ultra for material processing, scan the QR code or visit support.xtool.com/product/35.
- Page 10 Use xTool M1 Ultra For laser cutting × 10 × 4 ■ Fit the other two triangular prism holders together in the same way. ■ Determine the number of the triangular prisms based on the material to be processed.
- Page 11 For blade cutting or combination of laser processing and blade cutting (1) Put the cutting mat on the baseplate Note: For paper materials such as cardboard and kraft paper, use the LightGrip cutting mat; and for fabric materials such as cloth, use the FrabicGrip cutting mat. Do not use any cutting mat when cutting a material with laser beams.
- Page 12 (2) Install the fine-point blade on the basic carriage Caution! Sharp blade...
- Page 13 For pen drawing (1) Install the fine-point pen on the pen holder...
- Page 14 (2) Install the fine-point pen on the multi-function carriage Caution! Sharp blade...
- Page 15 For more functions (2) Install the accessory on the multi-function carriage...
- Page 16 Select accessories according to the processing needs. ■ Ensure that the sign faces you when fitting the cutting blade. Caution! Sharp blade...
- Page 18 Indicator description Indicator status Buzzer status Device status Standby, not connected to XCS Solid white (at AP mode) Standby, not connected to XCS Solid light blue (at STA mode) Solid purple Sounding once Standby, connected to XCS Breathing white Sleeping, not connected to XCS Breathing purple Sleeping, connected to XCS Blinking purple slowly...
