Battery Installation
Insulating Gloves
4.2
Pre-installation Check
• Ensure that the battery is away from open flames, heat sources
• Cut off the power before wiring, installing or removing the
• To prevent electric shock, please remove watches, bracelets, rings
4.3
Battery Connection
4.3.1 Single Battery
Terminal Connection
Insulating Cap
9 ± 1 N·m
Terminal Bolt
Battery Adapter Cable
Safety Goggles
and flammable materials.
battery.
and other conductive items (if any) and wear insulating gloves and
safety goggles before installation.
Bus Bar
Charger
00
O-EC
OX122
2BOC
External Devices
-
-
-
+
+
+
Inverter
MPPT
3
