User's guide
"SHU" series
Commercial industrial unit heater
Replacement component list included
This unit complies with
the CSA and UL standards
For further information or to consult this guide online, please visit our Web site.
INSSHU0911

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Stelpro SHU Series

  • Page 1 User’s guide “SHU” series Commercial industrial unit heater Replacement component list included This unit complies with the CSA and UL standards For further information or to consult this guide online, please visit our Web site. INSSHU0911...
  • Page 2 If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings).
  • Page 3: Specifications

    SPECIFICATIONS COMMERCIAL INDUSTRIAL UNIT HEATER MODEL WATTS 2 to 10 kW 15 to 30 kW 40 to 60 kW WEIGHT 32 lb / 15 kg 60 lb / 27 kg 95 lb / 44 kg LENGTH 15’’ / 394 mm 17 5/8’’...
  • Page 4 INSTALLATION N.B. Cut off power supply at circuit breaker/fuse before proceeding to the installation. For best results, the following distances shall be respected when installing these unit heaters. Maximum height from the floor Minimum distance from the wall 2-10 kW models 8 ft (2.4 m) 6 in.
  • Page 5 REPLACEMENT COMPONENT LIST PARTS DESCRIPTION PARTS DESCRIPTION PARTS DESCRIPTION BLA-008 BLADE 10” 20° 5B (2-5 kW) ELF-SHU2561 ELEMENT (KIT) 25 kW 600 V 1 PH ELF-SHU761 ELEMENT (KIT) 7,5 kW 600 V 1 PH BLA-010 BLADE 10” 32° 4B (7,5-10 kW) ELF-SHU2563 ELEMENT (KIT) 25 kW 600 V 3 PH ELF-SHU763...
  • Page 6 Moreover, it does not cover the cost of disconnection, transport, and installation. The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty period.
