REFRIGERATOR-FREEZER
USER'S MANUAL
PXISBSWI 513 ENW
PXISBSWI 513 ENX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PXISBSWI 513 ENW and is the answer not in the manual?

Questions and answers

Summary of Contents for Philco PXISBSWI 513 ENW

  • Page 1 REFRIGERATOR-FREEZER USER’S MANUAL PXISBSWI 513 ENW PXISBSWI 513 ENX...
  • Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user‘s manual. Copyright © 2024, Fast ČR, a. s. Revision 01/2024...
  • Page 3: Table Of Contents

    CONTENTS PART 1: SAFETY INFORMATION........................2 PART 2: OVERVIEW ............................12 PART 3: INSTALLATION ..........................14 Product accessories ..................................14 Remove the doors ....................................14 Space requirement ..................................16 Levelling the refrigerator ................................16 Positioning ......................................17 Location .......................................17 Electrical connection ..................................17 PART 4: DAILY USE ............................18 Using the control panel .................................21 Display ........................................22 Door open alarm ....................................22 Child safety lock ....................................23...
  • Page 4: Part 1: Safety Information

    PART 1: SAFETY INFORMATION FOR YOUR SAFETY AND CORRECT USAGE, BEFORE INSTALLING AND FIRST USING THE APPLIANCE,READ THIS USER MANUAL CAREFULLY, INCLUDING ITS HINTS AND WARNINGS. TO AVOID UNNECESSARY MISTAKES AND ACCIDENTS,IT IS IMPORTANT TO MAKE SURE THAT ALL PEOPLE USING THE APPLIANCE ARE THOROUGHLY FAMILIAR WITH ITS OPERATION AND SAFETY FEATURES.
  • Page 5 IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A SPECIALIZED SERVICE CENTER IN ORDER TO AVOID DANGEROUS SITUATIONS. IT IS PROHIBITED TO USE THE APPLIANCE WHEN THE SUPPLY CABLE IS DAMAGED. WARNING: THE VENTILATION OPENINGS IN THE APPLIANCE HOUSING OR IN ITS CONSTRUCTION MUST BE KEPT FREE.
  • Page 6 THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLDS AND SIMILAR PREMISES, SUCH AS: – KITCHENETTES IN SHOPS, OFFICES AND OTHER WORKPLACES; – APPLIANCES USED BY GUESTS IN HOTELS, MOTELS, AND OTHER ACCOMMODATION FACILITIES; – APPLIANCES USED IN BED-AND-BREAKFAST FACILITIES; –...
  • Page 7 WARNING : RISK OF FIRE / FLAMMABLE MATERIALS CONTAINS COOLING GAS ISOBUTANE R600a REFRIGERANT THE REFRIGERANT ISOBUTENE (R600a) IS CONTAINED WITHIN THE REFRIGERANT CIRCUIT OF THE APPLIANCE,A NATURAL GAS WITH A HIGH LEVEL OF ENVIRONMENTAL COMPATIBILITY,WHICH IS NEVERTHELESS FLAMMABLE. DURING TRANSPORTATION AND INSTALLATION OF THE APPLIANCE,ENSURE THAT NONE OF THE COMPONENTS OF THE REFRIGERANT CIRCUIT BECOMES DAMAGED.
  • Page 8 WARNING : RISK OF FIRE / FLAMMABLE MATERIALS IF THE REFRIGERANT CIRCUIT SHOULD BE DAMAGED: - AVOID OPENING FLAMES AND SOURCES OF IGNITION. - THOROUGHLY VENTILATE THE ROOM IN WHICH THE APPLIANCE IS SITUATED. IT IS DANGEROUS TO ALTER THE SPECIFICATIONS OR MODIFY THIS PRODUCT IN ANY WAY.
  • Page 9: Electrical Safety

    IF THE COOLING APPLIANCE IS LEFT EMPTY FOR A LONGER PERIOD OF TIME, IT SHOULD BE SWITCHED OFF, DEFROSTED, CLEANED AND DRIED AND THE DOOR SHOULD BE LEFT OPEN TO PREVENT MOULD FROM FORMING INSIDE THE APPLIANCE. ELECTRICAL SAFETY 1. THE POWER CORD MUST NOT BE LENGTHENED. 2.
  • Page 10: Daily Use

    THE FRIDGE MUST EMPLOY A SPECIAL POWER SOCKET INSTEAD OF COMMON ONE WITH OTHER ELECTRIC APPLIANCES. ITS PLUG MUST MATCH THE SOCKET WITH GROUND WIRE. DAILY USE DO NOT STORE FLAMMABLE GAS OR LIQUIDS IN THE APPLIANCE, THERE IS A RISK OF AN EXPLOSION. DO NOT OPERATE ANY ELECTRICAL APPLIANCES IN THE APPLIANCE (E.G.
  • Page 11 THE APPLIANCE IS INTENDED FOR KEEPING FOOD STUFF AND/ OR BEVERAGES IN NORMAL HOUSEHOLD AS EXPLAINED IN THIS INSTRUCTION BOOKLET. YOU SHOULD TAKE CARE WHEN MOVE IT AS THE APPLIANCE IS HEAVY. DO NOT REMOVE OR TOUCH ITEMS FROM THE FREEZER COMPARTMENT IF YOUR HANDS ARE DAMP/WET, AS THIS COULD CAUSE SKIN ABRASIONS OR FROST/FREEZER BURNS.
  • Page 12 INSTALLATION IMPORTANT! FOR ELECTRICAL CONNECTION CAREFULLY, FOLLOW THE INSTRUCTIONS GIVEN IN THIS MANUAL. UNPACK THE APPLIANCE AND CHECK IF THERE ARE DAMAGES ON IT. DO NOT CONNECT THE APPLIANCE IF IT IS DAMAGED. REPORT POSSIBLE DAMAGES IMMEDIATELY TO THE PLACE YOU BOUGHT IT.
  • Page 13 BEFORE CONNECTING THE REFRIGERATOR I FREEZER, MAKE SURE THAT THE MAINS VOLTAGE CORRESPONDS TO THE REQUIREMENTS FOR CONNECTING THE REFRIGERATOR / FREEZER. IF IN DOUBT, CONSULT A QUALIFIED ELECTRICIAN. THE APPLIANCE MUST BE CONNECTED TO A SOCKET WITH THE APPROPRIATE VOLTAGE AND A CORRECTLY INSTALLED FUSE SOCKET.
  • Page 14: Part 2: Overview

    PART 2: OVERVIEW Control panel Water/ ice dispenser (Remove away the metal compressor room cover) Main control board Power cord Compressor External main water valve EN - 12 Copyright © 2024, Fast ČR, a. s. Revision 01/2024...
  • Page 15 Ice box cover Ice storage box Fridge balcony *4 Fridge shelves *3 Freezer shelves *3 Freezer drawers *2 Fridge crispers *2 Freezer balcony *1 Water pipe connector This illustration is only for hinting, the detail please check your appliance. EN - 13 Copyright ©...
  • Page 16: Part 3: Installation

    PART 3: INSTALLATION Product accessories Water pipe connector*1 Water pipe parts * 1 Water filter * 1 Water filter connector*2 Anti-slip clips *8 Dispenser water tray * 1 User manual * 1 WARNING: Connect to potable water supply only Remove the doors Tool required: Philips screwdriver, Flat bladed screwdriver.
  • Page 17 2. Disconnect the harness. 3. Unscrew top hinge. 4 There is a water pipe connector at the bottom of the refrigerator freezer. Remove it from the protective cover and disconnect from the water pipe, and remember to pull the water pipe out of the lower hinge. 5.
  • Page 18: Space Requirement

    Space requirement Levelling the refrigerator Doors - Clockwise rotate feet to heighten them by hand. - Anticlockwise rotate feet to Iower them by hand. EN - 16 Copyright © 2024, Fast ČR, a. s. Revision 01/2024...
  • Page 19: Positioning

    Positioning Install this appliance at a location where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance: for refrigerating appliances with climate class: - extended temperate: this refrigerating appliance is intended to be used at ambient temperatures ranging from 10 °C to 32 °C;...
  • Page 20: Part 4: Daily Use

    PART 4: DAILY USE Important! How to install the water filter and water pipe 1. Before installing, the filter should be rinsing with water for 5 minutes or 5L of water to ensure that the toner in the filter is rinsed clean. Water source Connect tube Filter...
  • Page 21 4. Take out the water filter from the accessory bag, insert the connectors on both sides of the filter, then connect the water pipe and clamp into the anti-slip clips (pay attention to the direction of the filter arrow) Water filter Connectors Water pipes Anti-slip clips...
  • Page 22 Caution! working. and ice storage box. and the connecting pipe. If there is leakage, check the connection of the pipe. until the water is clean and smooth, during the process the water taken out is not drinkable. normal operation of the internal motor through the sound judgment. and water filter are leaking or not.
  • Page 23: Using The Control Panel

    Using the control panel Buttons Press to adjust temperature of freezer compartment (left side) from -14 °C to -22 °C. Press to adjust temperature of fridge compartment (right side) from 2 °C to 8 °C and "OFF". If select ”OFF” , Press to select running mode from SUPER COOLING , SUPER FREEZER , SMART...
  • Page 24: Display

    Display SMART mode, the refrigerator sets the temperature of two compartments automatically according to internal temperature and ambient temperature. ECO mode, the refrigerator runs in lowest energy consumption setting. SUPER COOLING cools the fridge compartment to the lowest temperature for approx. 2 hours. Then the temperature set before super mode is automatically restored.
  • Page 25: Child Safety Lock

    When any door is left open or not closed completely for about 60 seconds, the appliance will sound an alarm. Close the fridge door then the alarm will stop. If the door is not well closed, then the alarm will sound 5 times every 30 seconds until the doors are well closed.
  • Page 26: First Use

    First use Cleaning the interior Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand new product, then dry thoroughly. Important! Do not use detergents or abrasive powders, as these will damage the finish.
  • Page 27 Important! This section tells you how to avoid most issues you would happen. We recommend that you read through them carefully before using the appliance. When taking water for the first time or not taking water for a long time, please take out 1~2L of water and pour it away;...
  • Page 28 2) Clean the ice storage box regularly If the ice is not used for a long time or the freezer door is frequently opened, the ice in the ice storage box may melt and became frozen together, which makes the distributor outlet blocked. The ice in the ice storage box needs to be removed manually.
  • Page 29: Temperature Setting Recommendation

    Thawing Deep-frozen or frozen food, prior to be used, can be thawed in the freezer compartment or at room temperature, depending on the time available for this operation. Small pieces may even be cooked still frozen, directly from the freezer. In this case, cooking will take longer.
  • Page 30: Helpful Hints And Tips

    Daily use Refrigerator compartments Type of food Door or balconies of fridge compartment jams,juices, drinks, condiments. separately in the crisper bin. Crisper drawer (salad drawer) the refrigerator. Fridge shelf- middle Fridge shelf - top eat foods, deli meats, leftovers. Freezer drawer(s)/shelf baked goods.
  • Page 31 Hints for storage of frozen food To obtain the best performance from this appliance, you should: time; Hints for fresh food refrigeration To obtain the best performance: Hints for refrigeration Useful hints: polythene bags to exclude as much air as possible. Cleaning For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
  • Page 32: Part 5: Troubleshooting

    PART 5: TROUBLESHOOTING If you experience a problem with your appliance or are concerned that the appliance is not functioning properly, you could follow below tips to check the appliance before calling for service. Caution! Before troubleshooting, disconnect the power supply. Only a qualified electrician of competent person must do the troubleshooting that is not in this manual.
  • Page 33 Problem Possible cause Solution It’s normal. Heat exchange is in Take gloves to touch side panels Side panels are hot the side panels if need. Failing to access the water source Make sure the water source and or open the water valve the valve is open Dispenser couldn't get cooling Check whether the filter direction...
  • Page 34 Problem Possible cause Solution The pressure of water source is not Ensure the source water pressure enough is 1.5 ~ 7 bar The water filter is blocked, The cubed ice or water is too small because it has been used too long Replace a new water filter time Contact maintenance personnel...
  • Page 35: Part 6: Product Information Sheet

    Product Information Sheet COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating appliances Supplier's name or trademark: PHILCO Supplier's address: PHILCO, U Sanitasu 1621, 25101 Říčany, CZ Model identifier: PXISBSWI 513 ENW Type of refrigerating appliance: Low-noise appliance:...
  • Page 36 Cellar Fresh food 344.0 Chill 0-star or ice- making 1-star 2-star 3-star 4-star 169.0 12.0 2-star section Variable temperature compartment For 4-star compartments Fast freeze facility Light source parameters: Type of light source Energy efficiency class Minimum duration of the guarantee offered by the manufacturer: 24 months Additional information: Weblink to the manufacturer's website, where the information in point 4(a) Annex of Commission Regulation (EU) 2019/2019 is found: https://www.fastcr.cz...
  • Page 37: Technical Information

    When contacting our authorized service, have the model designation, serial number and defect description available. To download documents, visit www.philco.cz. To report a defect and obtain additional service information, visit https://philco.cz/podpora-a-servis. Subject to change without notice. EN - 35 Copyright © 2024, Fast ČR, a. s.
  • Page 38: Instructions And Information Regarding The Disposal Of Used Packaging Materials

    INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
  • Page 39 NOTES/POZNÁMKY/NOTATKI/MEGJEGYZÉS...
  • Page 40 Výrobce/Manufacturer: Fast ČR, a.s. U Sanitasu 1621 Říčany 251 01, CZECH REPUBLIC Distributor: FAST PLUS, a.s. Vlčie hrdlo 324/90 821 07 Bratislava, SLOVAKIA Distributor: FAST POLAND Sp. z o. o. Kwietniowa 36 05-090 Wypędy, POLAND Distributor: FAST HUNGARY Kft. H-2310 Szigetszentmiklós Kántor utca 10, HUNGARY is pending or registered trademark of Electrolux Home EN - 1...
