- Page 1 KeContact P40, P40 Pro MID Charging Station Manual for measuring point operators V 1.00 Translation of the original instructions...
- Page 2 Specifications are subject to change due to further technical developments. Details presented may be subject to correction. All rights reserved. Reindlstraße 51, 4040 Linz, Austria, www.keba.com/emobility KEBA Energy Automation GmbH +43 732 7090-0, +43 732 7309-10, kecontact@keba.com For information about KEBA and our subsidiaries please look at www.keba.com.
-
Page 3: Table Of Contents
Correctly reading the energy meter ..............Displays of calibratable energy meters ............Firmware update ....................Calibrating the device ....................Calibration mode....................Activating calibration mode ................Optical test output (pulse LED) ................ Schematic measurement setup ............... Maintenance....................... Index ........................... V1.00 © KEBA 2025... -
Page 4: Introduction
Introduction P40, P40 Pro MID Introduction This manual is valid for KeContact P40 variants with an installed MID meter (KC-P40-xxxxx- xxxxxMxx-…). The components shown in this manual are example graphics. The figures and explanations refer to typical product designs. The design of your product may differ. -
Page 5: Purpose Of The Document
Introduction Purpose of the document This document describes the relevant functions, properties and device-specific requirements for compliant operation of relevant KeContact P40 variants with an MID energy meter and is geared toward measuring point operators. Requirements This document contains information for persons who meet the following requirements:... -
Page 6: Description Of The Device
... KC-MS10 module ... Connector panel (interfaces) ... Application module The MID variants of KeContact P40 contain a KC-MS10 module, which is certified as an active power meter in accordance with the European Measuring Instruments Directive (MID) 2014/32/EU. The following chapters describe the KC-MS10 module as an MID device exclusively. -
Page 7: Description Of The Mid Device
The MID variants of KC-MS10 are certified as active power meters in accordance with the Eu- ropean Measuring Instruments Directive (MID) 2014/32/EU. Special markings on the KC-MS10 type plate allow for clear identification. The associated type examination refers to the KC-MS10. Fig. 2-1: Overview of KC-MS10 V1.00 © KEBA 2025... -
Page 8: Type Plate
... Electrical data of RDC (DC residual current ... Electrical data of RCD+RDC monitoring) ... Marking of the approval ... Portion of the type plate visible through the window in the outer housing ... CE mark V1.00 © KEBA 2025... -
Page 9: Manufacturer's Seal
The removal or destruction of one of the calibration seals indicates that inner parts of the KC-MS10 have been accessed and results in the loss of calibration validity. A gap effect makes tampering evident, as a checkerboard pattern is left behind when the label seal is removed. V1.00 © KEBA 2025... -
Page 10: Sealing (Charge Point Operator)
The lead seal, which can be selected by the operating company of the charging station, is ap- plied to the protective cover of the housing and is used to protect the installed measurement device from unwanted access. V1.00 © KEBA 2025... -
Page 11: Product Key (Overview Of Variants)
Maximum Charging Current ...32 A ...RCCB Type A + RDC-DD RCD functionality ...RDC-DD ...not equipped ...functional, not calibrated Metering ...MID (Measuring Instruments Directive) certified ...MessEV (Mess- und Eichverordnung) certified ...not equipped ...PLC communication Future options 0 ...none V1.00 © KEBA 2025... -
Page 12: Display For Energy Meters
Display for calibrated energy meters ... LCD display (two lines) Variants with an installed calibrated energy meter have an LCD display on the right side. This display shows the status of the energy meter and additional information. V1.00 © KEBA 2025... -
Page 13: Information On The Display
Relevant error on the KC-MS10, the module is out of operation. Oper- ation can only be restored by replacing the charging station or the Error KC-MS10 module. If an energy meter reading is displayed, this count value is correct despite the error. V1.00 © KEBA 2025... -
Page 14: Active Power Meters
The meter function is active in every operating mode in which energy is flowing through the device. If the KC-MS10 module is in the sleep state, the main relay is open, which prevents the transmission of energy. V1.00 © KEBA 2025... -
Page 15: Measurement Principle
... Power tap for internal supply: Before the ac- tive power meter ... Power measurement/active power meter ... Switching element ... Outlet for charging cable The switching element (4) refers to the additional function of the KC-MS10 and is not part of the meter function. V1.00 © KEBA 2025... -
Page 16: Operation Of The Kc-Ms10 As A Measuring Point
Outside of the sleep state, the relevant information is displayed permanently. For improved readability, the backlighting of the display is activated in case of relevant charge events. V1.00 © KEBA 2025... -
Page 17: Displays Of Calibratable Energy Meters
"2.8.1 Information on the display." Firmware update KeContact P40 supports updates to the legally relevant firmware. An update is triggered through the connected gateway (application module). Only firmware versions approved by the notified authority are installed on the device. Updates to the relevant firmware may require additional approval by the local authorities. -
Page 18: Calibrating The Device
For calibration mode, a specific test firmware is required as a software update; this can be provided by the manufacturer on request. To activate calibration mode, proceed as follows: ● Install the specific test firmware using the normal software update process. Calibration mode is activated. V1.00 © KEBA 2025... -
Page 19: Optical Test Output (Pulse Led)
P40, P40 Pro MID Calibrating the device Optical test output (pulse LED) ... Optical test output The optical test output is a pulse LED located behind the type plate, which is visible from the outside through a corresponding opening. V1.00 © KEBA 2025... -
Page 20: Schematic Measurement Setup
The test probes are connected to the output terminals on the output side. The optical test output must face the counterpart of the calibration test system. V1.00 © KEBA 2025... -
Page 21: Maintenance
P40, P40 Pro MID Maintenance Maintenance The KC-MS10 module is inherently maintenance free. However, periodically reading the meter is still recommended. In case of error, the KC-MS10 module must be replaced. V1.00 © KEBA 2025... -
Page 22: Index
Calibration mode ........ 18 Schematic measurement setup... 20 Seal ............ 9 Energy meter Type plate.......... 8 MID:Displays........ 13 Periodic checking........ 16 Firmware update ........ 17 Protective cover Lead seal.......... 10 Information on this document .... 5 Introduction.......... 4 Schematic diagram ........ 6 Type plates Position.......... 8 V1.00 © KEBA 2025... - Page 24 KEBA Energy Automation GmbH Reindlstraße 51 4040 Linz / Austria www.keba.com...
