Summary of Contents for FAAC 950N2
- Page 1 P a g e...
- Page 2 Use this template for the position of the mounting holes, both for the operator and the drive arm. If this is not available refer to the 950N2 installation manual pages 13 -16 for the mounting holes positions. (See table 1 below) Use appropriate fixings for the material that you are mounting the operator to.
- Page 3 STEP 5 Now perform a Setup on the 950N2 by holding SW1 on the I/O Board for 5 seconds -Hold the button until DL2 above starts flashing red repeatedly. Note that a SETUP can only be complete if the unit is set to the Automatic Mode (toggle switch on the side in the “0”...
- Page 4 Double Door Configuration – Primary /Secondary If you are installing the operators on a double door, you will need to enable the Primary /Secondary functionality of the 950N2. In order to do this, you will require the use of a KP EVO (Part Number: 790022) Note that the 950N2 can only be configured as Primary /Secondary with another 950N2 of the same firmware/software version.
- Page 5 STEP 3 Plug the KP EVO into the operator that you designate to be the Secondary (i.e. not receiving the opening commands). Using the KP EVO, go to Spanner, Programming and then into Intercom (see below) and perform the following configuration changes.
