- Page 1 HULALA ITEM NO.NSLS1236 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/28...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSONEN 03/28... -
Page 4: Parts List
PARTS LIST 1 04/28... - Page 5 PARTS LIST 2 05/28...
-
Page 6: Hardware List
HARDWARE LIST 8*30MM ∅15*12.5MM M6*50MM M6*30mm 8*1-1/2“ M8*50mm ∅ #8*5/8 TOOL LIST 06/28... - Page 7 HARDWARE SPARE LIST 8*30MM ∅15*12.5MM M6*50MM M6*30mm M8*50mm 8*1-1/2“ ∅ #8*5/8 07/28...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-1 Align the holes in part (F) with the holes in part (G), insert wood dowel #2 by hand, and tighten screw #5 with an Allen wrench #19. M6x50MM 8*30MM 08/28...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-2 Insert wood dowel #2 by hand, insert bolt #3 into the corresponding hole in the side plate (C&D), and tighten bolt #3 with a #18. screwdriver. C&D #3x4 #2x8 8*30MM 09/28...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-3 Insert the panels (G&F) into the side panels (C),make sure all holes aligned . 10/28...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-4 Insert the panels (H) into the side panels (C),make sure all holes aligned and insert cam bolt #4 into the corresponding hole of panel (H) ，tighten cam bolt #4 with screwdriver #18. Slide in the part (E) into the groove in part (C) . make sure they are also in groove in part (F).
- Page 12 ASSEMBLY INSTRUCTIONS STEP-5 Insert the panels (B) into the side panels (C&E),make sure all holes aligned and insert cam bolt #4 into the corresponding hole of panel (B) ，tighten cam bolt #4 with screwdriver #18. #4*2 ∅15*12.5MM 12/28...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-6 1. insert wood dowel #2 by hand into the corresponding hole in the panel (B&E&H&G) #2*4 8*30MM 13/28...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-7 1. Attach part D to the unit preassembled in step 6. Aligning the holes on the components. 2. Insert cam bolt #4 into the corresponding hole in the panel (B&E&H). Then, use a No. 18 screwdriver to tighten cam bolt #4. #4*2 #4*2 ∅15*12.5MM...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-8 1. Connect the leg frame to the cabinet.Align the hole in the leg frame part (Q) to the hole in the part (B&C&D),Insert gasket #16 into screw #5,tighten bolt #5 with allen key #19. 2. Connect the leg frame to the cabinet.Align the hole in the leg frame part (Q) to the hole in the part (B&C&D),tighten bolt #6 with allen key #19.
- Page 16 ASSEMBLY INSTRUCTIONS STEP-9 Insert gasket #8 and #9 in sequence into screw #7, install leg R on of bottom frame (Q), ensure the corresponding holes are aligned and fix with screw #7, then tighten the screw with an Allen key 17. #9x4 #7x4 #8x4...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-10 Insert wooden pin #2 to side panel (C&D&G) by hand.Connect socket #11 to part G using screw #10. and tighten it with screwdriver #18. #11x1 #10x2 #8*5/8 8*30MM 17/28...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-11 Insert bolt #3 into the corresponding hole of top panel (A),tighten bolt #3 with screwdriver #18. #3x6 18/28...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-12 Insert top panel (A) into the preassemble unit at step 11，make sure all holes aligned，and then insert cam bolt #4 into the corresponding hole of side panel (C)&(D)&(G)，tighten cam bolt #4 with screwdriver #18. #4x6 C&D&G C&D&G #4x6 ∅15*12.5MM 19/28...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-13 Attach the rear panel (E) to the front panel (F), side panels (D)&(C) and base panel (B) using screw #10 and plastic part #14, tighten screw #14 with screwdriver #18. Use wire cover #15 to with part G align the hole in the wire cover. 20/28...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-14 1.Use screw #12 to attach drawer side(K)&(L)to drawer back (J),tighten screw #12 with screwdriver#18 ,and slide in the part (M) into the groove in part (K)&(L) . make sure they are also in groove in part (J). 2.Use screw #12 to attach drawer side(N)&(O)to drawer back (J),tighten screw #12 with screwdriver# 18 ,and slide in the part (P) into the groove in part (N)&(O).
- Page 22 ASSEMBLY INSTRUCTIONS STEP-15 ， Insert drawer front (I) into preassemble step 14 make sure all holes aligned and insert screw into the corresponding hole of drawer side panel(K)&(L)&(N)&(O) tighten screw #12 with screwdriver #18. 8*1-1/2“ ∅ 22/28...
- Page 23 ASSEMBLY INSTRUCTIONS STEP-16 Use bolt #1 to attach handle #1 to drawer front(I)，tighten bolts #1 with screwdriver #18. 23/28...
- Page 24 ASSEMBLY INSTRUCTIONS Attention ： When installing the drawer , slide the steel ball slide rail of side panel to the most front as picture show . 24/28...
- Page 25 ASSEMBLY INSTRUCTIONS ① ② STEP-17 Use screw ② to attach bracket ① to top panel (A),tighten screw ② with screwdriver #18. ① ② ② ②x4 25/28...
- Page 26 ASSEMBLY INSTRUCTIONS ① ③ ④ STEP-18 1. Mark the position on the wall, that corresponds to the location of ① ④ bracket on the panel A; Drill and insert the expandable screw hammer. ① ① 2. Assemble the bracket to the wall. Align the hole in the bracket ④...
- Page 27 ASSEMBLY INSTRUCTIONS ⑤ STEP-19 ⑤ ① 3. Let the plastic belt pass through bracket and pull tightly. ⑤x2 ①x2 ⑤x2 ①x2 27/28...
-
Page 28: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
