ITEM NO.NSYL0857
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/22

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSYL0857 and is the answer not in the manual?

Questions and answers

Summary of Contents for HULALA HOME NSYL0857

  • Page 1 HULALA ITEM NO.NSYL0857 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/22...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONENS 03/22...
  • Page 4: Parts List

    PARTS LIST 1 04/22...
  • Page 5 PARTS LIST 2 05/22...
  • Page 6: Hardware List

    HARDWARE LIST Ø3*15MM Ø4*15MM Ø4*25MM Ø3*12MM Ø6*22MM Ø6*45MM TOOL LIST HARDWARE SPARE LIST Ø3*15MM Ø6*22MM Ø6*45MM Ø4*25MM 06/22...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-1 1.Combine part I and part J, making sure their grooves face each other. 2.Attach the assembled parts (J&I) to the bottom panel B with bolt #7, ensure the corresponding holes are aligned. Ø6*45MM 07/22...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-2 make sure all holes aligned and use 1.Insert part (E) into part (F), screw#4 to attach them ,tighten screw #4 with screwdriver 2.Insert side panel (C&D) into panel (E&F),make sure all holes aligned as picture show. Ø4*25MM 08/22...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert preassembled step 2 into the corresponding hole of bottom panel (B) , make sure all holes aligned and use Bolt#8 to attach them tighten bolt#8 with Allen Key & Ø6*22MM 09/22...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-4 1.insert back panel(H) into the groove of preassembled step 3,make sure all holes aligned and use screw#1 to attach them , tighten screw #6 with screwdriver#10. Ø3*15MM 10/22...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-5 1.insert part (G)into the preassembled step 4 make sure all holes aligned and use screw #4 to attach them , tighten screw #4 with screwdriver#10. Ø4*25MM 11/22...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-6 insert part #5 into the preassembled step 5,make sure all holes aligned and use screw#2 to attach them ,tighten screw #2 with screwdriver Ø3*12MM 12/22...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert top panel (A) into the corresponding hole of preassembled step 6 , make sure all holes aligned and use Bolt#8 to attach them tighten bolt#8 with Allen Key & Ø6*22MM 13/22...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-8 Attention: Before the next step, adjust the feet of the locker to keep it level. 14/22...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-9 1.Connect part (M&L) to part K using screw #4 and tighten it with screwdriver #10.Slide in the part (N) into the groove in part (L&M). make sure they are also in groove in part (K). & Ø4*25MM 15/22...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect the (O) connection (L&M) using screw #4 , and tighten it with screwdriver #10. & Ø4*25MM 16/22...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect part (Q&R) to part P using screw #4 and tighten it with screwdriver #10.Slide in the part (S) into the groove in part (Q&R). make sure they are also in groove in part (P). & Ø4*25MM 17/22...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Connect the (T) connection (Q&R) using screw #4 , and tighten it with screwdriver #10. Use screw #1 to fix handle #3 to part T, and tighten it with screwdriver #10. & Ø4*15MM Ø4*25MM 18/22...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-13 Attention : When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 19/22...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-14 Attention : When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 20/22...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-15 Assembly completed 。 21/22...
  • Page 22: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
