- Page 1 HULALA ITEM NO.NSSD0842 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/24...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 3/24... -
Page 4: Parts List
PARTS LIST 2PEOPLE 4/24... -
Page 5: Hardware List
HARDWARE LIST Ø15mm M7*50mm Ø3.5*14mm M6*35mm Ø8*30mm M6*35mm M6*50mm ∅ 4*35mm 比例 25.400 Ø13*Ø6.5*1 TOOL LIST HARDWARE SPARE LIST M6*40mm M7*50mm Ø3.5*14mm M6*35mm ∅ 4*35mm M6*50mm 5/24... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Insert bolt #1 into the corresponding hole of drawer front(I), tighten bolt #1 with screwdriver #19. M6*35mm 6/24...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 Use bolt #7 to attach drawer side (K) ＆（ J ） to drawer back (N),tighten bolt # 7 with screwdriver #19 ， and slide in the part O into the groove in part J,K . make sure they are also in groove in part N.
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 Insert drawer front (I) into preassemble step 2 ， make sure all holes aligned and insert cam bolt #2 into the corresponding hole of drawer side panel K&J&L&M， tighten cam bolt #2 with screwdriver #19. after installation, cover the screw holes with #14.
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 Use bolt #15 to attach handle #10 to drawer front （ I ）， tighten bolts #15 with screwdriver #19. #15x4 #10x2 9/24...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Align the holes of the G part with the holes of the F part, insert the screw #7 , and tighten the screw #7 with the screwdriver #19 . and insert wooden dowel #4 by hand. Ø8*30mm ∅...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-6 Insert bolt #1 into the corresponding hole of side panel(C&D), tighten bolt #1 with screwdriver #19. & & M6*35mm 11/24...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Insert the parts (G&F&E) into the side panels (C&D),make sure all holes aligned and insert cam bolt #2 into the corresponding hole of panel （ E&F&G ）， tighten cam bolt #2 with screwdriver #19. after installation, cover the screw holes with #14.
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 slide in the part (H) into the groove in part (C&D) . make sure they are also in groove in part G.And insert wooden pin #4 to side panel C&D by hand. Ø8*30mm 13/24...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Then align the holes in part B,Insert screw #3 and push it down so that it connects to parts (C&D&H). Next,and tighten the screw #3 with an Allen key #20 . & M7*50mm 14/24...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 Prepare the leg racks. Align the holes of the Q part with the holes of the R part, insert the screw #11, and tighten the screw #11 with the allen key #20 . #11x2 M6*35mm 15/24...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-11 Insert gasket #13 into bolt #12 ,connect the leg frame to the cabinet.Attach the leg frame to the pre-assembled unit in step 9 with a screw #12 and tighten #12 with a allen key #20 . #12x6 &...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-12 100% & 17/24...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Insert wooden pin #4 to side panel (C&D&F) by hand.Connect socket #17 to part G using screw #5. and tighten it with screwdriver #19. Ø8*30mm Ø3.5*14mm 18/24...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-14 Insert bolt #1 into the corresponding hole of top panel (A), tighten bolt #1 with screwdriver #19. #1x5 M6*35mm 19/24...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Insert the top panel (A) into the side panels (C&D&F),make sure all holes aligned and insert cam bolt #2 into the corresponding hole of panel （ C&D&F ）， tighten cam bolt #2 with screwdriver #19. after installation, cover the screw holes with #14. &...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-16 Use screw #5 to attach plastic bracket #16 to panel (A),make sure all holes aligned and tighten screw #5 with screwdriver Insert hardware #6 into part H as shown, screw in screw #5 using screwdriver #19 and tighten fully. Ø3.5*14mm 21/24...
- Page 22 ASSEMBLY INSTRUCTIONS STEP-17 Slide rail adjustment legend !!! 22/24...
- Page 23 ASSEMBLY INSTRUCTIONS STEP-18 Mark the position on the wall, that corresponds PROVIDED to the location of part #16 on the top panel A; Drill and insert the expandable screw #9 by hammer. Assemble the part #16 to the wall. Align the hole in the part #16 with the expandable screw #9 , use screw #7 to attach it and tighten by screwdriver 19 .
-
Page 24: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
