- Page 1 HULALA ITEM NO.NSCS1183D NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/20...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes. Do not use detergents, solvents, abrasives, spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water).
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSONENS 03/20... -
Page 4: Parts List
PARTS LIST 1 04/20... -
Page 5: Hardware List
HARDWARE LIST Ø3*15MM 5/32*25MM Ø4*25MM Ø3*15MM Ø8*25MM Ø4*38MM Ø3*20MM TOOL LIST Not including HARDWARE SPARE LIST Ø3*15MM Ø8*25MM Ø3*15MM Ø4*25MM 05/20... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Insert panel (B&F) into side panel (C&D), make sure all holes aligned and then pull panel (B&F) forward fix with as picture show. 06/20...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert part (E) into part (F), make sure all holes align aligned, wood dowel #7 and fix, with screw #5 then tighten the screw with an screwdriver #13. Not including Ø4*25MM Ø8*25MM 07/20...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert part (G) into the preassembled step 2, make sure all holes aligned and use screw #5 to attach them , tighten screw #5 with screwdriver #13. Not including Ø4*25MM 08/20...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert part #4 into the preassembled step 3, make sure all holes aligned and use screw #3 to attach them,tighten screw #3 with screwdriver #13. #3x2 Not including Ø3*15MM 09/20...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 1.Insert back panel (H) into the groove of preassembled step 4 back, make sure all holes aligned and use screw #6 to attach them , tighten screw #6 with screwdriver #13. Ø3*15MM Not including 10/20...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.Insert panel (C&D) into side panel (A), make sure all holes aligned and then pull panel (A) back fix with as picture show. 11/20...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 1.Connect part (J&K) to part (I) using screw #5 and tighten it with screwdriver #13. 2.Slide in the part (L) into the groove in part (J&K). Make sure they are also in groove in part (I). Not including Ø4*25MM 12/20...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1.Connect the (M) and (J&K) using screw #5, and tighten it with screwdriver #13. 2.Install handle #2 to panel (M) using bolt #1 and tighten it with screwdriver #13. J&K Not including 5/32*25MM Ø4*25MM 13/20...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 1.Connect part (O&P) to part (N) using screw #5 and tighten it with screwdriver #13. 2.Slide in the part (Q) into the groove in part (O&P). Make sure they are also in groove in part (N). Not including Ø4*25MM 14/20...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect the (R) and (O&P) using screw #5, and tighten it with screwdriver #13. O&P Not including Ø4*25MM 15/20...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-11 Attention ： When installing the drawer, slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 16/20...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Use screw #12 to attach plastic bracket #9 to panel (A), make sure all holes aligned and tighten screw #12 with screwdriver #13. Not including Ø3*20MM 17/20...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Not including Ø4*38MM 1. Mark the position on the wall, that corresponds to the location of bracket #9 on the panel A. Drill and insert the expandable screw #8 by hammer. 2. Assemble the bracket #9 to the wall. Align the hole in the bracket #9 with the expandable screw #8 , use screw #11 to attach it , tighten screw #11 with screwdriver #13.
- Page 19 ASSEMBLY INSTRUCTIONS STEP-14 3.Let the plastic belt #10 pass through bracket #9 and pull tightly. 19/20...
-
Page 20: Warranty
WARRANTY 1.We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 25 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive.
