HULALA HOME NSCS1184D Manual

Hide thumbs

Advertisement

Table of Contents

HULALA
H
O
M
E
ITEM NO.NSCS1184D
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NSCS1184D and is the answer not in the manual?

Questions and answers

Related Manuals for HULALA HOME NSCS1184D

Summary of Contents for HULALA HOME NSCS1184D

  • Page 1 HULALA ITEM NO.NSCS1184D NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/22...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes. Do not use detergents, solvents, abrasives, spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water).

  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONENS 03/22...

  • Page 4: Parts List

    PARTS LIST 1 04/22...
  • Page 5 PARTS LIST 1 05/22...

  • Page 6: Hardware List

    HARDWARE LIST Ø3*15MM 5/32*30MM Ø4*25MM Ø3*15MM 1/4*35MM Ø8*30MM Ø12*1MM Ø19*1MM Ø4*38MM Ø3*20MM TOOL LIST Not including HARDWARE SPARE LIST Ø3*15MM 1/4*35MM Ø4*25MM Ø8*30MM Ø12*1MM Ø19*1MM Ø3*15MM 06/22...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-1 1.Insert part (J&K) into part (H&I), make sure all holes align aligned, wood dowel #7 and fix, using screw #5 and tighten it with screwdriver #17. Not including Ø8*30MM Ø4*25MM 07/22...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert bolt (8), spring washer (9), flat washer (10) into the preassembled step 1, make sure all holes aligned then tighten the screw with an Allen key #16. 1/4*35MM Ø12*1MM Ø19*1MM 08/22...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert part (B) into part (H&I), make sure all holes align aligned, wood dowel #7 and using bolt (8), spring washer (9), flat washer (10) then tighten the screw with an Allen key #16. Ø8*30MM 1/4*35MM Ø12*1MM Ø19*1MM 09/22...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert part (A&B&E&F) into part (C&D), make sure all holes align aligned, wood dowel #7 and using bolt (8), spring washer (9), flat washer (10) then tighten the screw with an Allen key #16. Ø8*30MM 1/4*35MM Ø12*1MM Ø19*1MM 10/22...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-5 1.Into the preassembled step 4 make sure all holes aligned and then pull panel (E) forward fix with as picture show. 11/22...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-6 1.Insert back panel (G) into the groove of preassembled step 5 back, make sure all holes aligned and use screw #6 to attach them,tighten screw #6 with screwdriver #17. Ø3*15MM Not including 12/22...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert part #4 into the preassembled step 6, make sure all holes aligned and use screw #3 to attach them,tighten screw #3 with screwdriver #17. Not including Ø3*15MM 13/22...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-8 1.Connect part (M&N) to part (L) using screw #5 and tighten it with screwdriver #17. 2.Slide in the part (O) into the groove in part (M&N). Make sure they are also in groove in part (L). Not including Ø4*25MM 14/22...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-9 1.Connect the (P) and (M&N) using screw #5, and tighten it with screwdriver #17. 2.Install handle #2 to panel (P) using bolt #1 and tighten it with screwdriver #17. M&N Not including 5/32*30MM Ø4*25MM 15/22...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (R&S) to part (Q) using screw #5 and tighten it with screwdriver #17. 2.Slide in the part (T) into the groove in part (R&S). Make sure they are also in groove in part (Q). Not including Ø4*25MM 16/22...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect the (U) and (R&S) using screw #5, and tighten it with screwdriver #17. R&S Not including Ø4*25MM 17/22...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-12 Attention ： When installing the drawer, slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 18/22...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-13 Use screw #15 to attach plastic bracket #12 to panel (A), make sure all holes aligned and tighten screw #15 with screwdriver #17. Not including Ø3*20MM 19/22...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-14 Not including Ø4*38MM 1. Mark the position on the wall, that corresponds to the location of bracket #12 on the panel A. Drill and insert the expandable screw #11 by hammer. 2. Assemble the bracket #12 to the wall. Align the hole in the bracket #12 with the expandable screw #11 , use screw #14 to attach it , tighten screw #14 with screwdriver #17.
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-15 3.Let the plastic belt #13 pass through bracket #12 and pull tightly. 21/22...

  • Page 22: Warranty

    WARRANTY 1.We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive.
