- Page 1 HULALA ITEM NO.NSHM0832 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/21...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSONEN 03/21... -
Page 4: Parts List
PARTS LIST 04/21... - Page 5 PARTS LIST 05/21...
-
Page 6: Hardware List
HARDWARE LIST 1/4"*1-3/4" 8#*1" 3*14mm 1/4" 1/4" ∅ ∅ ∅ ∅ ∅ 3*12mm ∅ 8#*1" ∅ TOOL LIST HARDWARE SPARE LIST 3*14mm 06/21 ∅... - Page 7 ASSEMBLY INSTRUCTIONS STEP-1 1.Insert part (G) into part (F),make sure all holes align . 2.1.Insert panel (F&G&E) into side panel (D),make sure all holes aligned and then tighten it with allen key #9 as picture show. & 07/21...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert side panel (C) into the corresponding hole of preassembled step 1，make sure all holes aligned and use allen key #9 to tighten it as picture show. & 08/21...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert gasket #3 and #2 in sequence into bolt #4, install leg (T) on of bottom panel (B), ensure the corresponding holes are aligned and fix with bolt #4, then tighten the bolt with an Allen key #9. 1/4"...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert preassembled step 2 into the corresponding hole of bottom panel (B)，make sure all holes aligned and use allen key #9 to tighten it as picture show. 10/21...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-5 insert back panel (I) into the groove of preassembled step 4,make sure all holes aligned and use screw #1 to attach them ，tighten screw #1 with screwdriver 3*14mm ∅ 11/21...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-6 insert part (H) into the preassembled step 5,make sure all holes aligned and use screw #5 to attach them ，tighten screw #5 with screwdriver 8#*1" ∅ 12/21...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-7 insert part #8 into the preassembled step 6,make sure all holes aligned and use screw #6 to attach them ，tighten screw #6 with screwdriver 3*12mm ∅ 13/21...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-8 1.Insert top panel (A) into the corresponding hole of preassembled step 7，make sure all holes aligned and use allen key #9 to tighten it as picture show. 14/21...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-9 Attention: Before the next step, adjust the feet of the locker to keep it level. 15/21...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (O&P) to part (Q) using screw #7 and tighten it with screwdriver #10.Slide in the part (S) into the groove in part (O&P). make sure they are also in groove in part (Q). 8#*1" ∅ 16/21...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect part (J&K) to part (L) using screw #7 and tighten it with screwdriver #10.Slide in the part (N) into the groove in part (J&K). make sure they are also in groove in part (L). 8#*1" ∅ 17/21...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Connect the (M) connection (J&K) using screw #7 , and tighten it with screwdriver #10. 2.Connect the (R) connection (O&P) using screw #7 , and tighten it with screwdriver #10. J&K O&P 8#*1" ∅ 18/21...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-13 Attach drawer to preassemble unit at step 12. Attention ： When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 19/21...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-14 Assembly completed. 20/21...
-
Page 21: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
