  • Page 1 HULALA ITEM NO.NSHM0852 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/26...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1: 10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.

  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN 03/26...

  • Page 4: Parts List

    PARTS LIST 04/26...
  • Page 5 PARTS LIST 05/26...

  • Page 6: Hardware List

    HARDWARE LIST 1/4"*1-1/2" 8#*1" 3*14mm ∅ ∅ ∅ 3*12mm ∅ 3.5*35mm*7# 5/32"*1" ∅ ∅ 3.5*14mm*7# ∅ TOOL LIST HARDWARE SPARE LIST 3.5*14mm*7# ∅ 06/26...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-1 Insert part (G) into part (F),make sure all holes align Insert panel (F ＆ G) into panel (D),make sure all holes aligned and then tighten it with allen key #14 as picture show. 07/26...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-2 Insert panel (B) into panel (D&F),make sure all holes aligned and then tighten it with allen key #14 as picture show. 08/26...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-3 Insert panel (H) into panel (D),make sure all holes aligned and then tighten it with allen key #14 as picture show. 09/26...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-4 Insert panel (C) into panel (D),make sure all holes aligned and then tighten it with allen key #14 as picture show. 10/26...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-5 1.Insert side panel (E) into the corresponding hole of preassembled step 4 ，make sure all holes aligned and use allen key #14 to tighten it as picture show. 11/26...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-6 insert back panel(I) into the groove of preassembled step 5,make sure all holes aligned and use screw#1 to attach them ，tighten screw #1 with screwdriver 3*14mm ∅ 12/26...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert gasket #3 into screw #2,.Connect panel (A) to preassembled step 6 using bolt #2 and tighten it with Allen key #14. & 1/4"*1-1/2" ∅ 13/26...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-8 insert part (J) into the preassembled step 7,make sure all holes aligned and use screw#5 to attach them ，tighten screw #5 with #15. screwdriver 8#*1" ∅ 14/26...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-9 insert part #6 into the preassembled step 8,make sure all holes aligned and use screw #4 to attach them ，tighten screw #4with screwdriver 3*12mm ∅ 15/26...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-10 Attention: Before the next step, adjust the feet of the locker to keep it level. 16/26...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect part (L&M) to part K using screw #5 and tighten it with screwdriver #15.s lide in the part (N) into the groove in part (L&M). make sure they are also in groove in part (K). 8#*1" ∅...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-12 and tighten it with Connect the (R) and (L&M) using screw #5 , screwdriver #15. 2.Install handle #7 to panel (R) using bolt #8 and tighten it with screwdriver #15. & 8#*1" 5/32"*1" ∅ ∅ 18/26...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-13 Att�hen installing the drawer.slide the steel ball slide「ail of side panel to the most front as picture show. 一 －－ ＼ ＼ ＼ Male sliaer \ ~ － / Schematic diagram of slide rail disassembly ／ 19/26...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-14 1.Connect part (O&P) to part K using screw #5 and tighten it with screwdriver #15.s lide in the part (Q) into the groove in part (O&P). make sure they are also in groove in part (K). 8#*1" ∅...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-15 and tighten it with Connect the (R) and (O&P) using screw #5 , screwdriver #15. 2.Install handle #7 to panel (R) using bolt #8 and tighten it with screwdriver #15. & 8#*1" 5/32"*1" ∅ ∅ 21/26...
  • Page 22 ASSEMBLY INSTRUCTIONS STEP-16 Att�hen installing the drawer.slide the steel ball slide「ail of side panel to the most front as picture show. 一 －－ ＼ ＼ ＼ Male sliaer \ ~ － / Schematic diagram of slide rail disassembly ／ ／ 22/26...
  • Page 23 ASSEMBLY INSTRUCTIONS STEP-17 Use screw #13 to attach plastic bracket #9 to panel (A),make sure all holes aligned and tighten screw #1 with screwdriver #15 3.5*14mm*7# ∅ 23/26...
  • Page 24 ASSEMBLY INSTRUCTIONS 3.5*35mm*7# ∅ STEP-18 1. Mark the position on the wall, that corresponds to the location of bracket on the panel A; Drill and insert the expandable screw by hammer. 2. Assemble the bracket to the wall. Align the hole in the bracket with the expandable screw ,use screw to attach it...
  • Page 25 ASSEMBLY INSTRUCTIONS STEP-19 3. Let the plastic belt pass through bracket and pull tightly. 25/26...

  • Page 26: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
