ITEM NO.NSJY0539
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/21

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSJY0539 and is the answer not in the manual?

Questions and answers

Summary of Contents for HULALA HOME NSJY0539

  • Page 1 HULALA ITEM NO.NSJY0539 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/21...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes. Do not use detergents, solvents, abrasives, spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water).
  • Page 3 EXPLOSIVE VIEW 2PERSONENS Around 03/21...
  • Page 4 PARTS LIST 1 04/21...
  • Page 5 HARDWARE LIST Ø3*15MM Ø4*22MM Ø4*25MM Ø3*12MM Ø6*40MM Ø8*30MM Ø4*38MM Ø3*20MM TOOL LIST Not including HARDWARE SPARE LIST Ø3*15MM Ø6*40MM Ø8*30MM Ø4*25MM 05/21...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Install leg (J) on of bottom panel (B), ensure the corresponding holes are aligned and fix with, wood dowel #8, screw #7, then tighten the screw with an Allen key #14. Ø6*40MM Ø8*30MM 06/21...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert panel (E&G) into side panel (C&D), make sure all holes aligned and then pull panel (E&G) forward fix with as picture show. 07/21...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert part (F) into part (E), make sure all holes align aligned, wood dowel #8 and fix, with screw #4 then tighten the screw with screwdriver #15. Not including Ø4*25MM Ø8*30MM 08/21...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert panel (C&D) into side panel (B), make sure all holes aligned and then pull panel (C&D) forward fix with as picture show. 09/21...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 1.Insert part (H) into the preassembled step 6, make sure all holes aligned and use screw #4 to attach them , tighten screw #4 with screwdriver #15. Not including Ø4*25MM 10/21...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.Insert part #5 into the preassembled step 7, make sure all holes aligned and use screw #2 to attach them , tighten screw #2 with screwdriver #15. #2x2 Not including Ø3*12MM 11/21...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert panel (C&D) into side panel (A), make sure all holes aligned and then pull panel (A) back fix with as picture show. 12/21...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1.Insert back panel (I) into the groove of preassembled step 5 back, make sure all holes aligned and use screw #6 to attach them , tighten screw #6 with screwdriver #15. Ø3*15MM Not including 13/21...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Attention: Before the next step, adjust the feet of the locker to keep it level. 14/21...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (L&M) to part K using screw #4 and tighten it with screwdriver #15. 2.Slide in the part (N) into the groove in part (L&M). Make sure they are also in groove in part (K). Not including Ø4*25MM 15/21...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-11 1.Connect the (O) and (L&M) using screw #4, and tighten it with screwdriver #15. 2.Install handle #3 to panel (O) using bolt #1 and tighten it with screwdriver #15. L&M Not including Ø4*22MM Ø4*25MM 16/21...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Attention : When installing the drawer, slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 17/21...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Use screw #12 to attach plastic bracket #10 to panel (A), make sure all holes aligned and tighten screw #13 with screwdriver Not including Ø3*20MM 18/21...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-14 Not including Ø4*38MM 1. Mark the position on the wall, that corresponds to the location of bracket #9 on the panel A. Drill and insert the expandable screw #8 by hammer. 2. Assemble the bracket #9 to the wall. Align the hole in the bracket #9 with the expandable screw #8 , use screw #11 to attach it , tighten screw #11 with screwdriver #15.
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-15 3.Let the plastic belt #11 pass through bracket #10 and pull tightly. 20/21...
  • Page 21 WARRANTY 1.We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive.
