BAYLON CEILING FAN
1
ITEM #5709385
MODEL #BAY52MBKB3R
BAY60MBKB3R
Español p. 18
ATTACH YOUR RECEIPT HERE
4007498
APPROVED FOR
USE IN DAMP
LOCATIONS
5709393

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAYLON BAY52MBKB3R and is the answer not in the manual?

Questions and answers

Related Manuals for Harbor Breeze BAYLON BAY52MBKB3R

Summary of Contents for Harbor Breeze BAYLON BAY52MBKB3R

  • Page 1 ITEM #5709385 5709393 MODEL #BAY52MBKB3R BAY60MBKB3R BAYLON CEILING FAN Español p. 18 ATTACH YOUR RECEIPT HERE 4007498 APPROVED FOR USE IN DAMP Purchase Date LOCATIONS Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 800-527-1292, 8:30 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information ............................. 2 Package Contents ............................. 5 Hardware Contents ..............................6 Preparation ............................... 6 Initial Installation ............................6 Wiring ..............................11 Final Installation ............................12 Operating Instructions ..........................13 Care and Maintenance ..........................15 Troubleshooting ............................16 Limited Lifetime Warranty ........................
  • Page 3 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS Please read and understand this entire manual before attempting to assemble, install or operate the product. Review the accompanying assembly diagrams. • Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for repairs, it must be shipped in its original packaging to ensure proper protection against damage that might exceed the initial cause for return.
  • Page 4 SAFETY INFORMATION WARNING To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed control device or control fan speed with a full range dimmer switch. To reduce the risk of fire, electrical shock or personal injury, do not bend the blade arms when installing them, balancing the blades or cleaning the fan.

  • Page 5: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Blade Plate Downrod Canopy Cover Mounting Bracket Metal Cover Canopy Yoke Cover Motor Housing IMPORTANT REMINDER: You must use the Blade parts provided with this fan for proper installation Pin (preassembled) and safety. Clip (preassembled) Canopy Mounting Screw (preassembled)

  • Page 6: Hardware Contents

    HARDWARE CONTENTS (shown actual size) Wire Blade Screw/ Connector Lock Washer Qty. 3 Qty. 6 +1 extra PREPARATION Before beginning assembly of product, make sure all parts are present. Place motor on carpet or on foam to avoid damage to finish. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
  • Page 7 INITIAL INSTALLATION If applicable, remove existing fan including the mounting bracket, from outlet box and disconnect all electrical wiring. WARNING: To reduce the risk of personal injury, use ONLY parts provided with your new fan. The use of parts OTHER than those provided with this fan will void the warranty.
  • Page 8 INITIAL INSTALLATION Remove all three preassembled motor stabilization pieces from motor housing (E). The motor stabilization pieces may be discarded at this time. Motor Stabilization Piece Secure mounting bracket (B) to outlet box (not ANGLE STANDARD included) using screws, spring washers and flat MOUNT MOUNT washers provided with the outlet box.
  • Page 9 INITIAL INSTALLATION Remove pin (G) and clip (H) from downrod (A). Partially loosen preassembled set screws and nut in yoke at top of motor housing (E). Set Screw & Nut Yoke Insert downrod (A) through canopy (C), canopy cover (M) and yoke cover (D). NOTE: Canopy cover (M) must be turned with the smooth side toward the motor housing (E).
  • Page 10 INITIAL INSTALLATION Depending on the length of downrod you use, you may need to cut the lead wires back to 8 in. simplify the wiring. If you decide to cut back the lead wires, it is suggested you do so in the Hanging following manner: Ball...

  • Page 11: Wiring

    WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12-gauge or there is more than one house wire to connect to the corresponding fan lead wires, consult an electrician for the proper size wire connectors to use.

  • Page 12: Final Installation

    WIRING Wrap electrical tape (not included) around each individual wire connector down to the wire. WARNING: Make sure no bare wire or wire strands are visible after making connections. Place GREEN and WHITE connections on opposite side of the outlet box from the BLACK and BLUE (if applicable) connections.
  • Page 13 FINAL INSTALLATION DANGER: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades (F). If overtightened, blades (F) may crack and break. Place one blade plate (L) under blade (F), aligning holes. Insert two blade screws/lock washers (BB) into holes of the blade (F), until the blade screw/lock washer (BB) comes through the other side of the blade (F).

  • Page 14: Operating Instructions

    OPERATING INSTRUCTIONS CAUTION: The remote control transmitter can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. FCC Compliance Notice for Remote Control CAUTION: Changes or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 15: Care And Maintenance

    OPERATING INSTRUCTIONS 2. Restore electrical power. IMPORTANT: To prevent damage to remote control transmitter, remove the battery if not used for long periods. Store the remote control transmitter away from excess heat or humidity. NOTE: If fan and/or remote control fail(s) to operate or you have purchased a new remote control transmitter, make sure to turn the power off first.

  • Page 16: Troubleshooting

    TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Fan does not move. 1. Power is off or fuse is blown. 1. Turn power on or check fuse. 2. Faulty wire connection. 2.

  • Page 17: Limited Lifetime Warranty

    LIMITED LIFETIME WARRANTY Set forth below, the manufacturer warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also, subject to the limitations below, the manufacturer warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year after the date of purchase by the original purchaser at retail.
