- Page 1 PAC600T PAC600T • Use and maintenance manual ..• Mode d’emploi et d’entretien ..• Instrucciones de uso ..• Manual de instruções ..pag.
-
Page 2: Save These Instructions
As with any electrical appliance, whilst the instructions aim to cover as many eventualities as possible caution and common sense should be applied when operating and installing this air conditioner. • This appliance has been manufactured to cool and de-humidify domestic environments and should not be used for other purposes. - Page 3 75°F (24 °C) and 50% relative humidity. An air conditioner removes moisture and heat from the room where it is located. One advantage of portable air conditioning units over fitted models is that they can be moved from one room to another in the home or even transferred between different buildings.
- Page 4 Insert the nozzle of the exhaust hose into the slot, then connect the hose to the air conditioner (Fig. D).Thanks to the wing nut, it’s possible to use the window bracket also for sliding windows. Position the hole of the bracket so to allow a correct installation of the exhaust hose.
- Page 5 S e t t i n g u p AIR CONDITIONING WITH INSTALLATION For more efficient use Pinguino can also be semi-permanently installed 12" 30 cm 12" 30 cm To install, proceed as follows: • Make a hole in a outside wall or through the glass of a window.
- Page 6 These air conditioners can use both air and water to cool the condenser (the hot part) of the air conditioner. To utilise the full potential of your air conditioner, the tank is used to increase the cooling power and reduce the noise level and energy consumption of the air conditioner.
- Page 7 Turning on and setting the timer ELECTRICAL CONNECTION Before plugging in check that: • the mains supply corresponds to the power supply shown on the rating plate; • the socket and the mains lead correspond to the power requirements of the applian- •...
- Page 8 (never towards the air conditioner) and eliminate the siphon on the hose. 2) The exhaust hose is obstructed: eliminate the obstacles which obstruct the expulsion of the air to the outside.
- Page 9 Remove the purification filter from its packaging. Anchor the filter to the appliance by atta- ching the two plastic pieces on the filter to the special supports on the air conditioner (see the illustration below). Set the dust filter aside.
- Page 10 • open the front panel tank • remove the bung from the drainage hose which can be found at the back the air conditioner and empty out the water to a container. • after draining off the water, replace the drainage hose plug.
- Page 11 (fig. L), on the bottom of the appliance. 3) Operate the air conditioner for about half an hour. 4) After this, drain out all of the liquid remai- ning in the collection reservoir and rinse thoroughly (fig.
-
Page 12: Troubleshooting
If the unit is not working properly, this may be due to small problems that you can easily resolve yourself. Follow these instructions carefully before contacting your local Authorised Technical Service Centre. PROBLEM The air conditioner is • it is not plugged in... -
Page 13: Technical Specification
Technical specification RECOMMENDED OPERATING CONDITIONS Room temperature 70°F -90°F (21 ÷ 32°C) This appliance contains substances which, if released into the atmosphere, would damage the ozone layer. Care should therefore be taken not to perforate the refrigerant circuit. At the end of its working life, delivery the air conditioning unit to a special collection centre. - Page 14 ear Customer, Thank you for having purchased an appliance made by De’ Longhi, the international leader in portable air conditioning units. Thanks to our years of experience all around the world we are constantly improving the qua- lity and performance of Pinguino. We are confident that you will be sati- sfied with your purchase and enjoy the cool comfort created by the Pin- guino for many years to come.
- Page 15 • De s c r i p t i o n • De s c r i p t c i ó n • De s c r i ç ã o • CONTROL PANEL • TABLERO DE MANDOS • PAINEL DE COMANDOS •...
- Page 16 5751006700/ 01.02...
