CHESTER LAB12VS Operation Manual page 4

SPECIFICATIONS:
Capacities:
Swing Over Bed
Swing Over Cross Slide
Distance Between Centers
Width of Bed
Headstock:
Hole Through Spindle
Taper in Spindle Nose
Number of Spindle Speeds
Range of Spindle Speeds
Feeding and Threading:
Number of Metric Threads
Range of Metric Threads
Number of Imperial Threads
Range of Imperial Threads
Range of Corss Feed
Range of Longitudinal Feed
Compound and Carriage:
Tool Post Type
Maximum Compound Slide Travel
Maximum Cross Slide Travel
Maximum Carriage Travel
Tailstock:
Tailstock Spindle Travel
Taper in Tailstock Spindle
Miscellaneous:
Main Motor
Dimension:
Length
Width
Height
Weight
LAB12 VS Lathe
75-435 rpm / 400-2250 rpm
0.017~0.25mm/r
0.07~0.72mm/r
4-Way (Quick
1.5 KW (5~100Hz)
3
320mm
200mm
900mm
180mm
38mm
MT5
2
18
0.2~3.5mm
21
8~56 T.P.I.
change tool posts)
85mm
165mm
850mm
80mm
MT3
1650mm
750mm
700mm
300Kg
