- Page 1 DB7VS LATHE Manual Chester UK Ltd Clwyd Close Hawarden Industrial Park Hawarden Chester CH5 3PZ Tel: 01244 531631 sales@chestermachinetools.com www.chestermachinetools.com...
- Page 2 Safety guidelines Personnel working with any machine tools are required to follow the safety instructions stated below in order to prevent any accident that may occur. • Appropriate personal protective equipment (such as safety glasses, dust coat, shoes etc..) must be worn whilst operating the machine.
-
Page 3: Table Of Contents
Index Safety ……………………………………………………………..............3 1.1 Proper use ………………………………………………………………………………………………….. 3 1.2 Possible dangers caused by the lathe …………………………………………………………………… 4 1.3 Individual protection gear ………………………………………………………………………………….. 4 1.4 For your own safety during operation …………………………………………………………………….. 4 1.4.1 Disconnecting the lathe and making it safe ……………………………………………………….. 5 Unpacking and connecting ……………………………………………………………………………………... -
Page 4: Safety
Safety This part of the operating manual: • Explains the meaning and use of the warning references contained in the operating manual • Explains how to use the lathe properly • Highlights the dangers that might arise for you or others if these instructions are not obeyed •... -
Page 5: Possible Dangers Caused By The Lathe
1.2 Possible dangers caused by the lathe The lathe has been designed and built using the latest technological advances, nonetheless, there remains a residual risk since the machine operates with • High revolutions • Rotating parts • Electrical voltage and currents We have used construction resources and safety techniques to the minimize the risk to personnel resulting from these hazards. -
Page 6: Disconnecting The Lathe And Making It Safe
• Mind the maximum chuck opening • Use protective goggles • Do not removing turning chips by hand. To remove chips, use a chip hook and or a handbrush • Clamp the turning tool at the correct height and with the least possible overhang •... -
Page 7: Unpacking And Connecting
2 Unpacking and connecting The lathes come preassembled. When the lathe is delivered, check immediately that it has not been damaged during shipping, and that all components are included. Also, check that no fastenings have come loose. 2.1 Extent of supply Compare the parts supplied with the information on the packing list. -
Page 8: First Use
Insufficient rigidity of the foundation leads to the superposition of vibrations between the lathe and foundation (natural frequency of components). Insufficient rigidity of the entire lathe assembly also rapidly causes the lathe to reach critical speeds, with unpleasant vibrations, leading to bad turning results. 2.3 First use 2.3.1 Cleaning and greasing Cleaning the machine... -
Page 9: Optional Accessories
2.3.2 Optional accessories 4 jaw chuck 100mm Flange for 4-jaw chuck Face plate Follow rest Steady rest Set of collet chucks, 1-16mm, 15 pieces (ER25) ER25 Toolholder Quick change tool holder AA Single toolholder WAAD Set of lathe tools, 10mm, 7 pieces Set of tipped tools, 8mm, 11 pieces... -
Page 10: Operation
3 Operation 3.1 Safety Use the lathe only under the following conditions: • The machine is in proper working order • The lathe is used as prescribed • The operating manual is followed All abnormalities should be eliminated immediately. Stop the lathe immediately in the event of any abnormality in operation and make sure it cannot be started up accidentally or without authorization. -
Page 11: Clamping The Tool
3.3 Clamping the tool Clamp the turning tool into the tool holder. The tool must be clamped firmly and with the least possible overhang in order to absorb well and make sure that the cutting force is reliably generated during the chip formation. -
Page 12: Clamping A Workpiece Into The Lathe Chuck
3.4 Clamping a workpiece into the lathe chuck When the workpiece is being improperly clamped, there is a risk of injury as the workpiece may fly off or the jaws may break. The following examples do not show all possible risks of danger. The workpiece should be clamped safely and tightly on the lathe before starting operation. -
Page 13: Replacing The Clamping Jaws On The Lathe Chuck
3.4.1 Replacing the clamp jaws on the lathe chuck The clamping jaws and the three-jaw chuck are equipped with numbers. Insert the clamping jaws at the correct position and in the right order into the three-jaw chuck. After replacement, bring the jaws completely together in order to ensure that they are inserted correctly. -
Page 14: Changing-Over Switch
3.6 Change-over switch The sense of rotation of the lathe is performed by the change-over switch. • The R marking means right-handed rotation. The lathe chuck turns anti-clockwise • The L marking means left-handed rotation. In the left-handed rotation for instance, the lathe slide is being reversed for thread cutting. -
Page 15: Adjusting Feeds And Threads Pitches
3.9 Adjusting feeds and thread pitches In order to achieve a change of feed of a certain thread pitch, the changes wheels are to be changed according to the table. You will find the complete table on the lathe. For example: •... -
Page 16: General Working Notes
3.10 General working notes 3.10.1 Coolant Friction during the cutting processes causes high temperature at the cutting edge of the tool. The tool should therefore be cooled during the cutting process. Cooling the tool with a suitable cooling lubricant ensures better working results and a longer edge life of the cutting tool. Use a water soluble and non-pollutant emulsion as a cooling agent. -
Page 17: Maintenance
4 Maintenance In this section you will find important information about • Inspection • Maintenance • Repair Properly performed regular maintenance is an essential prerequisite for • Safe operation • Faulty-free operation • Long service life of the lathe and •... -
Page 18: Spare Parts Drawing Drive
4.3 Spare parts drawing. Drive... -
Page 19: Spare Parts Drawing Top Slide And Compound Slide
4.4 Spare parts drawing. Top slide and compound slide... -
Page 20: Spare Parts Drawing Lathe Slide
4.5 Spare parts drawing. Lathe slide 4.6 Spare parts drawing. Engine bed... -
Page 21: Spare Parts Drawing Tailstock
4.7 Spare parts drawing. Tailstock... -
Page 22: Spare Parts List
4.8 Spare parts list Pos. Designation Size Quantity Pos. Designation Size Quantity Hexagon socket screw M5x25 Spindle DIN 912 Split washer DIN 127 Handle D.C Motor Tightening nut quadruplicate tool holder V-belt pulley engine Washer quadruplicate tool holder Feather key DIN 6885- Threaded bolt A4x4x20... - Page 23 Pos. Designation Size Quantity Pos. Designation Size Quantity Graduated collar Hexagon socket screw M6x35 compound slide DIN 912 Hexagon socket screw DIN M6x50 Slide bearing Bearing block spindle Left bearing block, leading compound slide spindle Clamping plate lathe slide Hexagon socket screw M6x14 DIN 912 Hexagon socket screw DIN...
- Page 24 Spare parts without illustration: • Splashboard • Chip pan • Rubber place of deposit for tools • Thread cutting table • Cover scale potentiometer • Potentiometer • Control board • Change-over switch • On/Off switch with emergency stop button • Protection lathe chuck •...
-
Page 25: Technical Data
5 Technical data The following information gives the dimensions and weight, and is the manufacturers authorized machine data. Centre Height 90mm Swing over bed 180mm Swing over cross-slide 120mm Distance between centers 300mm Speed range 50-2500rpm Spindle bore 21mm Spindle taper Width of bed 100mm Toolpost tool size...
