HL11 Lathe
Instruction Manual
Chester UK Ltd
Clwyd Close
Hawarden Industrial Park Hawarden
Chester CH5 3PZ
Tel: 01244 531631
sales@chestermachinetools.com
www.chestermachinetools.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HL11 and is the answer not in the manual?

Questions and answers

Related Manuals for CHESTER HL11

Summary of Contents for CHESTER HL11

  • Page 1 HL11 Lathe Instruction Manual Chester UK Ltd Clwyd Close Hawarden Industrial Park Hawarden Chester CH5 3PZ Tel: 01244 531631 sales@chestermachinetools.com www.chestermachinetools.com...

  • Page 2: Limited Warranty

    NOTE The information contained in this handbook is intended as a guide to the operation of these machines and does not form part of any contract. The data it contains has been obtained from the machine manufacturer and from other sources. Whilst every effort has been made to ensure the accuracy of these transcriptions it would be impracticable to verify each and every item.

  • Page 3: Safety Warnings

    13.Keep children and visitors away. All WARNING! visitors should be kept a safe distance Read and understand the entire instruction from the work area. manual before attempting set-up or operation of this machine! 14. Make the workshop childproof.Use padlocks, master switches, and This machine is designed and intended remove starter keys.

  • Page 4: Specifications

    SPECIFICATIONS: HL11 Lathe Capacities: Swing Over Bed 280mm Swing Over Cross Slide 165mm Distance Between Centers 650mm Width of Bed 160mm Headstock: Hole Through Spindle 26mm Taper in Spindle Nose Number of Spindle Speeds 70-2000 rpm Range of Spindle Speeds...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS LIMITED WARRANTY ____________________________________________________ 1 SAFETY WARNINGS _____________________________________________________ 2 SPECIFICATIONS _______________________________________________________ 3 TABLE OF CONTENT ____________________________________________________ 4 CONTENTS OF SHIPPING CONTAINER _____________________________________ 5 UNCRATING AND CLEAN-UP ______________________________________________ 6 FOUNDATION DRAWING _________________________________________________ 6 GENERAL DESCRIPTION _________________________________________________ 7 CONTROLS ____________________________________________________________ 9 OPERATION ____________________________________________________________ 11 LATHE ACCESSORIES ___________________________________________________ 16 ADJUSTMENT __________________________________________________________ 18...

  • Page 6: Contents Of Shipping Container

    Read and understand the entire contents of thisManual before attempting set-up or operation! Failure to comply may cause serious injure! CONTENTS OF SHIPPING CONTAINER HL11 Lathe Test Flow Chat Toolbox & Tools TOOLBOX CONTENTS (Fig. 01 ) Dead Center MT4...

  • Page 7: Uncrating And Clean-Up

    UNCRATING AND CLEAN-UP 1. Finish removing the wooden crate from around the lathe 2. Check all the accessories of the machine tool according to the packing list. 3. Unbolt the lathe from the shipping crate bottom. 4. Choose a location for the lathe that is dry, has good lighting and has enough room to be able to service the lathe on all four sides.

  • Page 8: General Description

    GENERAL DESCRIPTION Lathe Bed (Fig. 03) The lathe bed is made of high-grade iron. By combining high cheeks with strong cross ribs, a bed of low vibration and rigidity is produced. It integrates the headstock and drive unit, for attaching the carriage and leadscrew. The two precision-ground V - sideways, re-enforced by heat hardening and grinding, are the accurate guide for the carriage and tailstock.
  • Page 9 Apron (Fig. 07) The apron is mounted on the bed. It houses the half nut with an engaging lever for activating the automatic feed. The half nut gibs can be adjusted from the outside. A rack, mounted on the bed, and a pinion operated by handwheel on the carriage allow for quick travel of the apron.

  • Page 10: Controls

    CONTROLS 1. Change-over Switch (A, Fig. 11) After the machine is switched on, turn the switch to “F” position for counter-clockwise spindle rotation (forward). Turn the switch to “R” position for clockwise spindle rotation (reverse). “0” position is OFF and the spindle remains idle.
  • Page 11 9. Carriage Lock Turn hex socket cap screw (A, Fig.14) clockwise and tighten to lock. Turn counter-clockwise and loosen to unlock. Caution: carriage lock screw must be unlocked before engaging automatic feeds or damage to lathe may occur. 10. Longitudinal Traverse (B, Fig. 15) Rotate hand wheel clockwise to move the apron assembly toward the tailstock (right).

  • Page 12: Operation

    OPERATION Replacement of Chuck The head spindle holding fixture is cylindrical. Loosen three set screws and nuts (A, Fig.17, only two are shown) on the lathe chuck flange to remove the chuck. Position the new chuck and fix it using the same set screws and nuts.
  • Page 13 Manual Turning Apron travel, cross travel, and top slide handwheel can be operated for longitudinal or cross feeding. (Fig.21) Longitudinal Turning with Auto-Feed 1. Set the selector knob (A, Fig.22) to select the feed direction and feed speed. 2. Use the table (B, Fig.22) on the lathe for selecting the feed speed or the thread pitch.
  • Page 14 THREADING AND FEEDING TABLE FOR METRIC LATHE...
  • Page 15 Straight Turning (Fig. 25) In the straight turning operation, the tool feeds parallel to the axis of rotation of the workpiece. The feed can be either manual by turning the handwheel on the lathe saddle or the top slide, or by activating the automatic feed. The crossfeed for the depth of cut is achieved using the cross slide.
  • Page 16 Taper Turning by Setting the Top Slide By angling the top slide, tapers may be turned manually with the top slide. (Fig. 29) Rotate the top slide to the required angle. A graduated scale permits accurate adjustment of the top slide. The crossfeed is performed with the cross slide.

  • Page 17: Lathe Accessories

    LATHE ACCESSORIES Three Jaw Universal Lathe Chuck Using this universal chuck, round, triangular, square, hexagonal octagonal, and twelve-cornered stock may be clamped. (Fig.31) Note: new lathes have very tight fitting jaws. This is necessary to ensure accurate clamping and long service life.
  • Page 18 Steady Rest The steady rest serves as a support for shafts on the free tailstock end. For many operations the tailstock can not be used as it obstructs the turning tool or drilling tool, and therefore, must be removed from the machine. The steady rest, which function as an end support, ensures chatter-free operation.

  • Page 19: Adjustment

    ADJUSTMENT After a period time, wear in some of the moving components may need to be adjust Main Spindle Bearings The main spindle bearings are adjusted at the factory. If end play becomes evident after considerable use, the bearings may be adjusted. Loosen two hex socket cap screws (A, Fig.38) in the slotted nut (B, Fig.38) on the back of the spindle.

  • Page 20: Lubrication

    LUBRICATION CAUTION! Lathe must be serviced at all lubrication points and all reservoirs filled to operating level before the lathe is placed into service! Failure to comply may cause serious damage! NOTES: WfAHOMG Lubricate all slideways lightly before every use. Lubricate the change gears and the leadscrew slightly with a lithium-based grease.
  • Page 21 oil port (A, 6. Leadscrew Lubricate the oil port (A. FIG.46) with 20W machine oil once daily. 7. Tailstock Lubricate two oil ports (B. Fig.46) with 20W machine oil once daily.

  • Page 22: Electrical Connection

    Failure to comply may cause serious injury and damage to the machinery and property! The HL11 Lathe is rated at 70W, 1PH, 230V only. Confirm power available at the lathe’s location is the same rating as the lathe. Using the wiring diagram (Fig.47) for connecting the lathe to the mains supply.

  • Page 23: Maintenance

    MAINTENANCE Keep the maintenance of the machine tool during the operation to guarantee the accuracy and service life of the machine tool. 1. In order to retain the machine’s precision and functionality, it is essential to treat it with care, keep it clean and grease and lubricate it regularly.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Problem Possible Reason Elimination Resharpen tool Surface of workpiece too Tool blunt Tool springs Feed too high Clamp tool with less overhang rough Radius at the tool tip too small Reduce feed Increase radius Centers are not aligned (tailstock has Adjust tailstock to the center Align offset) Workpiece becomes coned...
  • Page 25 BENCH LATHE Parts list for HL11 Keep Read and Understand the Operation Manual and SafetyInformation Before Operated!
  • Page 26 Headstock and Driving Assembly...
  • Page 27 Headstock and Driving Assembly(I) Parts No. Description Specification spindle box CQC280-04-01B CQC280-04-02B.1 Gasket Gearbox cover CQC280-04-02B G38-4 M18x1.5 Oil plug M6x16 Hex Socket Cap Screw Round nut M20x1.5 20 mm Spanner nut toothed washer V-Belt pulley CQC280-04B-31 Bushing CQC280-04-32 Oil seal FB25x42x8 6004 Ball Bearing...
  • Page 28 Parts No. Description Specification End cover CQC280-04-41 Hex Socket Cap Screw M6x18 Tapered roller bearing 30208 Gear CQC280-04B-19.1 Gear CQC280-04B-19.2 Ext retaining ring 38 mm Gear CQC280-04-20 Ext retaining ring 35 mm Tapered roller bearing 30207 End cover CQC280-04-40 Hex Socket Cap Screw M6x18 Bushing CQC280-04-39...
  • Page 29 Parts No. Description Specification Ext retaining ring 12 mm Ball oiler 6 mm Speed shift fork CQC280-04-65 Rocker arm CQC280-04-74 Small axis CQC280-04-62 Rolling sleeve CQC280-04-61 Swing arm support CQC280-04-75 Countersunk screw M5x10 Swing arm shaft CQC280-04-76 Speed shift fork CQC280-04-66 Rocker arm CQC280-04-67...
  • Page 30 Gearbox Assembly...
  • Page 31 Gearbox Assembly (I) Parts No. Description Specification Gearbox CQC280-05-01 Gearbox Cover CQC280-05-33 Countersunk screw M4x6 Ball oiler 6 mm Ext retaining ring 12 mm Washer CQ290V-05- 07B Spacer sleeve CQC280-04-52 Gear CQC280-05-03B Shaft CQC280-05-04 6x18 4x80 Left flange CQC280-05-05 Countersunk screw M5x10 O-Ring GB/T3452.1 22.4x1.8...
  • Page 32 Gearbox Assembly (II) Parts No. Description Specification Gear CQC280-05-22 4x10 Gear CQC280-05-23 Gear CQC280-05-24 Set Screw M5x6 O-Ring GB/T3452.1 22.4x1.8 Plug CQC280-05-16 Speed shift fork CQC280-05-27 Rocker arm CQC280-05-28 Set Screw M6x8 Shaft CQC280-05-29 O-Ring GB/T3452.1 21.2x1.8 Flange CQC280-05-30 Countersunk screw M4x10 O-Ring GB/T3452.1 11.8x1.8...
  • Page 33 Top slide Cross slide , Carriage Assembly...
  • Page 34 Top slide Cross slide , Carriage Assembly ( I ) Parts No. Description Specification Screw M8x30 Handle base CQ6230-07-20 Handle lever CQ6230-07-21 washer CQ6230-07-19 Tool slide CQ6230-WM290V-23 Plunger CQ6230-07-16 Spring CQ6230-07-48.1 Tool post stud CQ6230-WM290V-18 Set screw M6x8 Compound slide CQ6230-07-24 (b) CQ6230-07-38 Gib adjustment screw...
  • Page 35 Top slide Cross slide , Carriage Assembly ( II ) Parts No. Description Specification Hex Socket Cap Screw M8x20 Oil ball Cross slide leadscrew nut CQC280-07-15 Hex Socket Cap Screw M4x10 Cross slide leadscrew CQC280-07-14 Gear CQC280-07-13 Roll Pin 3x18 Thrust bearing 51100 Bushing...
  • Page 36 Apron Assembly...
  • Page 37 Apron Assembly ( I ) Parts No. Description Specification Apron casting CQC280-06-01 Gear Shaft CQC280-06-05 4x14 Bracket CQC280-06-04 Oil ball Hex Socket Cap Screw M5x20 Graduated dial CQC280-06-03 Handwheel CQC280-06-02 Spring plate CQ6123-07-37 washer 10mm Hex nut Handwheel handle ZX30-01-10 Handle step screw ZX30-01-09 Gear Shaft...
  • Page 38 Apron Assembly (II) Parts No. Description Specification Φ4x18 Feed control seat CQC280-06-18 Hex Socket Cap Screw M5x35 Gear shaft CQC280-06-19 Handle CQC280-06-23 Guide block CQC280-06-21 Hex Socket Cap Screw M5x12 Ball Φ5 Spring 0.7x4x10 Set Screw M6x5 Half Nut CQC280-06-29 Opening and closing nut seat CQC280-06-28 Hexagon socket pan head screws...
  • Page 39 Tailstock Assembly...
  • Page 40 Tailstock Assembly Parts No. Description Specification Tailstock quill CQ290V-08-14 CQ290V-08-12 CQ290V-08-15 Hex Socket Cap Screw M4x12 Lead Screw CQ6132-08-16 3x10 Pivot Block CQ6132V-08-09 Washer Φ10 Adjustment handle M10-95x50 Oil Ball Φ6 Tailstock body CQC280-08-01 Collar CQ6132V-08-06 Set Screw M6x10 Limit Screw M6x10 Flange Cover CQ290V-08-17...
  • Page 41 Bed Assembly...
  • Page 42 Bed Assembly Parts No. Description Specification Lathe bed CQC280-01-01 Rack gear CQC280-01-03 Hex Socket Cap Screw M5x16 Spring pin Φ4x16 Lead screw guard CQC280-13-10 Cross recessed head screws M5x10 Lead screw CQC280-01-02 Bracket CQC280-01-04 Bearing 51102 Round nut M12x1.25 Hex Socket Cap Screw M6x50 Oil Ball Φ6...
  • Page 43 Parts No. Description Specification Set screw M6x12 V-Belt Gates-XPZ710 Washer Φ12 Hex Socket Cap Screw M8x25 Electrical cabinet CQC280-13-05 Splash guard CQC280-13-01 Washer Φ6 Hex Socket Cap Screw M6x12 Chuck cover CQC280-13-11...
  • Page 44 Reversing Maneuver Parts No. Description Specification Hex Socket Cap Screw M3x16 Micro Switch 0V-156-1C25 Switch box CQC280-01-17 Set Screw M6x5 Hex Socket Cap Screw M5x25 Threaded cylindrical pin 4x14 Hexagon joystick CQC280-01-15 Shaft sleeve CQC280-01-21 Washer CQC280-01-20 Spring CQC280-01-19 Switch bracket CQC280-01-18 Hex Socket Cap Screw M6x16...
  • Page 45 Change Gear Assembly Parts No. Description Specification Oil ball Ext retaining ring 12mm Washer CQ290V-05- 07B Gear CQC280-04-27B Gear CQC280-04-26B 6x20 Bushing CQC280-04-51 Shaft CQC280-05-34 Swing frame CQC280-05-35 Hex nut Hex Socket Cap Screw M6x16 Spacer sleeve CQC280-05-36 Washer Hex Socket Cap Screw M8x30 Gear CQC280-05-03B...
  • Page 46 Thread Chasing Dial Parts No. Description Specification Screw GB818-85 M6x10 Thread chasing dial CQ6125-06-06 Clasp seat CQ6123-06-14 Hex Socket Cap Screw GB70-85 M8x45 Shaft CQ6123-06-12 GB1096-79 3x12 Gear CQC280-06-49 Gear CQ290V-06-49B Washer GB97.1-85 GB6170-86...
  • Page 47 HL11 Lathe I. Visual Inspection IV. Electrical Inspection □ 1. Correct label 1. Connection tightened □ 2. Painting damage □ 2. Correct electrical elements □ 3. Corrosion damage □ 3. Earth resistance □ 4. Screw tightened □ 4. Insulation resistance □...
  • Page 48 Test Record HL11 Lathe...

  • Page 49: Inspection Item

    HL11 Lathe TOLERANCE mm INSPECTION DIAGRAM PERMISSIBL ITEM ACTUAL Runout of spindle 0.015 a radial plane b 0.015 b face plane Runout of center 0.03 Runout of spindle 0.015 taper hole a spindle nose b 0.04 b 250 distance Parallelism of center...
  • Page 50 HL11 Lathe TOLERANCE mm INSPECTION DIAGRAM PERMISSIBL ITEM ACTUAL Parallelism of &--b tailstock quill to 0.025/50 carriage movement a in horizontal plane 0.025/50 b in vertical plane Parallelism of tailstock quill taper 6---b a 0.03/50 hole to carriage movement b 0.03/50...
