Summary of Contents for Fenix CR
- Page 10 RF SENSOR WIFI BOX RF sensor...
- Page 15 Method of installation Graphic instructions for mounting on the wall Connecting to home Wi-Fi network Wifi Box control elements Using CR Wifi heating panels Modes for heating RF sensor (temperature sensor Description of RF sensor Reset of RF pairing Pairing Wifi box - RF sensor...
- Page 16 Ceramic is a fragile material, be careful during WARNING: Some parts of this product may transportation, handling and assembly! become very hot when used and may cause burns. Special attention must be paid to Installation/removal of the panel may only be presence of children and disabled persons.
- Page 17 Place the enclosed frame on the wall, mark and drill the holes for the fixing Insert the fixing and fix the frame with the appropriate number of chubby head screws Slide the panel onto the frame and unscrew the plastic rollers on the rear side of the panel so that it is firmly backed up against the wall If the panel has to be connected to el.
- Page 19 The CR radiant panel falls into the category of controlled heaters. According to Commission Regulation (EU) 2015/1188, the controlled heaters must be controlled by external elec- tronic temperature regulation in the room with a weekly programme, which additionally con- tains at least one of the following functions...
- Page 20 Switching the panel on or off (see sec. 2.7 Starts RF pairing mode (see sec. 4.3)
- Page 21 Switching the panel on/off has a sound signal Two short tones when ON One long tone when OFF Not lit: the panel is switched off Red: the panel is on and heats Green: heated - the panel is on, but does not Wifi LED starts flashing red and blue alternate- heat ly, after releasing the button it starts flashing...
- Page 22 Start and end of the Holiday mode is set in the format: day:year + hour:min (step 15 min) When opening the menu for the Holiday mode, start on the current day and time, end +1 day +1 hour is offered automatically In the set time interval, the connected devices are assigned one of four modes Connected devices will switch to the OFF status...
- Page 23 If more heating panels should be in a single room, use only one panel with Wifi box and RF sensor. Choose the other panels (max. 3) with the V26 wireless receiver, they will be connected to the Wifi box as subordinate heaters Process of pairing the Wifi box with V26 receiv- ers is the same as pairing with the RF sensor Green: RF pairing mode...
- Page 26 LED indication of Wifi status Check your Wifi router. If it is OK, switch the Wifi box on the panel to the local mode, connect to the mobile The time period of lost connection application and check network with the Wifi router is 6 hours or settings more LED indication of Wifi status...
- Page 27 All products containing hydrofluoric acid or fluorine derivatives are prohibited, as they can destroy the coating and surface of the glass Clin - spray window cleaner (contains alcohol, Highly acidic and alkaline products are prohibit- manufactured by Henkel) ed, abrasive products are prohibited as well Vitro - industrial window and mirror cleaner (contains 2-butoxyethanol, manufacturer Am- stutz produkte AG)
- Page 29 BEMERKUNG: Dieses Produkt fällt in die Kate- gorie der geregelten Heizungen. Gemäß der Verordnung 2015/1188 der EU-Kommission müssen die geregelten Heizgeräte in Bezug auf die Ökodesign-Anforderungen für lokale Heiz- geräte von einem externen Steuergerät (Thermostat) reguliert werden, das nicht Teil des Produkts ist und der oben genannten Verordnung entspricht.
- Page 36 RF SENSOR WIFI BOX RF sensor...
