Page 1 SuperServer ® ARS-111GL-SHR USER’S MANUAL Revision 1.0...
Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Page 3: About This Manual
If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
Page 4: Table Of Contents
Contents Contents Contacting Supermicro ......................7 Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View ...........................9 NVMe SSD Drive Indicators ..................10 Control Panel .........................11 Rear View ..........................12 Rear Input/Output Panel ....................13 Power Supply Indicators ....................13 Top View ..........................14 Grace CPU Superchip.......................15...
Page 5 Contents Removing the Chassis from the Rack ................28 Removing the Outer Rails from the Rack .................29 Chapter 3 Maintenance and Component Installation 3.1 Removing Power .......................30 3.2 Accessing the System ......................31 Removing the Top Cover ....................31 3.3 Processor and Heatsink Installation ...................32 3.4 Memory Support .........................36 Memory Support ........................36 3.5 Motherboard Battery ......................37...
Page 6 6.4 CMOS Clear ........................57 6.5 Where to Get Replacement Components ................58 6.6 Technical Support Procedures ...................58 Returning Merchandise for Service ...................59 6.7 Feedback ..........................59 6.8 Contacting Supermicro .......................60 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...
Page 7: Contacting Supermicro
San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 8: Chapter 1 Introduction
1U: 17.33" x 1.75" x 37" (440 x 44 x 940 mm (W x H x D) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the ARS-111GL-SHR have been certified as...
Page 9: System Features
Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Service/Asset Tag Control Panels Figure 1-1. Front View System Features: Front Feature Description Service Tag Service Tag with BMC Password Reset...
Page 10: Nvme Ssd Drive Indicators
Chapter 1: Introduction NVMe SSD Drive Indicators Each E1.S NVMe SSD drive has two LED indicators: an activity indicator and a status indicator. Storage Drive Indicator LEDs Color Blinking Pattern Behavior for Device Blue Solid on Idle SAS/NVMe drive installed Activity Blue Blinking...
Page 11: Control Panel
Chapter 1: Introduction Control Panel NIC2 LED UID LED Power Fail LED Power LED Power Button Drive LED Information LED NIC1 LED Figure 1-2. Control Panel Control Panel Features Features Description The main power switch applies or removes primary power from the power supply to the Power Button server but maintains standby power.
Page 12: Rear View
Chapter 1: Introduction Information LED Color, Status Description Red, solid An overheating condition has occurred Red, blinking at 1 Hz Fan failure, check for an inoperative fan Red, blinking at 0.25 Hz Power failure, check for a non-operational power supply Red, blinking at 10 Hz CPLD recovery mode error Blue, solid...
Page 13: Rear Input/Output Panel
Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. Solid Amber The system might need service. Please contact Supermicro technical support. No AC power to modules...
Page 14: Top View
Chapter 1: Introduction Top View Rear Power Supplies Expansion Slot Bays Fans Front Figure 1-5. Motherboard Tray: Top View System Features: Top Feature Description Power Supplies PWS-2K09A-1R, two 2000 Watt redundant Titanium level power supplies Expansion Slot Bays Three PCIe 5.0 x16 expansion slots Fans Nine heavy-duty 4-cm fans Nvidia Grace CPU Superchip via two Mirror Mezz connectors...
Page 15: Grace Cpu Superchip
Chapter 1: Introduction Grace CPU Superchip The ARS-111GL-SHR features one Grace CPU Superchip with attached LPDDR5x memory on a mezzanine module, and a 900 GB/s NVLink, chip-to-chip on the module. There is no off-the-module NVLink support. Grace CPU Superchip Overview Core Count 72 Arm Neoverse V2 Cores with 4 x128b SVE2 L1 Cache...
Page 16: Motherboard Layout
Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the G1SMH-G motherboard. See the table on the following page for descriptions. JPWR1 JLFP1 GPU1 J49 JFP1 HB_LED1 UID_LED1 PWR_LED1 MH14 JLFP1 JFP1 PRESS-FIT PRESS-FIT G1SMH-G JSB3 PWR_LED1 UID_LED1 HB_LED1 REV:1.02 JSB3...
Page 17: Quick Reference Table
Chapter 1: Introduction Quick Reference Table Description Status HB_LED1 CPLD Initialization Green Blinking: CPLD initialized Before pressing PWRBTN1: Yellow Solid LED1 EROT Detected After pressing PWRBTN1: Yellow Off LED2 EROT Not Detected Red Solid: EROT is not detected Before pressing PWRBTN1: Green Blinking LED3 Normal Power Detected After pressing PWRBTN1: Green Solid...
Page 18 Chapter 1: Introduction Connector Description JNCSIBF3 NVIDIA BlueField-3 DPU Card NCSI Sideband Connector JSB1 74-Pin IO Sideband Signals Connector JSB2 20-Pin Main Sideband Signals Connector JSB3 Front Control Board Debug Header JPFR1 PFR Debug JPFR2 PFR Operation JPFR3 PFR Force Recovery JPWR1 48 V 6-Pin GPU Power Supply Connector JPWR2-JPWR4...
Page 19: Motherboard Block Diagram
Chapter 1: Introduction Motherboard Block Diagram Figure 1-7. Motherboard Block Diagram...
Page 20: Chapter 2 Chassis Installation
Chapter 2: Server Installation Chapter 2 Chassis Installation 2.1 Overview This chapter provides advice and instructions for mounting your chassis in a server rack. If your chassis is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those specific components.
Page 21: System/Chassis Precautions
Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack installations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.
Page 22: Circuit Overloading
Chapter 2: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.
Page 23: Installing The System Into A Rack
Chapter 2: Server Installation 2.3 Installing the System into a Rack This section provides information on installing the SCGP101/102 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
Page 24: Releasing The Inner Rail
Chapter 2: Server Installation Releasing the Inner Rail It is necessary to release the inner rail from the middle and outer rails before installing the inner rail on the chassis. Releasing the Inner Rail from the Middle and Outer Rails 1.
Page 25: Installing The Inner Rails On The Chassis
Chapter 2: Server Installation Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Confirm that the left and right inner rails have been correctly identified. 2. Place the inner rail firmly against the side of the chassis, aligning the pins on the side of the chassis with the slotted thru holes in the inner rail.
Page 26: Installing The Outer Rails On The Rack
Chapter 2: Server Installation Installing the Outer Rails on the Rack Installing the Outer Rails 1. Confirm that the left and right outer rails have been correctly identified. 2. Release the small locking lever on the inside of the middle rail and push the middle rail back into the outer rail.
Page 27: Installing Into The Rack
Chapter 2: Server Installation Installing into the Rack After the rails are installed on the chassis and on the rack, the server can be installed in the rack. It is heavy and requires two or three people to lift. Installing the Chassis into a Rack 1.
Page 28: Removing The Chassis From The Rack
Chapter 2: Server Installation Removing the Chassis from the Rack Caution: The chassis is heavy and requires two or three people to lift it out. Removing the Chassis 1. Lift the right and left front latches on either side of the front panel. 2.
Page 29: Removing The Outer Rails From The Rack
Chapter 2: Server Installation Removing the Outer Rails from the Rack In the uncommon event that it is necessary to remove the outer rails from the rack, follow these instructions. The chassis must be out of the rack. Releasing the Outer Rails 1.
Page 30: Chapter 3 Maintenance And Component Installation
Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.
Page 31: Accessing The System
Chapter 3: Maintenance and Component Installation 3.2 Accessing the System Note: The chassis features a removable top cover for access to the internal components. When performing service on components inside the system, remove the system from the rack and place it on a workbench or desk. Do not service with the system extended from the rack. Removing the Top Cover The top cover can be removed to access the chassis fans while the server continues to operate.
Page 32: Processor And Heatsink Installation
• Make sure to install the motherboard into the chassis before you install the module heatsink. • Refer to the Supermicro website for updates on the NVIDIA GH200 Grace Hopper Super- chip module support. Installing the Superchip onto the Motherboard 1.
Page 33 Chapter 3: Maintenance and Component Installation Superchip Top View 3. Before the springs underneath the NVIDIA GH200 Grace Hopper Superchip module are compressed, check the alignment of the guide pins and the holes on the motherboard again. 4. Fasten the four screws using a torque of 5.2 lb-in (0.587 N-m) to complete the NVIDIA GH200 Grace Hopper Superchip module installation.
Page 34 Chapter 3: Maintenance and Component Installation Superchip Top View 5. Place thermal pads on the module. The thermal pads are shown as red rectangles above. 6. Peel off the thermal pad protector underneath each heatsink. 7. Place the heatsinks on top of the NVIDIA GH200 Grace Hopper Superchip module.
Page 35 Chapter 3: Maintenance and Component Installation 8. Using a torque of 5.2 lb-in (0.587 N-m), secure each heatsink onto the NVIDIA GH200 Grace Hopper Superchip module with four screws. Uninstalling the NVIDIA GH200 Grace Hopper Superchip Module and Heatsinks 1. Remove the heatsinks attached to the top of the module by reversing the installation procedure.
Page 36: Memory Support
Chapter 3: Maintenance and Component Installation 3.4 Memory Support Memory Support The G1SMH-G supports up to 480 GB of ECC LPDDR5 and 96 GB of HBM. The memory is embedded and no installation is required.
Page 37: Motherboard Battery
Chapter 3: Maintenance and Component Installation 3.5 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system. 1.
Page 38: Storage Modules
Chapter 3: Maintenance and Component Installation 3.6 Storage Modules The system supports up to eight E1.S NVMe SSD drives using mounting trays or carriers. Note: Enterprise-level storage drives are recommended for use in Supermicro servers. For information on recommended drives, visit the Supermicro website. Carrier The storage drives are mounted in carriers to simplify their installation and removal from the chassis.
Page 39: Removing The I/O And Pcie/Gpu Modules
Chapter 3: Maintenance and Component Installation 3.7 Removing the I/O and PCIe/GPU Modules The system provides one PCIe/GPU bay and an I/O module. The PCIe/GPU bay has a pull- out module where two GPU cards may be installed. Removal of the pull-out module is shown below.
Page 40: System Fans
Chapter 3: Maintenance and Component Installation 3.8 System Fans Up to nine heavy-duty fans provide cooling for the system. Power must be removed from the system before replacing them. Replacing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan requires changing.
Page 41: Power Supply
The system features two redundant 2000 W power supplies. Each power supply can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense and operate with an input voltage of 100-120 V or 180-240 V.
Page 42: Chapter 4 Motherboard Connections
Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
Page 43: Headers And Connectors
Chapter 4: Motherboard Connections 4.2 Headers and Connectors 12 V 8-pin IO Board Power Supply Connector (JPWR6) JPWR6 is an 8-pin MICRO POWER PLUS power input to provide power to the I/O board. Refer to the table below for pin definitions. 12 V 8-pin IO Board Power Connector Pin Definitions Pin#...
Page 44 Chapter 4: Motherboard Connections 74-pin IO Sideband Power Supply Connector (JSB1) JSB1 is a 74-pin MICRO POWER PLUS power input to provide power to the sideband connector. Refer to the table below for pin definitions. 74-pin IO Sideband Power Connector Pin Definitions Pin# Definition...
Page 45: Expansion Slots
Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
Page 46 Chapter 4: Motherboard Connections Power SMB Header (PWRI2C) Power System Management Bus (I C) header monitors power supply, fan and system temperatures. See the table below for pin definitions. Power SMB Header Pin Definitions Pin# Definition Clock Data Alert Ground +3.3V...
Page 47: I/O Ports
Chapter 4: Motherboard Connections 4.3 I/O Ports I/O ports are located in a module that installs into a rear expansion slot. LAN Port USB Port Mini DisplayPort Figure 4-1. Input/Output Module LAN Port The LAN port on the rear I/O module is a 1GbE dedicated IPMI LAN port. Mini DisplayPort Mini DisplayPort connector (digital display interface) used to connect a video source to a display device.
Page 48: Led Indicators
Chapter 4: Motherboard Connections 4.4 LED Indicators UID LED (UID_LED1) The UID LED is located next to two buttons at one of the corners of the motherboard. One of the buttons is the UIDBTN1 button. Press this button and the LED will blink blue to show that the UID is active.
Page 49: Activity Leds
Chapter 4: Motherboard Connections M.2 Activity LEDs ACT_LED1 and ACT_LED2 are onboard M.2 LEDs. When these LEDs are blinking green, the M.2 SSD is active. M.2 Activity LEDs LED Color State Definition None M.2 Inactive Green Blinking M.2 Active EROT Detected LEDs (LED1 and LED2) The EROT Detected OK LED (LED1) and the EROT Detected Fail LED (LED2) shows the status of the Root-of-Trust (RoT).
Page 50: Chapter 5 Software
Chapter 5: Software Chapter 5 Software After the hardware has been installed, install an operating system. Also, some management and diagnostic software is available. 5.1 Operating System Installation Several operating systems are supported: • Ubuntu • Red Hat Enterprise Linux •...
Page 51: Superdoctor ® 5
5.2 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).
Page 52: Bmc
There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: https://www.supermicro.com/manuals/other/BMC_IPMI_X13_H13.pdf BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.
Page 53: Chapter 6 Troubleshooting And Support
Chapter 6: Troubleshooting and Support Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking Products option. •...
Page 54: Baseboard Management Controller (Bmc)
Security Center for recent security notices Supermicro Phone and Addresses 6.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring, and management. There are several BIOS settings that are related to BMC.
Page 55: Troubleshooting Procedures
Chapter 6: Troubleshooting and Support 6.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Always disconnect the AC power cables before adding, changing or installing any non hot-swap hardware components.
Page 56: Losing The System's Setup Configuration
BIOS installed in your system. 2. Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. Is this needed since memory is embedded? Note: Click on the "Tested Memory List"...
Page 57: Cmos Clear
Chapter 6: Troubleshooting and Support memory module installed) to identify the trouble areas. Refer to the steps listed in Section above for proper troubleshooting procedures. 4. Identifying bad components by isolating them. If necessary, remove a component in question from the chassis, and test it in isolation to make sure that it works properly. Replace a bad component with a good one.
Page 58: Where To Get Replacement Components
Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services. They should know of any possible problems with the specific system configuration that was sold to you.
Page 59: Returning Merchandise For Service
During the warranty period, contact your distributor first for any product problems. 6.7 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. To provide feedback on our manuals, please email us at techwriterteam@ supermicro.com.
Page 60: Contacting Supermicro
San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 61: Appendix A Standardized Warning Statements For Ac Systems
Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
Page 62 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
Page 63: Installation Instructions
Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
Page 64: Circuit Breaker
Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
Page 65 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
Page 66: Power Disconnection Warning
Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
Page 67: Equipment Installation
Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
Page 68: Restricted Area
Appendix A: Warning Statements Attention Seul le personnel autorisé et le personnel de maintenance qualifié doivent être autorisés à installer, remplacer ou entretenir cet équipement.. !‫אזהרה‬ ‫.יש לאפשר רק צוות מורשה ואנשי שירות מוסמכים להתקין, להחליף או לטפל בציוד זה‬ ‫.ينبغي...
Page 69 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
Page 70: Battery Handling
Appendix A: Warning Statements Battery Handling CAUTION: There is risk of explosion if the battery is replaced by an incorrect type. Replace the battery only with the same or equivalent type recommended by the manu- facturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
Page 71: Redundant Power Supplies
Appendix A: Warning Statements ‫.هناك خطر االنفجار إذا تم استبدال البطارية بنوع غري صحيح‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리를 잘못된 종류로 교체하면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조 사에서...
Page 72 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
Page 73: Backplane Voltage
Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧システムの稼働中は危険な電圧または電力が、バックプレーン上にかかっています。修理する際には注意ください。警告当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。警告當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
Page 74: Comply With Local And National Electrical Codes
Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
Page 75: Product Disposal
Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
Page 76 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
Page 77 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
Page 78 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
Page 79 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
Page 80 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
Page 81: Appendix B System Specifications
Appendix B: System Specifications Appendix B System Specifications Processor Nvidia Grace CPU Superchip via two Mirror Mezz connectors Note: Refer to the motherboard specifications pages on our website for updates to supported processors. GPUs One NVIDIA H100 Tensor Core GPU on GH200 Grace Hopper™ Superchip (Air-cooled), highest GPU communication using ®...
Page 82 Appendix B: System Specifications Operating Environment Operating Temperature: 10ºC to 35ºC (50ºF to 95ºF) Non-operating Temperature: -40ºC to 60ºC (-40ºF to 140ºF) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016...
Page 83 Appendix B: System Specifications General Data Center Environmental Specifications Particulate contamination specifications Air filtration: Data centers must be kept clean to Class 8 of ISO 14644-1 (ISO 2015). The air entering the data center should be filtered with a MERV 11 filter or better. The air within the data center should be continuously filtered with a MERV 8 filter or better.
