PICOTE Xpress Coating System Operation & Installation Manual page 10

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
4.
5.
6.
General Description:
1. Operation Check Button
2. Filling/Coating Switch
3. Emergency Stop
4. Cylinder Thermostat
5. On/Off Switch
6. Power Socket
7. Emergency Check Button
8. Hose Reel Connector
9. Pump Display
Intended Use:
Picote Brush Coating pipes from DN32-300 (1¼-12'') in diameter
Voltage:
All variants of the Xpress Coating System operate within 90-240VAC 50/60Hz.
Battery:
The Xpress Coating Pump has an internal 48V, 882Wh Li-Ion battery.
Picote Solutions Oy Ltd
PUMP
1. 2. 3.
9.
10
5
7.
8.
