Summary of Contents for PICOTE MIDI CLEANER 10/23
- Page 1 These instructions are for your personal safety. Always ensure that you have read and understood these instructions before using the equipment. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
To watch practical demonstration videos, take a course, or to download an electronic copy of these Instructions, please visit www.picoteinstitute.com. Please note that videos and courses are not intended as a replacement or alternative to this operating and safety manual, but only as an additional learning tool. Picote Solutions Oy Ltd 2 of 25 www.picoteinstitute.com... -
Page 3: Safety Information
Suitable respirator to prevent any dust or fumes being inhaled or consumed, which could cause occupational asthma or dermatitis. Picote Solutions Oy Ltd 3 of 25 www.picoteinstitute.com... - Page 4 15. Only operate the foot pedal or OPC as instructed. Never place anything on it in place of a foot. 16. Do not extend a Midi Cleaner shaft by more than one extension. Use only Picote Solutions shaft extensions &...
-
Page 5: Environment, Transport, Storage & Disposal
• Maximum Humidity: 95% non-condensing. TRANSPORT: Picote Millers should be transported in a vehicle or trailer and laid down and secured with ratchet straps to prevent any sudden movements or accidents caused by hard braking or accident. Never transport the machine with tooling attached to the shaft. -
Page 6: General Information
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Midi Cleaner When in use always lay the machine down horizontally on the floor. When not in use some non-toxic Picote Flexible Shaft Lubricant might leak from the hand guard Picote Solutions Oy Ltd 6 of 25... -
Page 7: Digital Control Box
Parameters of your Midi Cleaner have been pre-set by the manufacturer. Picote Solutions accepts no liability for failures or accidents caused by tampering with or changing of the manufacturer settings. The control box has been pre-programmed and requires no additional adjustments. -
Page 8: Technical Data
Always follow Picote Solutions instructions when installing and using the machine with accessories. * There are 3 Picote Brush Coating Pump options that can work with the Midi Cleaner. The selection and capabilities of the Coating Pump chosen will determine the pipe size range and length available. -
Page 9: Voltage & Power Supply
3-prong, 15A (125V). If a power generator is used, a minimum 3kW required. Adapters may be necessary for generator connections. Contact your reseller or Picote technical support for more information. AUSTRALIA/UK: Midi Cleaners in these regions have special plugs. -
Page 10: Noise Levels, Vibrations & Emissions
Hand vibration levels depend on the distance from the tool head to the user and working conditions. The vibration levels below have been measured during normal lining activities at Picote worksites in Finland. Vibration has been determined according to ISO-5349 and EU-directive 2002/44/EG. The table below details the safe daily exposure time for the user depending on tool used. -
Page 11: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE We Picote Solutions Oy Ltd as the responsible manufacturer, declare that the following Picote Solutions Oy Ltd drain cleaning machine: Midi Cleaner / Super Midi 10mm Model No: 10/23... -
Page 12: Operating Instructions
Failure to comply could result in serious injury or death. BEFORE OPERATION: Before installing Picote tools, always make sure that the machine is fully turned off and unplugged. Always round off sharp edges of the shaft to avoid cuts and make it easier to insert shaft into tooling/leaders. -
Page 13: Attaching Tools
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE ATTACHING TOOLS: TIGHTENING SET SCREWS: When you add a tool always tighten the screws starting from the screw furthest away from the end of the flexible shaft (where applicable). Picote Solutions Oy Ltd 13 of 25 www.picoteinstitute.com... -
Page 14: Maintenance Programme & Warranty Periods
I: Inspect, fix or replace if needed. P: Perform, replace if needed. R: Replace Service Period 3 months 6 months 1 year Machine & Spare Parts except: Electric Motors Service Centre Repair Work Picote Solutions Oy Ltd 14 of 25 www.picoteinstitute.com... -
Page 15: Maintenance
CHANGING THE FLEXIBLE SHAFT: Only use the shaft and its outer casing specified by Picote Solutions. Order the replacement shaft from your reseller. The flexible shaft is pre-treated with Picote Flexible Shaft Lubricant and the casing replaced prior to shipping. -
Page 16: Servicing The Flexible Shaft
SERVICING THE FLEXIBLE SHAFT & ITS OUTER CASING: The flexible shaft is pre-treated with Picote Flexible Shaft Lubricant and the casing replaced prior to shipping. Always inspect the condition of the shaft and its outer casing regularly. Also, inspect at least once a week that the shaft is well attached under the hand guard at the machine end. -
Page 17: Inspecting Flexible Shaft For Damage
Appropriate oils to use: Shell omala 100 or Agip blasia 100 or Tamoil ep 100 Amount of oil: 42 g / 1.5 oz / 47ml If there is problem that you cannot resolve with this manual, please consult your Picote Reseller or Picote Solutions. Picote Solutions Oy Ltd 17 of 25... -
Page 18: Accessories & Spare Parts
Failure to comply could result in serious injury or death. You must use only the Picote Solutions accessories and attachments with the machine described in this operations manual. The use of other accessories or attachments could present a risk of injury or death. The accessories or attachments should only be used in the proper and intended manner, and always follow Picote Solutions instructions. -
Page 19: Service Tools
Failure to comply could result in serious injury or death. You must use only the Picote Solutions accessories and attachments with the machine described in this operations manual. The use of other accessories or attachments could present a risk of injury or death. The accessories or attachments should only be used in the proper and intended manner, and always follow Picote Solutions instructions. -
Page 20: Practical Tips & Safety Advice
This section contains important safety information. Failure to comply could result in serious injury or death. Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury. - Page 21 Place it ≈500mm (20”) from the end of the shaft. The marker will indicate the tools location and help prevent possible injury from the rotating parts by alerting you when the tool is about to exit the pipe. Picote Solutions Oy Ltd 21 of 25 www.picoteinstitute.com...
-
Page 22: Troubleshooting Flowchart
Change shaft if necessary. Did it help? Midi Cleaner is OK! If there is problem that you cannot resolve with this manual, please consult your Picote Reseller or Picote Solutions at claims@picotesolutions.com Picote Solutions Oy Ltd 22 of 25 www.picoteinstitute.com... -
Page 23: Troubleshooting Fault Codes
Check the motor and connections. Write down the Error Code flashing in the screen of Control Box if needed to contact the Picote Service Centre. The Error Code narrows down the list of possible problems with your Miller unit. -
Page 24: Warranty Policy & Procedure
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with, and substantially conform to their published specifications when shipped or otherwise... - Page 25 • Porvoo, Finland • Sandhurst, England, UK Picote is highly recommended to get the most out of your investment. Certificates are awarded for all certification trainings. Visit our website at www.picotegroup.com or contact us at training@picotesolutions.com to find out about course offerings, pricing, and scheduling.
- Page 26 Revision Date: March 2025 Revision number: 2 Author: Richard Swan Accepted: Ryan Boldan: March 2025 Please Contact: Your Reseller / Salesperson or Picote www.picotegroup.com Production & R&D: International Offices: Technical Support: Pienteollisuustie 24 Finland. United Kingdom. USA. support@picotesolutions.com 06450 Porvoo, Finland support@picotesolutions.com...
