MAXI MILLER 12/30
MAXI MILLER 12/30 | MAXI MILLER PLUS 12/30
OPERATION & SAFETY MANUAL
These instructions are for your personal safety. Always ensure that you
We now have resellers in the U.S., Europe & Australasia.
have read and understood these instructions before using the machinery.
Locate your reseller at picotesolutions.com
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for PICOTE MAXI MILLER 12/30
Summary of Contents for PICOTE MAXI MILLER 12/30
- Page 1 MAXI MILLER 12/30 MAXI MILLER 12/30 | MAXI MILLER PLUS 12/30 OPERATION & SAFETY MANUAL These instructions are for your personal safety. Always ensure that you We now have resellers in the U.S., Europe & Australasia. have read and understood these instructions before using the machinery.
-
Page 2: Table Of Contents
To watch practical demonstration videos, take a course, or to download an electronic copy of these Instructions, please visit www.picoteinstitute.com. Please note that videos and courses are not intended as a replacement or alternative to this operating and safety manual, but only as an additional learning tool. Picote Solutions Oy Ltd www.picoteinstitute.com... -
Page 3: Safety Information
Suitable respirator to prevent any dust or fumes being inhaled or consumed, which could cause occupational asthma or dermatitis. www.picotesolutions.com www.picoteinstitute.com Picote Solutions Oy Ltd... - Page 4 Do not stand on the machine. 13. Only use this machine with the accessories and spare parts offered by the Picote Solutions. Accessories and spare parts should only be used in the manner intended and as described by Picote Solutions.
-
Page 5: Environment, Transport, Storage & Disposal
Never transport machine with tool attached to the shaft. If using pick-up or trailor to transport Picote milling machines, cover the unit to protect it from the elements. STORAGE It is recemmended that milling machines are stored indoors protected from rain and sunlight and in constant ambient temperature. -
Page 6: General Information
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE When in use, always lay the machine down horizontally on the floor. When not in use some non-hazardous Picote Flexible Shaft Lubricant might leak from the hand guard. www.picoteinstitute.com Picote Solutions Oy Ltd... - Page 7 Parameters of your Maxi Miller and Maxi Miller Plus have been pre-set by the manufacturer. Picote Solutions accepts no liability for failures or accidents caused by tampering with or changing of the manufacturer settings. The control box has been pre-programmed and requires no additional adjustments.
-
Page 8: Technical Data
6. Removing metallic inserts. 7. Removing deformed or collapsed CIPP linings. 8. Internal pipe coating using the Picote Brush Coating System™ and the Maxi Coating Pump. Always follow the Picote Solutions instructions when installing and using the machine with accessories. -
Page 9: Voltage & Power Supply
When used with an extension cord, the cord must be a 3 prong twist-lock, 30 Amp (120V). If power invertor generator is used, minimum 3 kW required. Adapters may be necessary for generator connections. Contact your reseller or Picote technical support for more information. -
Page 10: Noise Levels, Vibrations & Emissions
Hand vibration levels depend on the distance from the tool head to the user and working conditions. The vibra- tion levels below have been measured during normal lining activities at Picote worksites in Finland. Vibration has been determined according to ISO-5349 and EU-directive 2002/44/EG. The table below details the safe daily ex- posure time for the user depending on tool used. -
Page 11: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE We Picote Solutions Oy Ltd as the responsible manufacturer, declare that the following Picote Solutions Oy Ltd drain cleaning machines: Maxi Miller: Model No: MXM 12/30 Maxi Miller Plus:... -
Page 12: Operating Instructions
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Before operation: • Before installing Picote tools, always make sure that the machine is fully turned off and unplugged. • Always round off the sharp edges of the shaft to avoid cuts and to make it easier to insert the shaft into the tool or for a leader to be used. -
Page 13: Attaching Tools
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE ATTACHING TOOLS TIGHTENING THE SET SCREWS When you add a tool always tighten the screws starting from the screw furthest away from the end of the flexible shaft (where applicable). www.picoteinstitute.com Picote Solutions Oy Ltd... -
Page 14: Maintenance Programme & Warranty Periods
I: Inspect, fix or replace if needed. P: Perform, replace if needed. R: Replace WARRANTY PERIODS Picote Solutions grants limited warranty for certain machines, equipment & components. Read more detailed in- formation on page 23 Picote Warranty Policy and Procedure. Service Period 3 months 6 months 12 months Milling machine &... -
Page 15: Maintenance
CHANGING THE FLEXIBLE SHAFT Only use the shaft and its outer casing specified by Picote Solutions. Order the replacement shaft from your resel- ler. The flexible shaft is pre-treated with Picote Flexible Shaft Lubricant and the casing replaced prior to shipping. -
Page 16: Servicing The Flexible Shaft
SERVICING THE FLEXIBLE SHAFT & ITS OUTER CASING The flexible shaft is pre-treated with Picote Flexible Shaft Lubricant and the casing replaced prior to shipping. Always inspect the condition of the shaft and its outer casing regularly. Also, inspect at least once a week that the shaft is well attached under the hand guard at the machine end. -
Page 17: Inspecting Flexible Shaft For Damage
Appropriate oils to use: Shell omala 100 or Agip blasia 100 or Tamoil ep 100 Amount of oil: 42 g / 1.5 oz / 47ml If there is problem that you cannot resolve with this manual, please consult your Picote Reseller or Picote Solutions. -
Page 18: Accessories & Spare Parts
The accessories or attachments should only be used in the proper and intended manner, and always follow Picote Solutions instructions. MAXI MILLER 3560032012 Maxi Miller 12/30 Maxi Miller 12/30 Plus, control box with 5m cord. Special order only with longer lead 3560042012 time. 3560032012US Maxi Miller12/30 110V US model Maxi Miller 12/30 Plus, control box with 5m cord. -
Page 19: Practical Tips & Safety Advice
PRACTICAL TIPS & SAFETY ADVICE SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury. - Page 20 PRACTICAL TIPS & SAFETY ADVICE SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Here are some useful tips on how to get the most out of your Picote system. Always use the recommended tools for maintenance to avoid personal injury.
-
Page 21: Troubleshooting Flowchart
Service Center Miller is OK! Write down the Error Code flashing in the screen of Control Box if needed to contact the Picote Service Centre. The Error Code narrows down the list of possible problems with your Miller unit. If there is problem that you cannot resolve with this manual, please consult your Picote Reseller or Picote Solutions at claims@picotesolutions.com... -
Page 22: Troubleshooting Fault Codes
Note: Following a trip, the drive cannot be immediately reset. A delay time is inbuilt, which al- lows the power components of the drive time to recover to avoid damage. dAtA-F Internal memory fault (IO) Press stop-key. If fault persists, consult Picote Solutions. dAtA-E Internal memory fault Press stop-key. If fault persists, consult Picote Solutions. -
Page 23: Warranty Policy & Procedure
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE Limited Warranty: Picote warrants to the original End User that the Product purchased by such End User will operate in accordance with, and substantially conform to their published specifications when shipped or otherwise... - Page 24 Date: FEB 2021 Revision number: Rev. 5 Author: Ville Hukkanen Please Contact: Accepted: Dawn Greig Your Reseller / Salesperson or Picote www.picotesolutions.com Production & R&D International Offices Technical Support Finland. United Kingdom. USA. support@picotesolutions.com Pienteollisuustie 24 06450 Porvoo, Finland support@picotesolutions.com Claims claims@picotesolutions.com...
