Wyrestorm EX-100-IW-USBC Quick Start Manual

100m usb 3.2 single gan in-wall hdbt 3.0 transmitter and receiver kit

Download this manual

100m USB 3.2 Single Gan In-Wall HDBT 3.0

Transmitter and Receiver Kit

EX-100-IW-USBC

WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the

installation process.

IMPORTANT! Installation Requirements

• Read through the

Wiring and Connections

guidelines before creating or choosing premade cables.

• Visit the product pages to download the latest firmware, document version,

additional documentation, and configuration tools.

Basic Wiring Diagram

EX-100-IW-USBC Quickstart Guide | 241002

section for important wiring

wyrestorm.com

In the Box

1x EX-100-IW-USBC Transmitter

1x EX-100-IW-USBC Receiver

1x DC 20V/3A Power Adaptor (US/UK/EU/AU)

1x 2m USB 3.2 Type-C to Type-C Cable

1x Wall Plate Plastic Panel (1-gang US) with Screws

2x Mounting Bracket with Screws

1x Quickstart Guide (This Document)

INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)

1 of 4

Quickstart Guide

support@wyrestorm.com

Need help?

Do you have a question about the EX-100-IW-USBC and is the answer not in the manual?

Page 1 100m USB 3.2 Single Gan In-Wall HDBT 3.0 Transmitter and Receiver Kit EX-100-IW-USBC Quickstart Guide WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation Requirements 1x EX-100-IW-USBC Transmitter •...
Page 2 DC 20V Connect to the 20V power adapter USB3 Link Connect to the receiver for USB transmission Copyright © 2024 WyreStorm ProAV Corporation | Copyright © 2024 WyreStorm ProAV Corporation | wyrestorm.com wyrestorm.com INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
Page 3 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the reciever and transmitter. Read through this section in its entirety before running or terminating any wires to ensure proper operation and to avoid damaging the equipment.
Page 4 Safety and Emission CE | FCC | RoHS | RCM | EAC | UKCA Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal use for a period of five (5) years from the date of purchase.
