Page 1 ProLiant ML330 Generation 2 Server Setup and Installation Guide First Edition (August 2001) Part Number 234833-001 Compaq Computer Corporation...
Page 2 © 2001 Compaq Computer Corporation Compaq, the Compaq logo, Compaq Insight Manager, ProLiant, ROMPaq, and SmartStart Registered in U.S. Patent and Trademark Office. CarePaq is a trademark of Compaq Information Technologies Group, L.P. in the United States and other countries.
Page 3: Table Of Contents
Text Conventions......................x Symbols in Text......................xi Symbols on Equipment....................xi Rack Stability ......................xii Important Safety Information ..................xii Getting Help ......................xiii Compaq Technical Support ................xiii Compaq Website....................xiii Compaq Authorized Reseller................xiv Chapter 1 Server Features Standard Hardware Features..................1-3 Drive Positions ....................1-3 Front Panel Components ..................
Page 4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Chapter 2 Overview of Server Installation Selecting a Site......................2-2 Installing the Rack Server ..................2-3 Rack Enabling Option..................2-3 Rack Environment .................... 2-4 Locating Materials ....................2-5 Installation Sequence ....................2-6 Factory-Installed Operating Systems ..............
Page 5 Disaster Recovery..................... 5-9 ROMPaq ........................ 5-10 SmartStart Software....................5-10 SmartStart Diskette Builder ................... 5-11 Compaq Insight Manager..................5-11 Compaq Survey Utility ..................5-12 Compaq Diagnostics Utility................... 5-12 Automatic Server Recovery-2 ................5-13 Power-On Self-Test ....................5-13 Chapter 6 RAID Configuration and Management Introduction to RAID....................
Page 6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Appendix A Regulatory Compliance Notices Regulatory Compliance Identification Numbers............. A-1 Communications Commission Notice..............A-1 Class A Equipment....................A-2 Class B Equipment....................A-2 Declaration of Conformity for Products Marked with the FCC Logo—...
Page 7 Contents vii Appendix E LED Indicators, Switches, and Jumpers LEDs........................E-2 System LEDs ....................E-2 System Board LEDs ..................E-4 Network Controller LEDs................. E-7 Switch Settings ......................E-8 System Configuration Switch Settings ............. E-8 System ID Switch Settings ................E-12 Jumper Settings......................
Page 8: About This Guide
About This Guide This guide is designed to be used as step-by-step instructions for the installation of a Compaq ProLiant ML330 Generation 2 server and as a reference for operation, troubleshooting, and future upgrades. Server Name A generation identifier (G2) located on the front of the server indicates the model of the server purchased.
Page 9: Text Conventions
Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Text Conventions This document uses the following conventions to distinguish elements of text: Keys Keys are displayed in boldface. A plus sign (+) between two keys indicates that they should be pressed simultaneously.
Page 10: Symbols In Text
About This Guide xi Symbols in Text These symbols may be found in the text of this guide. They have the following meanings: WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life. CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information.
Page 11: Rack Stability
Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide This symbol, on an RJ-45 receptacle, indicates a network interface connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle.
Page 12: Getting Help
Compaq Technical Support In North America, call the Compaq Technical Support Phone Center at 1-800-OK-COMPAQ. This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. Outside North America, call the nearest Compaq Technical Support Phone Center.
Page 13: Compaq Authorized Reseller
Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Compaq Authorized Reseller For the name of your nearest Compaq authorized reseller: In the United States, call 1-800-345-1518. In Canada, call 1-800-263-5868. Elsewhere, see the Compaq website for locations and telephone numbers: http://www.compaq.com...
Page 14: Server Features
ProLiant ML330 Generation 2 server is the server you and your business can depend on. And thanks to tools like SmartStart™ for Servers software and Compaq Insight Manager™ management tool, the ProLiant ML330 Generation 2 server is easy to set up and easy to maintain.
Page 15 1-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Server features include: Intel Pentium III processor with 133-MHz front-side system bus Dual-processor capability 128 MB PC133-MHz ECC Registered SDRAM DIMM, upgradable to 4 GB Capacity for five 36.4-GB SCSI hard drives for a maximum of 182 GB...
Page 16: Standard Hardware Features
Server Features 1-3 Standard Hardware Features The following hardware features are standard on the ProLiant ML330 Generation 2 server, unless otherwise noted. Drive Positions The ProLiant ML330 Generation 2 server supports a maximum of seven internal drive bays. Figure 1-2 and Table 1-1 show the drive configuration. Figure 1-2.
Page 17: Front Panel Components
1-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Front Panel Components Figure 1-3 and Table 1-2 show the front panel components, including buttons and LEDs. Figure 1-3. Front panel components Table 1-2 Front Panel Components Item Component...
Page 18: Rear Panel Connectors
Server Features 1-5 Rear Panel Connectors Figure 1-4 and Table 1-3 show the rear panel connectors. Figure 1-4. Identifying rear panel connectors Table 1-3 Rear Panel Connectors Item Connector Item Connector Power cord Serial ports Mouse Parallel port Keyboard RJ-45 Ethernet for NIC USB ports Video...
Page 19: System Board Components
1-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide System Board Components Figure 1-5 and Table 1-4 show the components and connectors of the ProLiant ML330 Generation 2 server system board. Figure 1-5. Identifying system board components...
Page 20: System Board Components
Server Features 1-7 Table 1-4 System Board Components Item Component Item Component Server Feature Board slot (slot 6) USB port connectors PCI slot 5 (32-bit) Mouse connector PCI slot 4 (64-bit) Keyboard connector PCI slot 3 (64-bit) Power supply connector (20-pin) PCI slot 2 (64-bit) Power supply connector (10-pin) PCI slot 1 (64-bit) (for half-length boards)
Page 21: Server Feature Board Components
1-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Server Feature Board Components The following sections detail components and features of the Server Feature Board for both SCSI and ATA models of the ProLiant ML330 Generation 2 server.
Page 22 Server Features 1-9 Server Feature Board (SCSI Model) Figure 1-6 and Table 1-5 show the components of the Server Feature Board for the ProLiant ML330 Generation 2 server with a standard integrated dual-channel Wide Ultra3 SCSI controller. Figure 1-6. Identifying Server Feature Board components (SCSI model) Table 1-5 Server Feature Board Components (SCSI Model) Item...
Page 23 1-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Server Feature Board (ATA Model) Figure 1-7 and Table 1-6 show the components of the Server Feature Board for the ProLiant ML330 Generation 2 server with a standard integrated dual-channel ATA/100 controller.
Page 24: Processors And System Memory
Server Features 1-11 Processors and System Memory Intel Pentium III processor with 133-MHz front-side system bus Dual-processor capability ECC for memory error detection and correction 128 MB PC133-MHz ECC Registered SDRAM DIMM, expandable to 4 GB Support for up to four PC133-MHz ECC Registered SDRAM DIMMs, installed one at a time, in any order Expansion Slots Five expansion slots: one 32-bit PCI slot and four 64-bit PCI slots...
Page 25: Ports/Connectors
Manager, included with the system, must be installed for the Compaq Pre-Failure Warranty to be in effect. When Compaq Insight Manager alerts you that a component may be eligible for Pre-Failure Warranty replacement, follow the onscreen instructions or contact a Compaq authorized service provider in your area. A yellow status indicator on the Compaq Insight Manager control panel signals that a component is in a pre-failure condition and should be replaced.
Page 26: Server Configuration And Management
Compaq Survey Utility—allows you to keep a historical record of server hardware and software changes in a single configuration history file Power-On Self-Test—checks firmware and assemblies during system startup to ensure that the system is functioning properly Integrated ATA RAID Configuration Utility (ATA model)—supports,...
Page 27: Security
1-14 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Security Security features for the ProLiant ML330 Generation 2 server include: Power-on password Administrator password Network server mode Diskette write control Quicklock Redundant ROM support Most security features are established through RBSU. See Chapter 5, “Server Configuration and Utilities,”...
Page 28: Overview Of Server Installation
Overview of Server Installation The following instructions are provided as an overview for first-time installation of your Compaq ProLiant ML330 Generation 2 server. If you have any problems, contact your Compaq authorized reseller. WARNING: To reduce the risk of electric shock or damage to the equipment: Do not disable the power cord grounding plug.
Page 29: Selecting A Site
2-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Selecting a Site Make sure that the installation area you select has the following features: A sturdy, level site that includes dedicated and properly grounded (earthed) circuits, air conditioning, and ESD protection 7.6 cm (3.0 inches) clearance on all sides of tower server for proper...
Page 30: Installing The Rack Server
Figure 2-1. The ProLiant ML330 Generation 2 server installed into a rack To purchase the rack enabling kit (Part Number 238547-B21), contact your local Compaq authorized reseller. A selection of racks for your server can be purchased through your Compaq authorized reseller or online at http://www.compaq.com/storage/...
Page 31: Rack Environment
Compaq servers draw in cool air through the front door of the rack and expel warm air through the rear door. Therefore, the front door must be adequately...
Page 32: Locating Materials
Overview of Server Installation 2-5 Compaq 9000 Series racks provide proper server cooling from flow-through perforations, ensuring 64 percent open area for ventilation. Refer to the rack documentation provided with Compaq 7000 Series racks for guidelines on meeting airflow requirements.
Page 33: Installation Sequence
2-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installation Sequence Observe the following cautions before beginning any installation procedures: CAUTION: If your server has a factory-installed operating system, prevent data loss by configuring the server using the instructions in the following section, “Factory-Installed Operating Systems.”...
Page 34 Compaq Management CD. For Compaq Management CD initialization procedures, refer to the Server Setup and Management pack shipped with your server. IMPORTANT: You must install and use Compaq Insight Manager to benefit from the Compaq Pre-Failure Warranty on processors, hard drives, and memory modules.
Page 35: Operating Systems Purchased Separately
2-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide 6. After verifying your server configuration, back up your system configuration. Refer to the System Configuration Utility menu on the SmartStart CD for further information on backing up your system configuration.
Page 36 Server Setup and Management pack shipped with your server. IMPORTANT: You must install and use Compaq Insight Manager to benefit from the Compaq Pre-Failure Warranty on processors, hard drives, and memory modules. 9. Install any application software needed.
Page 37: Configuring The Server
2-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Configuring the Server The server setup utility, RBSU, can be used to configure the server and options. To initiate RBSU, press the F9 key when prompted during start up.
Page 38: Hardware Options Installation
Hardware Options Installation This chapter provides procedures for installing, removing, and replacing hardware options for the Compaq ProLiant ML330 Generation 2 server. WARNING: There is a risk of personal injury from hazardous energy levels. The installation of options and the routine maintenance and service of this product...
Page 39: Preparing The Server
3-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Preparing the Server Powering Down the Server Before installing or removing any options, prepare your server by following these steps: CAUTION: Failure to follow these instructions could result in damage to equipment or loss of information.
Page 40: Removing The Front Bezel
Hardware Options Installation 3-3 Removing the Front Bezel To remove the front bezel: CAUTION: To prevent damage to equipment or loss of information, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet before removing the front bezel.
Page 41: Removing The Access Panel
3-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Removing the Access Panel To remove the access panel: WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching them.
Page 42: Removing Bezel Blanks
Hardware Options Installation 3-5 Removing Bezel Blanks When installing a device into a removable media bay, it is sometimes necessary to remove the corresponding bezel blank from the front bezel. To remove a bezel blank: CAUTION: To prevent damage to equipment or loss of information, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet before removing the front bezel.
Page 43: Removing A Drive Tray
3-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Removing a Drive Tray NOTE: The drive trays in the removable media bays can be used to mount internal 3.5-inch hard drives. The rails mounted inside the drive trays can be removed and used to mount other devices in the removable media bays.
Page 44: Storage Devices
Hardware Options Installation 3-7 Storage Devices This section covers removal and replacement procedures for the storage devices supported by the ProLiant ML330 Generation 2 server. See Chapter 1, “Server Features,” for the location and dimensions of the server drive bays, before installing a device. CAUTION: To prevent damage to equipment or loss of information, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed)
Page 45: Installing A Hard Drive
3-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Hard Drive To install a 3.5-inch hard drive: 1. Follow the steps in “Removing the Access Panel” earlier in this chapter. 2. Disconnect the power and data cables from the back of all devices located in the hard drive compartment.
Page 46 Hardware Options Installation 3-9 5. If applicable, remove all terminating jumpers from third-party SCSI devices (Compaq SCSI cables are terminated). NOTE: Using a non-Ultra3 drive impacts the SCSI bus performance of the ProLiant ML330 Generation 2 server. 6. Slide the drive into the drive bay...
Page 47: Removing A Hard Drive
3-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Removing a Hard Drive To remove a 3.5-inch hard drive: 1. Follow the steps in “Removing the Access Panel” earlier in this chapter. 2. Disconnect the power and data cables from the back of all devices in the hard drive compartment.
Page 48 Hardware Options Installation 3-11 3. Remove the three shipping screws, press the tabs on each side of the drive compartment, and then pull the drive compartment from the chassis as shown in Figure 3-5. 4. Remove the two screws on each side of the drive , and then gently pull the drive out of the drive bay as shown in Figure 3-9.
Page 49: Installing A Hard Drive Into A Removable Media Bay
3-12 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Hard Drive into a Removable Media Bay IMPORTANT: If you are installing a hard drive into a removable media drive bay, you must use a drive tray. Drive trays are found in each removable media bay. See “Removing a Drive Tray”...
Page 50 Hardware Options Installation 3-13 4. Slide the drive tray into the removable media bay , and then secure , as shown in Figure 3-11. with a screw on each side of the drive tray Figure 3-11. Installing a hard drive into a removable media bay 5.
Page 51: Installing A Tape Drive
3-14 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Tape Drive IMPORTANT: When installing a tape drive, remove the rails included in the drive tray and install them onto the tape drive, replacing any existing rails. The rails are secured to the drive tray with two screws on each rail.
Page 52 Hardware Options Installation 3-15 4. Slide the drive into the drive bay, as shown in Figure 3-12. Figure 3-12. Installing a tape drive 5. Connect the data and power cables to the back of the drive, as instructed in Chapter 4, “Cabling Guidelines.” 6.
Page 53: Installing A Device Into A Removable Media Bay
3-16 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Device into a Removable Media Bay All ProLiant ML330 Generation 2 server models ship standard with four removable media bays. The top 5.25-inch bay is occupied by an IDE CD-ROM drive.
Page 54: Removing A Hard Drive Or Other Device From A Removable Media Bay
Hardware Options Installation 3-17 Removing a Hard Drive or Other Device from a Removable Media Bay To remove a device from a removable media bay: 1. Follow the steps in “Removing the Access Panel” at the beginning of this chapter. 2.
Page 55: Installing An Expansion Board
3-18 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing an Expansion Board Figure 3-14 and Table 3-1 identify the location of expansion slots. Figure 3-14. Locating expansion slots Table 3-1 Expansion Slots Item Slot Type Slot Number...
Page 56 Hardware Options Installation 3-19 To install an expansion board: CAUTION: Electrostatic discharge (ESD) can damage electronic components. Make sure that you are properly grounded (earthed) before beginning any installation procedure. See Appendix B, “Electrostatic Discharge,” for more information. 1. Follow the steps in “Removing the Access Panel” earlier in this chapter. 2.
Page 57 3-20 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide 3. Release the expansion board retainer by loosening the screw pivoting the retainer back towards the front of the chassis , as shown in Figure 3-16. Figure 3-16. Releasing the expansion board retainer IMPORTANT: Be sure to insert expansion boards into the appropriate type of expansion slot.
Page 58: Memory Modules
Hardware Options Installation 3-21 5. Connect any cables to the expansion board. 6. Reinstall the expansion board retainer by reversing step 3. To remove an expansion board, reverse steps 1 through 5. Memory Modules Technical Information and Important Guidelines CAUTION: To prevent damage to equipment or loss of information, make sure that the server is powered down, all cables are disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed) AC outlet before removing the access panel.
Page 59: Installing A Memory Module
3-22 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Memory Module The ProLiant ML330 Generation 2 server supports PC133-MHz ECC Registered SDRAM DIMMs. Additional DIMMs are available to upgrade the memory. The server has four DIMM sockets located on the system board.
Page 60 Hardware Options Installation 3-23 To install a DIMM: 1. Follow the steps in “Removing the Access Panel” at the beginning of this chapter. 2. Press outward on both latches of the DIMM socket at the same time 3. Insert the DIMM into the socket CAUTION: A DIMM can be installed only one way or damage will result.
Page 61: Removing A Memory Module
3-24 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Removing a Memory Module To remove a DIMM: 1. Follow the steps in “Removing the Access Panel” at the beginning of this chapter. 2. Press outward on both latches of the DIMM socket at the same time This releases the DIMM and pushes it partially out of the socket.
Page 62: Processors And Ppms
Hardware Options Installation 3-25 Processors and PPMs The ProLiant ML330 Generation 2 server comes standard with an Intel Pentium III processor. Its corresponding PPM is integrated on the system board. An optional processor and PPM can be installed. WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching them.
Page 63: Installing A Processor
3-26 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Installing a Processor IMPORTANT: Both processors must be the same speed. 1. Verify that all critical data has been backed up. 2. Ensure that your server has the most current ROM version. To update your ROM, visit the Compaq website at http://www.compaq.com/support/files/server/us/...
Page 64: Processor Sockets And Ppm
Hardware Options Installation 3-27 5. Locate the processor sockets and PPM slot as shown in Figure 3-22 and Table 3-2. Figure 3-22. Locating the processor sockets and PPM slot Table 3-2 Processor Sockets and PPM Slot Item Description Processor socket 1 (populated) Processor socket 2 PPM 2 slot Note: The PPM for Processor 1 is integrated on the system board.
Page 65 3-28 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide 6. Raise the processor socket lever , and then place the processor into the socket , as shown in Figure 3-23. The guide posts and directional key marks on the socket must be aligned with the corresponding slots and marks on the processor.
Page 66 Hardware Options Installation 3-29 8. Secure the heatsink retainer clip on the back of the processor to the socket, as shown in Figure 3-25. Figure 3-25. Securing the heatsink retainer clip 9. Secure the assembly clip on the front side of the processor to the socket , and then lock the processor into place by pressing down on the assembly clip lever...
Page 67: Installing The Ppm For Processor 2
11. Reinstall the internal fan baffle by reversing step 4. Installing the PPM for Processor 2 Each Intel Pentium III processor supplied by Compaq comes with a PPM (DC-to-DC converter). The PPM must be installed into the slot adjacent to its processor to provide power to that processor.
Page 68: Removing A Processor
Hardware Options Installation 3-31 Removing a Processor 1. Follow the steps in “Removing the Access Panel” at the beginning of the chapter. 2. Remove the internal fan baffle. See step 4 of “Installing a Processor” for instructions. 3. Locate the processors and PPM as shown in Figure 3-22 and Table 3-2. 4.
Page 69: Removing The Ppm For Processor 2
3-32 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Removing the PPM for Processor 2 To remove the PPM, open the latches of the PPM slot , and then remove the PPM from the slot NOTE: The PPM for Processor 1 is integrated on the system board and cannot be removed.
Page 70: Replacing Batteries
When replacing a battery, use a CR2032 three-volt lithium coin cell battery. After you have completed the battery installation, run RBSU (by pressing the F9 key) to reconfigure your system. See Chapter 5, “Server Configuration and Utilities,” or the Compaq ROM Based Setup Utility User Guide, for more information on RBSU.
Page 71 5. Replace the server access panel and connect cables to the server. 6. Run RBSU to reconfigure your system by pressing the F9 key when prompted during server startup. See Chapter 5, “Server Configuration and Utilities,” or the Compaq ROM Based Setup Utility User Guide, for more information on RBSU.
Page 72: Replacing The Server Feature Board Battery
6. Replace the access panel, and then connect cables to the server. 7. Run RBSU to reconfigure your system by pressing the F9 key when prompted during server startup. See Chapter 5, “Server Configuration and Utilities,” or the Compaq ROM Based Setup Utility User Guide, for more information on RBSU.
Page 73: Cabling Guidelines
This chapter is an overview of the cabling that resides in the system chassis of a Compaq ProLiant ML330 Generation 2 server. Information on how to cable SCSI and ATA devices in the system, as well as information about all critical system cabling, is provided.
Page 74: Scsi Cabling
“ATA Cabling,” for information on cabling ATA models. IMPORTANT: ATA models with a SCSI option card require a SCSI cable not included with the option kit. Refer to the Compaq ProLiant ML330 Generation 2 Cabling Guide for cable information specific to your model.
Page 75: Identifying Scsi Components
Cabling Guidelines 4-3 Identifying SCSI Components SCSI Cable Components The SCSI cable shown in Figure 4-1 supports up to five SCSI devices and comes with a terminator on the end. One cable is included with SCSI models of the server. Figure 4-1.
Page 76: Internal Scsi
4-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Internal SCSI Components Before cabling devices, note the removable media and hard drive compartment locations, shown in Figure 4-2 and Table 4-1. For information about installing optional SCSI devices, refer to Chapter 3, “Hardware Options Installation,” or the documentation included with the device.
Page 77 Cabling Guidelines 4-5 68-to-50 pin SCSI Adapter If installing a device that uses a Fast SCSI-2 interface, you must provide a 68-to-50 pin SCSI adapter (Part Number 199618-001), shown in Figure 4-3. This adapter should be installed between the 50-pin interface on the device and the 68-pin SCSI cable connected to the SCSI channel on the Server Feature Board.
Page 78: Cabling Scsi Devices
Board. If installing a tape drive, locate the cable connected to the secondary channel. NOTE: Compaq recommends connecting a tape drive to a separate SCSI cable to avoid a decrease in other SCSI device performance. 4. Install the next available connector on the cable to the hard drive or SCSI device.
Page 79: Cabling A Smart Array Controller
Cabling Guidelines 4-7 Cabling a Smart Array Controller Many configurations are possible when multiple SCSI controllers are added. This section outlines the cabling procedure for an installed Smart Array Controller. Refer to the Smart Array Controller option documentation for further installation information. The following steps outline the cabling procedure for the Smart Array Controller: 1.
Page 80 4-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide 5. Connect the SCSI cable to the Smart Array Controller. Figure 4-6. Connecting the SCSI cable to the Smart Array Controller NOTE: The SCSI channels on the Server Feature Board are self-terminating. If you choose...
Page 81: Ata Cabling
SCSI models. IMPORTANT: ATA models with a SCSI option card require a SCSI cable not included with the option kit. Refer to the Compaq ProLiant ML330 Generation 2 Cabling Guide for cable information specific to your model.
Page 82: Identifying Ata Components
4-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Identifying ATA Components ATA Cable Components The ATA cable shown in Figure 4-7 supports up to two ATA devices. Two cables are included with ATA models of the server.
Page 83: Internal Ata Components
Cabling Guidelines 4-11 Internal ATA Components Before cabling devices, note the removable media and hard drive compartment locations, shown in Figure 4-8 and Table 4-3. For information about installing optional ATA devices, refer to Chapter 3, “Hardware Options Installation,” or the documentation included with the device.
Page 84: Cabling Ata Devices
4-12 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Cabling ATA Devices The following steps detail the procedure for connecting cables from an integrated ATA/100 controller to an internal ATA hard drive or other device: 1. Install the device. Refer to “Installing a Hard Drive” or “Installing a Device into a Removable Media Bay,”...
Page 85: Cabling An Atapi Tape Drive
Cabling Guidelines 4-13 4. Install the next available power connector to the hard drive or ATA device. Cabling an ATAPI Tape Drive The following steps detail the procedure for cabling an optional ATAPI tape drive: 1. Install the tape drive into removable media bay 2 by following steps 1 through 5 under “Installing a Tape Drive”...
Page 86: Server Configuration And Utilities
Chapter Server Configuration and Utilities This chapter provides information about the following utilities and support tools included with your Compaq ProLiant ML330 Generation 2 server: ROM Based Setup Utility (RBSU) Redundant ROM support ROMPaq SmartStart software SmartStart Diskette Builder Compaq Insight Manager...
Page 87: Rom Based Setup Utility
In addition, RBSU includes other features, which are outlined in “Using RBSU” later in this chapter. For information on RBSU not found in this guide, refer to the Compaq ROM Based Setup Utility User Guide found in your documentation pack.
Page 88: Using Rbsu
Server Configuration and Utilities 5-3 Using RBSU NOTE: Most of the features in RBSU are not required in the setup of your server. The options in this utility are designed to assist with specific server configuration issues. RBSU is separated into a series of menu selections designed to configure specific areas of the system.
Page 89 5-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Diskette Write Control allows the user to configure the write control of the diskette drive. It can be set to read and write or to read only. Diskette Boot Control enables you to have the system boot from the removable media device.
Page 90 Server Configuration and Utilities 5-5 Server Passwords The Server Passwords menu configures the password environment of the server. The available options are: Set Admin Password sets a password to control access to the administrative features of the server. When this password is set, the administrative features of the server cannot be accessed without the correct password being entered.
Page 91 5-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Server Asset Text The Server Asset Text menu customizes the system-specific text for the server, including the following: Set Server Information Text defines reference information for the server, such as Server Name, Server Asset Tag, Server Primary OS, and Other Text.
Page 92: Redundant Rom Support
The Utility Language option is used to set the language in which RBSU is displayed. Redundant ROM Support Compaq ProLiant ML330 Generation 2 servers enable you to upgrade or configure your ROM safely with redundant ROM support. The server has a 2-MB ROM that acts as two, separate 1-MB ROMs. In the standard implementation, one side of the ROM contains the current ROM program version, while the other side of the ROM contains the backup version.
Page 93: Access To Redundant Rom Settings
5-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Access to Redundant ROM Settings Use ROMPaq utilities to create a backup ROM image before upgrading the configuration or to restore saved ROM data. 1. Access RBSU by pressing the F9 key when the prompt displays in the lower right corner of the screen during power up.
Page 94: Disaster Recovery
Server Configuration and Utilities 5-9 Disaster Recovery If both the current and backup versions of the ROM are corrupt: 1. Create a new ROMPaq diskette using your SmartStart for Servers CD. See “SmartStart Diskette Builder” later in this chapter for instructions. IMPORTANT: If the ROM is corrupted by a ROMPaq interruption, the initial ROMPaq attempt may have affected the contents of the original diskette.
Page 95: Rompaq
5-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide ROMPaq Using flash ROM in Compaq servers allows the firmware (BIOS) to be upgraded with system or option ROMPaq utilities. To upgrade the BIOS, insert a ROMPaq diskette into the diskette drive, remove power from the system, and then power up the system again.
Page 96: Smartstart Diskette Builder
Compaq Insight Manager is the Compaq application for easily managing network devices. Compaq Insight Manager delivers intelligent monitoring and alerting as well as visual control of your Compaq devices, and includes the following functions: Forwards server alerts and fault conditions...
Page 97: Compaq Survey Utility
5-12 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Compaq Survey Utility Compaq Survey Utility is an online information-gathering agent for Microsoft Windows, Novell NetWare, and Linux that collects critical hardware and software information from various sources. If a significant change occurs between data-gathering intervals, the previous information is marked, and the data file is overwritten to reflect the latest configuration and changes.
Page 98: Automatic Server Recovery-2
ABEND (abnormal end), or panic. A system failsafe timer, the ASR-2 timer, is started when the Compaq System Management driver, also known as the health driver, is loaded. The timer is reset periodically during normal operation, but in the event of operating system failure, the timer expires and restarts the server.
Page 99: Raid Configuration And Management
RAID Configuration and Management This chapter provides an overview of the Integrated ATA RAID Configuration Utility that comes standard with ATA models of the Compaq ProLiant ML330 Generation 2 server. Introduction to RAID Overview of RAID Redundant array of independent drives (RAID) is an array of multiple independent hard drives that can be accessed simultaneously, improving I/O (input/output) performance.
Page 100: Raid Terminology
6-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide RAID Terminology IMPORTANT: Only RAID levels 0, 1, and 0+1 are supported by the Integrated ATA RAID Configuration Utility. RAID 0 (Stripe) RAID 0 is a RAID level that involves breaking up data into smaller blocks and then writing a block to each drive in the array (striping).
Page 101: Integrated Ata Raid Configuration Utility
RAID Configuration and Management 6-3 Integrated ATA RAID Configuration Utility The Integrated ATA RAID Configuration Utility is a standard feature of ATA models of the ProLiant ML330 Generation 2 server. The following sections detail the features of the utility, including how to access and change utility options.
Page 102: Using The Configuration Utility
6-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Using the Configuration Utility After all hard drives have been installed and connected, press the F8 key during startup to run the Integrated ATA RAID Configuration Utility and view the setup screen.
Page 103 RAID Configuration and Management 6-5 Help The Help window displays hints on available options and provides a list of keys that you can use to perform tasks, such as: Switch Windows (TAB)—switches the control back and forth between the Array Information and the Physical Drive Information windows. Auto Configure RAID 0 (F1)—automatically creates and configures a striped array based on the available physical drives installed.
Page 104 6-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Drive Size—displays the size of the array and cannot be edited. If the array type is stripe, then the drive size is the total of all the drives selected. When mirror, drive size is shown by individual drive.
Page 105: Troubleshooting
RAID Configuration and Management 6-7 Troubleshooting Drive Connection Tips 1. If you have two drives, connect one per channel. The performance of the array is best with one drive per channel. 2. Use the same type of drives or drives with similar capability (in terms of speed and capacity).
Page 106: Regulatory Compliance Notices
Numbers For the purpose of regulatory compliance certifications and identification, your server is assigned a Compaq series number. The Compaq series number for the Compaq ProLiant ML330 Generation 2 server is Series ES1022. The series number can be found on the product label, along with the required approval markings and information.
Page 107: Class A Equipment
A-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide The rating label on the device shows which class (A or B) the equipment falls into. Class B devices have an FCC logo or FCC ID on the label. Class A devices do not have an FCC logo or FCC ID on the label.
Page 108: Declaration Of Conformity For Products Marked With The Fcc Logo-United States Only
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
Page 109: Mouse Compliance Statement
A-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Mouse Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 110: Japanese Notice
Regulatory Compliance Notices A-5 Japanese Notice Taiwanese Notice...
Page 111: Battery Replacement Notice
A-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Battery Replacement Notice Your server is provided with a lithium manganese dioxide battery. There is a danger of explosion and risk of personal injury if the battery is incorrectly replaced or mistreated.
Page 112: Laser Compliance
Laser Compliance The CD-ROM drive contains a laser diode of gallium aluminum arsenide (GaAlAs) emitting in the wavelength range of 780 ± 35 nm. All Compaq systems equipped with a laser device comply with safety standards, including International Electrotechnical Commission (IEC) 825. With specific regard to the laser, the equipment complies with laser product performance standards set by government agencies as a Class 1 laser product.
Page 113: Power Cords
A-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Power Cords If you were not provided with a power cord for your server, you should purchase a power cord that is approved for use in your country. The power cord must be rated for the product and for the voltage and current marked on the electrical ratings label of the product.
Page 114: Electrostatic Discharge
Appendix Electrostatic Discharge To prevent damaging the system, be aware of the precautions you must follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices.
Page 115: Grounding Methods
B-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Grounding Methods There are several methods for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis.
Page 116: Server Error Messages
Appendix Server Error Messages The following POST error message is new to the Compaq ProLiant ML330 Generation 2 server: Table C-1 POST Error Message Error Code Audible Probable Source of Action Beeps Problem A processor thermal None Processor X (1 or 2)
Page 117: Appendix D Troubleshooting
Appendix Troubleshooting This appendix provides specific troubleshooting information for the Compaq ProLiant ML330 Generation 2 server. Use it to diagnose server startup and installation problems. For information on LEDs, switch settings, and jumpers, see Appendix E, “LED Indicators, Switches, and Jumpers.”...
Page 118: When The Server Does Not Start
D-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide This appendix includes the following topics: When the Server Does Not Start You are provided with step-by-step instructions on what to try and where to go for help with the most common problems encountered during initial Power-On Self-Test (POST).
Page 119: When The Server Does Not Start
NOTE: If the server is rebooting repeatedly, verify that the system is not restarting due to an Automatic Server Recovery-2 (ASR-2) powerup caused by another problem. Check Compaq Insight Manager for notification of this event. Refer to the Compaq Servers Troubleshooting Guide for more information.
Page 120 D-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide 4. Restart the server. 5. Check for the following “normal power-up sequence” to verify that your system meets the minimal hardware requirements and is powered up under normal operation: a.
Page 121: Diagnosis Steps
If yes, video is available for diagnosis. Determine next action by observing POST progress and error messages. Refer to the Compaq Servers Troubleshooting Guide for a complete description of each POST error message. Note: If your server attempts to load the operating system, go to “Problems After Initial...
Page 122: Front Panel Power-On/Standby
D-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Table D-2 Front Panel Power-On/Standby LED Is Not On WARNING: To reduce the risk of electric shock or damage to the equipment, before opening access panels to reseat components, power down the server, and then disconnect the power cord.
Page 123: Server Does Not Have
POST error messages. Check the diagnostic LEDs on the system board for failure conditions. Refer to “Video Problems” in the Compaq Servers Troubleshooting Guide. If these steps do not correct the problem, contact your Compaq authorized service provider for further technical support.
Page 124: Problems After Initial Startup
NOTE: If the server is rebooting repeatedly, verify that the system is not restarting due to an Automatic Server Recovery-2 (ASR-2) powerup caused by another problem. Check Compaq Insight Manager for notification of this event. Refer to the Compaq Servers Troubleshooting Guide for more information.
Page 125: Problems After Initial
Check the SmartStart release notes and user cannot load SmartStart is being documentation. SmartStart. installed. Refer to the Compaq website to verify the version of SmartStart. The CD-ROM/diskette Press the F9 key to run the ROM Based Setup Utility drive assembly is not (RBSU).
Page 126 CAUTION: The Compaq System Erase Utility causes the loss of all configuration information, as well as loss of existing data on all connected hard drives. Read “Compaq System Erase Utility” and the associated cautionary statements in the Compaq Servers Troubleshooting Guide before performing this operation.
Page 127: Other Information Resources
Troubleshooting Guide the scope of this document. It includes general hardware and software troubleshooting information for all Compaq ProLiant servers, a complete list of error messages along with an explanation of probable cause, and a list of appropriate measures. This guide ships with your server.
Page 128: Led Indicators, Switches, And Jumpers
Appendix LED Indicators, Switches, and Jumpers This appendix provides information on LED statuses, switch settings, and jumper settings for Compaq ProLiant ML330 Generation 2 servers. This appendix includes the following topics: LEDs There are several LEDs located on the front, the back, and the inside of your server.
Page 129: Leds
E-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide LEDs A variety of LEDs is located on the front and back of your server. These LEDs aid you in diagnosing problems by communicating the status of the components and operations of the server. The following ProLiant ML330 Generation 2 server LEDs are explained in this appendix.
Page 130 LED Indicators, Switches, and Jumpers E-3 See Figure E-1 and Table E-1 for an explanation of each possible LED status. Figure E-1. Power button and system LEDs Table E-1 Power Button and System LEDs Item Description Status Means Power button Power On/Standby LED Green System on, AC power OK.
Page 131: System Board Leds
E-4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide System Board LEDs The following LEDs are located on the system board of the ProLiant ML330 Generation 2 server and indicate error conditions, such as processor, PPM, or memory module failures. Table E-2 provides detailed information for all system board LEDs Figure E-2.
Page 132: Ac Power
LED Indicators, Switches, and Jumpers E-5 Table E-2 System Board LEDs Item Description Status Means AC power The AC power cord is not plugged into the power supply or the power supply failed Green Power supply is on and functioning Processor 1 thermal Processor 1 temperature normal Amber...
Page 133 E-6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Table E-2 System Board LEDs continued Item Description Status Means Temperature threshold Temperature is normal Amber Temperature threshold exceeded Server Feature Board Server Feature Board is installed installation failure...
Page 134: Network Controller Leds
If the server is linked to the network The speed at which the network is being accessed If there is current network activity Refer to the Compaq Servers Troubleshooting Guide for more information on troubleshooting network controller problems. Figure E-3. Network controller LEDs...
Page 135: Switch Settings
E-8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Switch Settings The ProLiant ML330 Generation 2 server contains two switchbanks. This section explains the use of each reserved and nonreserved switch System Configuration Switch Settings The system configuration switchbank is located on the system board. Some switches are reserved for use by Compaq authorized service providers and must not be changed unless instructed otherwise.
Page 136 On = When the server is powered up, all system configuration information is erased Reserved Reserved Note: Switch positions 7 and 8 are reserved for Compaq authorized service providers only. Do not change the specified default setting for these positions, unless instructed otherwise.
Page 137 E-10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Resetting System Configuration Settings It may be necessary at some time to clear and reset system configuration settings. When the system configuration switch position 6 is set to the on...
Page 138 LED Indicators, Switches, and Jumpers E-11 Redundant ROM Settings IMPORTANT: Switching ROM images can also be done through RBSU. Use the following procedures when RBSU is inaccessible. For information on accessing redundant ROM options through RBSU, as well as disaster recovery procedures, see Chapter 5, “Server Configuration and Utilities.”...
Page 139: System Id Switch Settings
E-12 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide System ID Switch Settings The system ID switchbank, located on the system board, is reserved for use by Compaq authorized service providers only. Do not change the indicated default settings.
Page 140: Jumper Settings
LED Indicators, Switches, and Jumpers E-13 Jumper Settings SCSI Device Jumper Settings No two SCSI devices connected to the same SCSI controller can have the same SCSI ID. If another SCSI device is connected to the same controller, check its SCSI ID before beginning the installation procedure for the additional device.
Page 141: Appendix F Specifications
Appendix Specifications This chapter provides detailed, specific information for the operation of your Compaq ProLiant ML330 Generation 2 server, including: Server specifications Dimensions Power requirements Temperature requirements Minimum hardware configuration Supported operating systems Drivers...
Page 142: Server Specifications
F-2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Server Specifications Table F-1 ProLiant ML330 Generation 2 Server Specifications Dimensions Height 42.0 cm (16.5 in) Depth 19.1 cm (7.5 in) Width 51.5 cm (20.25 in) Approximate weight 15.42 kg (34 lb) Input specifications (per power U.S.
Page 143: Minimum Hardware Configuration
At least one slot must be populated with a PC133-MHz ECC Registered SDRAM DIMM. Note: The maximum memory configuration is 4 x 1-GB memory modules. Also refer to the Compaq ProLiant ML330 Generation 2 Server Maintenance and Service Guide at the Compaq website: http://www.compaq.com/support...
Page 144: Supported Operating Systems
Compaq website: http://www.compaq.com/products/servers/platforms/ For the latest information on Linux version and support, log on to the Compaq website: http://www.compaq.com/products/servers/linux.html CAUTION: If your server has a factory-installed operating system, configure the server using the instructions in the Compaq Factory-Installed Operating System Software Installation Guide or data will be lost.
Page 145: Illustrated
Index ASR-2 (Automatic Server Recovery-2) disabling 5-13 access panel overview 5-13 removing power cycling D-3, D-8 caution 3-4, 3-7, 3-21, 3-25, settings 5-4 3-33 assembly clip, processor, illustrated 3-4 illustrated 3-29 overview 3-4 ATA cable See also cabling warning D-6, D-7 illustrated 4-10 replacing 3-4 overview 4-10...
Page 146: Components
2 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide cabling ATA devices 4-9 backing up server 2-8, 3-2 ATA devices, illustrated 4-12 baffle, fan ATAPI tape drive 4-13 removing 3-26 caution 4-1 removing, illustrated 3-26 components, illustrated 4-4,...
Page 147 Index 3 CD-ROM drive Compaq Management CD 2-7, activity LED 1-4 2-9, 5-11 bay dimensions 1-3 Compaq ProLiant ML330 Generation 2 Server bay, locating 1-3 Maintenance and Service eject button 1-4 Guide D-11 troubleshooting D-9 Compaq Servers Troubleshooting Guide D-11...
Page 148 4 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide power supply 1-7 diagnosing problems See rear panel 1-5 troubleshooting Remote Insight 1-7 dimensions RJ-45 Ethernet drive bays 1-3 rear panel 1-5 server F-2 Server Feature Board 1-9, 1-10...
Page 149 Server Feature Board 1-9, illustrated 3-12 1-10 rails 3-14 European Union equipment removing 3-6 compliance A-4 removing, illustrated 3-6 event notification, Compaq Insight Manager D-3, D-8 replacing 3-6 drivers exclamation point symbol xi additional information D-8, expansion board retainer illustrated 3-20...
Page 150 6 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide feature board See Server Feature front panel components 1-4 Board memory 1-11 features minimum requirements F-3 hardware 1-3 network controllers 1-11 server 1-2 overview 1-3 software 5-1 power supply 1-12...
Page 151 A-7 Compaq authorized network controller LEDs E-7 resellers xiv power button E-3 Compaq website address xiii powering up server 2-7 technical support xiii hot surface, warning xii, 3-4, 3-25 installing 3-30 location 3-27 humidity, specifications F-2...
Page 152 8 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide installation Compaq Insight Manager 2-7, Japanese equipment compliance A-5 DIMMs 3-22 jumpers expansion boards 3-19 ATA devices E-13 hard drives 3-8, 3-12 overview E-1 hardware options 3-1 SCSI devices 3-9, 3-16, E-13...
Page 153 Index 9 warning 2-6, 2-8 NMI debug button 1-9, 1-10, 5-7 maintenance and service guide nonvolatile RAM See NVRAM website D-11 notices materials Canadian A-4 locating 2-5 Class A equipment A-2 shipped with server 2-5 Class B equipment A-2 media bays See removable media European Union A-4 bays FCC A-1...
Page 154 10 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide PCI slots See expansion slots power-on password PME See wake support network server mode 5-5 port settings 5-3 Quicklock 5-5 ports See connectors setting 5-5 POST (Power-On Self-Test) Power-On Self-Test See POST...
Page 155 IPL Device Boot Order Compaq ProLiant ML330 menu 5-4 Generation 2 Server keys 5-2 Maintenance and Service menus, listed 5-3 Guide D-11 navigation 5-2 Compaq Servers overview 5-2 Troubleshooting PCI Devices menu 5-4 Guide D-11 saving 5-2 Compaq technical support xiii...
Page 156 12 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide Important Safety ID, setting E-13 Information xii installation guidelines 4-2 maintenance and service guide jumper settings E-13 website F-3 RAID configuration 4-7 System Configuration terminating jumpers 3-9, 3-16 label 3-4...
Page 157 Index 13 Server Feature Board storage, expanding 1-11 battery, replacing 3-35 stripe size 6-5 components 1-8 striping, RAID configurations 6-2 illustrated (ATA model) 1-10 supported operating systems D-8 illustrated (SCSI model) 1-9 switches See system configuration installation failure LED E-6 switch;...
Page 158 14 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide system LEDs System Board AC power E-3 Components 1-7 hard drive E-3 System Board LEDs E-5 illustrated E-3 System Configuration Switch overview E-2 Settings E-9 Power On/Standby E-3 System ID Switch...
Page 159 D-6, system board 1-7 utilities audible D-7 ACU 5-11 batteries 3-33, A-6 ASR-2 5-13 beeps D-7 Compaq Insight defined xi Manager 5-11 electric shock xi, 2-1, 2-6, Erase 5-11 2-8, 3-2, D-6, D-7 overview 5-1 fire A-6...
Page 160 16 Compaq ProLiant ML330 Generation 2 Server Setup and Installation Guide warranty operating systems, Compaq Insight supported F-4 Manager 1-12 rack products 2-3 restrictions 2-7, 2-9, 5-11 ROM images F-4 server features 1-12 ROM updates 3-26 website 1-12, D-11 service and support...

This manual is also suitable for:

Proliant ml330 generation 2

Compaq 234664-002 - ProLiant - ML330T02 Setup And Installation Manual

Table of Contents

Chapter 1 Server Features

Chapter 2 Overview of Server Installation

Chapter 3 Hardware Options Installation

Chapter 4 Cabling Guidelines

Chapter 5 Server Configuration and Utilities

Chapter 6 RAID Configuration and Management

Appendix A Regulatory Compliance Notices

Appendix B Electrostatic Discharge

Appendix C

Appendix D Troubleshooting

Appendix E LED Indicators, Switches, and Jumpers

Appendix F Specifications

Tape Drive

Quick Links

Chapters

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq 234664-002 - ProLiant - ML330T02

Summary of Contents for Compaq 234664-002 - ProLiant - ML330T02

This manual is also suitable for:

Table of Contents
