  • Page 1 XPJ-C641SR-P Startup Guide Unpacking and Assembling Instructions XPJC641SRPE-Q-00...
  • Page 2 Guide. • Please be aware that MUTOH will not be liable in any way for failures or accidents that result from handling or operating the printer according to any procedures other than those set forth in this Guide.

  • Page 3: Table Of Contents

    Table of Contents Safety Precautions Safety Symbols..........5 Electrical shock/ short circuit/ fire hazards .
  • Page 4 Table of Contents Preparations Connecting the power cord and Ethernet cable ....24 Turning on the print and cut machine ......27 Downloading software .

  • Page 5: Safety Precautions

    Provides information that require special attention or should be followed. Note Provides supplemental or reference information. Indicates the link to the reference section. Note For the name of each part marked with warning or caution symbols, see “Before Use” on the XPJ-C641SR-P operation manual.

  • Page 6: Electrical Shock/ Short Circuit/ Fire Hazards

    If foreign objects or liquid accidentally entered the inside of the printer, do not use it. This could result in an electrical shock or fire. Immediately power off the printer and disconnect the power plug from the outlet. Then contact the MUTOH customer support.

  • Page 7: Installation

    Failure to do so could cause slip or damage to the product. Caution At least two people are required for moving Do not tilt the product. this product. When moving, keep the The ink inside the product may spill. MUTOH product level. cannot guarantee that the printer can run properly.

  • Page 8: Handling

    XPJ-C641SR-P Startup Guide Handling Warning Do not sit on or place heavy objects on the product. Failure to do so could result in injury from a fall. Do not touch the moving parts. This could cause injury or damage to the product.

  • Page 9: Ink And Waste Fluid

    This printer is designed to deliver best • Do not disassemble performance by using MUTOH genuine ink. • Do not drop or hit The use of non-genuine ink may affect the printer as well as print quality. This is not This could lead to ink leakage.

  • Page 10: Warning Labels

    Warning labels Warning labels are affixed to the hazardous area of the product. Read and follow the instructions on the labels. In case the warning labels came off or get dirty, please contact your local MUTOH dealer for replacement. ① ②...

  • Page 11: Instruction Labels

    XPJ-C641SR-P Startup Guide Instruction Labels Instruction labels are affixed where special attention for operating this product is required. The contents of each label are shown here. ① ② Type of labels Name / Meaning ① Ink Color Label • Insert the correct color of ink cartridge according to this label.

  • Page 12: Check Before Installation

    XPJ-C641SR-P Startup Guide Check before installation Installation Location Requirements Choose the location which satisfies the requirements below. • The floor must be level • Avoid vibration from the neighboring devices • Low humidity and free from dust • Less chance of temperature and humidity changes •...

  • Page 13: Power Specification

    XPJ-C641SR-P Startup Guide Power Specification The installation site must meet the following power specification: • Input voltage : AC 100V to 120V ± 10% AC 200V to 240V ± 10% • Input frequency : 50/60 Hz ± 1Hz • Input load current : 6.5 A or more...

  • Page 14: Unpacking

    • CPU: Intel (R) Core (TM) i5 or more • Memory: 16 GB minimum • Network: Ethernet network port Note • The OS support period of software supplied from MUTOH conforms to the Microsoft support lifecycle policies. • Please also check the system requirements of your RIP software.

  • Page 15: Unpacking The Machine

    XPJ-C641SR-P Startup Guide Unpacking the machine Caution • At least two people are required for unpacking and moving this machine. • When taking out the machine from the packaging box, remove the plastic sheet wrapped around the machine, then take it out. Failure to do so may cause slip and damage to the machine.
  • Page 16 XPJ-C641SR-P Startup Guide Check that the following items are included. □Machine : 1 □Scroller: 1 □Request for Registration □Startup Guide: □Cleaning stick: 10 & Download English/Japanese 1 each : English/Japanese (this document) □Cable tie : 1 □Cord clamp: 1 □Media guide : 2 □Paper towel : 5...

  • Page 17: Unpacking The Optional Stand

    XPJ-C641SR-P Startup Guide Unpacking the optional stand Open the packaging box and take out each part. Check that the following items are included. □Stand upper frame : 1 □Stand foot : 1 □Stand leg : 1 □Socket head cap screw : 4 □Hex wrench : 1...

  • Page 18: Assembling

    XPJ-C641SR-P Startup Guide Assembling Assembling the main unit and the optional stand 1.Attaching media guides and cable ties Follow these steps to attach the media guides and the cable ties. Attach the media guides. × 2 Attach the supplied cable ties to the position shown in the illustration on the rear side of the machine.
  • Page 19 XPJ-C641SR-P Startup Guide 2.Assembling the optional stand Caution At least two people are required for mounting the machine on the stand. Follow these steps. Assemble the stand. × 4 Lock the casters. • Adjust the position of the rubber feet and place the machine on the stand.
  • Page 20 XPJ-C641SR-P Startup Guide Stand with reinforcement Next follow these steps to assemble the stand. Use the screws to temporarily attach the bracket to the stand frame. • Screw（M5x40）× 4 Move the bracket to the position shown in the illustration. Right side...
  • Page 21 XPJ-C641SR-P Startup Guide Use the screws to attach the fixing plate to the center of the four aluminum frames. • Screw（M5x10）× 4 Note When attaching the fixing plate, the side with large chamfered corner should be upper side. Tighten all the screws that were temporarily attached.

  • Page 22: Removing Protective Materials

    XPJ-C641SR-P Startup Guide Removing protective materials Follow these steps. Remove all the protective materials and tapes attached to the outer side of the machine. Open the front cover. Remove the roller protection sheet. Remove the tape and remove the steel veyor protector.
  • Page 23 XPJ-C641SR-P Startup Guide Remove the tape securing the sheet cutter. Remove the tape securing the contour cutter. • Remove the screw and remove the carriage shipping bracket. • Close the front cover. Important Keep the following parts for reuse. You will need them when transporting this machine.

  • Page 24: Connecting The Power Cord And Ethernet Cable

    XPJ-C641SR-P Startup Guide Preparations Connecting the power cord and Ethernet cable 1.Before connecting the cable • Turn the media fixing handle to lock it. • Check that the knob of the drain tube valve is in the position shown in the illustration.
  • Page 25 XPJ-C641SR-P Startup Guide Connect the power cord to the machine. Secure the power cord to the cord clamp. 1. Pass the power cord through the clamp and push in to close the cord clamp until it clicks. 2. Slide the clamp to the inlet direction.
  • Page 26 XPJ-C641SR-P Startup Guide 3.Connecting an Ethernet cable Connect the Ethernet cable to this product. Secure the Ethernet cable with the cable tie. Connect the Ethernet cable to the LAN port of the networking device like hub or router. Important This product should be used in a LAN environment with Internet access.

  • Page 27: Turning On The Print And Cut Machine

    XPJ-C641SR-P Startup Guide Turning on the print and cut machine Press the power button on this machine. 押す Press • The blue lamp on the panel will light up. • Machine initialization begins. Important Before turning on this machine, make sure •...

  • Page 28: Downloading Software

    MUTOH printers and VerteLith streamlines your workflow. (License purchase required) MUTOH Status Monitor (MSM) must be installed before printing. Once installed, follow the MSM operation manual to do initial setup and machine registration. MUTOH Status Monitor OPERATION MANUAL「Initial Setting」 Important Make sure to use MSM downloaded from MUTOH Club.
  • Page 29 XPJ-C641SR-P Startup Guide On the next screen, click [New Registration] and follow the on-screen instruction to complete user registration. Once completed, go to the download page. Important The activation code displayed during registration is required the first time you start this machine.

  • Page 30: Setup

    XPJ-C641SR-P Startup Guide Setup Setup Flow • Unzip the file downloaded to any location. • Open the folder and double click the setup.exe. The all-in-one installer starts and begins the setup wizard. • Follow the wizard instructions and complete the printer setup. Here is the setup flow.

  • Page 31: Configure Initial Setup Of Vertelith And Machine

    You will need to configure the settings of printer, cutter and various print condition before outputting through VerteLith. Start VerteLith and click [Add Printer]. Configure access settings for MUTOH Club. Enter your user ID (e-mail address) and password, then click [Next]. Enter the VerteLith serial number and authorization code, then click [Next].
  • Page 32 XPJ-C641SR-P Startup Guide Select “Select from the printers on the network” and then click [Find Printer]. Important • Make sure that - the machine is connected to the network. - the machine is turned on. • If the computer and this machine are connected on a different network, select “Add a printer using IP Address”, enter the IP address of the printer, and click [Retrieve].
  • Page 33 XPJ-C641SR-P Startup Guide Enter a name of the print environment and click [Next]. Specify the location of the hot folder. To change, click [Browse] to specify. Important A hot folder is the folder that runs automatic processing on jobs. The hot folder has two subfolders: •...
  • Page 34 XPJ-C641SR-P Startup Guide Specify the standard print settings for the print environment and click [Next]. • To edit the print settings, click [Edit]. Important These settings will be the default for a job added to the print environment. If needed, select the “Allow Auto Nesting” checkbox and click [Next].
  • Page 35 XPJ-C641SR-P Startup Guide Click [Save]. The settings required for printing and cutting are now saved.
