MUTOH XpertJet XPJ-1341SR-P Maintenance Sheet

User maintenance sheet when using UMS21 ink
• Please follow the instructions on this sheet to perform maintenance. Inadequate maintenance
will cause nozzle clogs or damage to the print head or reduce cleaning performance of your
printer.
• When using UMS21 ink, please purchase the designated maintenance cleaner
(VJ-ULVA1-ML500) and maintenance kit (VJ-PH-MAINTKIT).
• Always wear protective gloves during maintenance work to avoid contact with maintenance
cleaner and ink.
《Printer use conditions》
Operating environment
Storage environment
When stored above 32℃: Storage period allowed: up to 4 days
less than a week
a) Run a nozzle check once a week.
Perform cleaning if there are nozzles missing.
If you're not
See the section
using the
operation manual
printer for
over a week
b) If you are unable to perform a)
Use the "Longstore" menu to perform a head washing and then
power off the printer. The storage period with power off must be
up to one month.
See the section "Longstore" in your printer's operation manual
《When to perform maintenance》
Once a week before your work
When this message is prompted on the operation panel
Perform CR Maint.
In case the following problems appear, you should perform maintenance immediately:
・ Nozzle missing or deflection persists even after several cleaning attempts.
・ The accumulated ink sticking to the print head hits a print and causes smears.
・ Nozzle got clogged due to the accumulated ink removed from the print head, causing nozzle
missing or deflection.
CS3024-E-00
Temperature 20℃ to 32℃ Humidity 40％ to 60％
Temperature 5℃ to 40℃ Humidity 20％ to 80％
Power off the printer (when stored below 32℃)
"Nozzle Check" and "Cleaning" in your printer's
XPJ-1341SR-P
Items required:
a. Maintenance cleaner (Optional consumables)
b. Plastic cup
c. Cleaning stick
d. Vinyl gloves
e. Personal goggles
(a) Use the designated cleaner.
Items (b) to (d) are included in the maintenance kit.
Preparations:
Wear protective gloves and goggles.
Pour some maintenance cleaner into the
plastic cup and dip the cleaning stick into the
cleaner.
[If gets dirty during maintenance] Rinse the stick
in the cleaner.
Please contact your local MUTOH dealer for ordering maintenance parts.
Part name
Maintenance cleaner
Maintenance kit
Cleaning stick
Polyester knit wipe
a
c
e
Part number Quantity (per box)
VJ-ULVA1-ML500 1
VJ-PH-MAINTKIT 1
RH2 Clean Stick 100
300
PJ-POLYNITW2
b
d
