Page 1 of 6
ECC0022
FITTING INSTRUCTIONS FOR ECC0022
T
.
HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
S
.
OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
D
.
O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
P
.
LEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
P
LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
I
,
N THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
Racing Technique Ltd T/A R&G
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Related Manuals for R&G ECC0022
Summary of Contents for R&G ECC0022
- Page 1 Page 1 of 6 ECC0022 FITTING INSTRUCTIONS FOR ECC0022 HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
-
Page 2: Tools Required
M12 BOLT = 40Nm LEGEND ITEM NO. DESCRIPTION ITEM 1 ECC0022 ENGINE CASE COVER INCLUDING FITTED SPACERS ITEM 2 M6 x 1.00 x 40mm CAP HEAD BOLTS FITTING DIAGRAM Racing Technique Ltd T/A R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com... -
Page 3: Fitting Instructions
FITTING INSTRUCTIONS Make sure the engine is cold before proceeding to fit the R&G engine case cover. Ensure the pre-fitted threaded spacers in the casing are hand tight against the inside of the ECC0022 • Engine Case Cover (Item 1). - Page 4 Page 4 of 6 ECC0022 NOTICE DE MONTAGE POUR ECC0022 E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS E PAS PROCEDER AU MONTAGE TANT QUE VOUS N...
-
Page 5: Outils Requis
M12 BOULON = 40Nm LÉGENDE ARTICLE NO. DESCRIPTION QTÉ ARTICLE 1 ECC0022 PROTECTION R&G AVEC ENTRETOISES MONTÉES ARTICLE 2 M6 x 1.00 x 40mm BOULONS SCHÉMA DE MONTAGE Racing Technique Ltd T/A R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com... -
Page 6: Notice De Montage
R&G. Assurez-vous que les entretoises filetées préinstallées dans le carter soient serrées à la main contre • l'intérieur du couvercle du carter moteur ECC0022 (article 1). Retirez le bouchon de remplissage d'huile. • Retirez les cinq boulons du carter moteur entourés en orange ci-dessus sur l'image de montage.
