4.Assembly of sensor arrays

NO
1
Wind Cup
2
Solar Panel
3
Wind Vane
4 Bubble Level
5
Thermometer-Hygrometer Sensor
6
Rain Collector

4.1.Parts List

The weather station consists of the following parts.
QTY
Gateway：
Frame Dimensions:
1
3.1x3.1x3.6inch
(78x78*91mm)
Integrated Outdoor
Transmitter Dimensions:
1
12.9x4x9.8inch
(327*101*249mm)
Figure 1
Description
Item
NO
7
Reset Button/LED Indicator
8
Battery Door
9
Mounting Pole Socket
— 4 —
Description
