VEVOR HBZB-36F Original Instruction

VEVOR HBZB-36F Original Instruction

Automatic ice maker
Hide thumbs

Advertisement

Quick Links

Download this manual
Technical Support and E-Warranty Certificate
www.vevor.com/support
AUTOMATIC ICE MAKER
MODEL: HBZB-36F
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to cover
all categories of tools offered by us. You are kindly reminded to verify carefully
when you are placing an order with us if you are actually Saving
Half in comparison with the top major brands.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HBZB-36F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VEVOR HBZB-36F

Summary of Contents for VEVOR HBZB-36F

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support AUTOMATIC ICE MAKER MODEL: HBZB-36F We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 4: Table Of Contents

    CONTENTS IMPORTANT SAFETY................3 SPECIFICATION..................5 DIMENSION/ CONNECTION..............5 RATING....................7 GENERAL INFORMATION..............8 MAIN UNIT CONSTRUCTION..............8 ICE-MAKING AND ITS WATER TANK PARTS........8 OPERATION PANEL................9 EXPLOSIVE DRAWING................11 OPERATING PROCEDURE AND MAINTENANCE........14 UNPACKING YOUR ICE MAKER............14 DOOR REVERSING(Optinal)..............15 INSTALLATION LOCATION REQUIREMENT........17 ELECTRICAL REQUIREMENT & CONNECTIONS......19 CLEANING YOUR ICE MAKER BEFROE FIRST USING....20 WATER CONNECTIONS FOR YOUR ICE MAKER......20 OPERATION YOUR UNIT..............22 OPERATION OF ICE MAKING PROCESS..........22...

  • Page 5: Important Safety

    IMPORTANT SAFETY When using electrical appliances, basic safety precautions should be followed to reduce the risk of fire, electric shock, and injury to persons or property. Read all instructions before using any appliance. Use this appliance only for its intended purpose as described in this owner’s manual.
  • Page 6 the unit. If the unit is brought in from outside in the winter season, give it a few hours to warm up to room temperature before plugging it in. Do not use other liquid to make the ice-cube other than water. Do not clean your ice maker with flammable fluids.

  • Page 7: Specification

    Used . • CAUTION-Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing;Follow Handling Instructions Carefully. Flammable Refrigerant Used. • The ice maker should be installed in accordance with the safety standard for Refrigeration Systems, ASHRAE15. The ice maker shall not be installed in corridors or hallways of public buildings.
  • Page 8 [20.3] [15.0] [16.8] [1.9] [2.1] - 6 -...

  • Page 9: Rating

    2)Rating MODEL HBZB-36F POWER SUPPLY 1Phase, 115V/60Hz VOLTAGE CLAIMATE CLASS SN/N/ST/T ELECTRICAL PROTECTION CLASS ICE MAKING RATING (Amps) ICE HARVEST RATING (Amps) ICE MAKING CAPACITY 36 * (KG/24H) REFRIGERANT CHARGE R290 2.65Oz / 75g NET WEIGHT(lbs) VESICANT UNIT DIMENSIONS(W X D 15x20.3x33.5...

  • Page 10: General Information

    GENERAL INFORMATION 1)Main Unit Construction ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ 1.Door 2.Ice-making & its water tank assembly: Including ice-making evaporator, water tank, water pump and some detecting parts 3.Handle 4.Ice tank 5.Operation panel 6.Air outlet: Must keep the air circulate smoothly, hot air will blow out when unit running.

  • Page 11: Operation Panel

    A.Water dividing pipe: with nine little holes, water will flow out from these little holes. And if no water flows out, can be disassembled and cleaned. B.Evaporator (ice-making module) C.Ice full detecting board: Use to detect the inner cabinet is full of ice or not, and to check the the ice-harvest process is over or not.
  • Page 12 Self-cleaning program, or normal ice-making state, press this button to turn off the unit at once; And also if the unit is set with the Timer, press this button to cancel the Timer setting. When the unit is making the ice cube, press this button for more than 5 seconds, the unit will switch to ice harvest process by force.

  • Page 13: Explosive Drawing

    Display ice making time setting with M as unit display. D&E．“+”/”-”button: Use to adjust the ice-making process duration period length, the default setting is zero, 1 minute adding or decreasing per each pressing of “+” or “-” button. Also to adjust the delay time of the timer, the default setting is zero, 1 hour adding or decreasing per each pressing of “+”...
  • Page 14 Part Name Specifications Door seal Door SUS & Foams Water tank side cover ABS White Float switch Electrical part DC5V Water tank cover ABS White Handle Pump Electrical part AC115V Water Tank ABS White Drain tube for water tank Silicone tube,FDA Water inlet solenoid Electrical part DC12V Filter Dryer...
  • Page 15 Electrical part DC12V 90mm Air outlet panel SUS430 δ=0.8 SPCC δ=2.5mm Chrome Left bottom hinge Plated SPCC δ=2.5mm Chrome Right bottom hinge Plated Adjusted foot M8*30mm Bottom plate Zinc-Plate sheet δ=1.2 Drain tube on liner Silicone tube,FDA Water drainage port ABS Gray,FDA Water drainage cap Rubber Black...

  • Page 16: Unpacking Your Ice Maker

    SPCC δ=2.5mm Top hinge Zinc-plated Top cover ABS Black Screw hole cover ABS Black SPCC δ=2.5mm Fix plate Zinc-plated Water outlet tube form Silicone tube,FDA pump Magnet switch Electrical part DC5V Evaporator frame ABS White Water dividing pipe, eight ABS White holes Cap of the water dividing Silicone,FDA...

  • Page 17: Door Reversing(Optinal)

    sources of heat (i.e.: stove, furnace, radiator). Make sure that there is at least 50cm gap between the air outlet and the obstacles, and at least 5 cm between the wall. 4.Allow 4 hours for the refrigerant fluid to settle before plugging the ice maker in if the unit maybe fall upside down during shipping or transportation.
  • Page 18 which is fix the top cover. 3.Remove the 2 screws from the top hinge, and 2 screws from the fix plate. 4.Lift the door up and take off the door. 5.Set the freezer door on a non-scratching surface with the outside up. 6.Release the 2 screw on the handle, fix on the opposite side of the door.

  • Page 19: Installation Location Requirement

    secure the top hinge on the left with 2 screws. 11. Open and close both the door several times to confirm the door is positioned correctly and the gasket is sealed well. If this is not the case, please adjust the door again. 12.
  • Page 20 b)This unit should not be located near any heat resource. c)The unit should be located on a firm & level foundation at normal counter top height. d)There must be at least a 2-inch clearance at rear side for connection and a 10-inch clearance in the front to open the door and keep good air circulation.

  • Page 21: Electrical Requirement & Connections

    drain fixtures in the recommended locations as shown. Choose a well-ventilated area with temperatures above 50 °F and below 90 °F. This unit MUST be installed in an area protected from the elements, such as wind, rain, water spray, or drips. The ice maker requires a continuous water supply with 1-8 bar pressure as required in above specification table.

  • Page 22: Cleaning Your Ice Maker Befroe First Using

    grounding-type wall receptacle, grounded in accordance with the National Electrical Code and local codes and ordinances. If a mating wall receptacle is not available, it is the personal responsibility of the customer to have a properly grounding wall receptacle installed by a qualified electrician. CLEANING YOUR ICE MAKER BEFROE FIRST USING Before using your ice maker, it is strongly recommended to clean it thoroughly.
  • Page 23 STEP STEP 1: Remove the tape Water inlet port on the unit back Remove the clip first STEP 2:Insert the water tube 1: Remove the tape Then install the r inlet port on the clip back back White water tube(accessory) Remove the clip first Insert water tube inward completely...

  • Page 24: Operation Your Unit

    2.Connecting the water drain pipe Pull out the water drainage cap with black color (indicated ○A above illustration), then connect the white drainage pipe included in accessory, again connect the other end of this drainage to the main water drainage pipeline. 3.

  • Page 25: Operation Of Ice Making Process

    OPERATION OF ICE MAKING PROCESS 1.Start up: Plug in the power plug, and the symbol will flash in the display window. Press the ON/OFF button on the control panel. The machine will start to make ice when the external pipe adds water to reach the standard level on the water tank through the electromagnetic water valve.
  • Page 26 To produce thicker ice, add one minute of ice making time by pressing “+” button once; in contrast, to produce thinner ice, reduce one minute of ice making time by pressing "-" once. Restart the machine and it will go back to the default setting of “0”.
  • Page 27 When the unit has a timing (the display window will display XX H), press“TIMER”button, the timing is canceled after the number on the screen and "H" are extinguished. When the unit has a timing, the display area in the lower left corner will display the timing time and the ice making setting time, and the display content will be switched every 5S.

  • Page 28: Wiring Diagram

    WIRING DIAGRAM Start Relay ELECTRICAL DIAGRAM COMPRESSOR O verload Protector Power VALVE PU MP AC W ater AC-L COMP AC-N Supply Pum p Solenoid Vale for D C Fan M otor Relay Ice-harvest Relay A C Drain Pum p DC Water Inlet Valve M ain C ontrol PCB W ATER W ater Level Detecting...

  • Page 29: Preparing The Ice Maker For Long Storage

    splashing sound. • Water running from the evaporator to the water tank may make a splashing sound. • As each cycle ends, you may hear a gurgling sound due to the refrigerant flowing in your ice maker. • You may hear air being forced over the condenser by the condenser fan. During the harvest cycle, you may hear the sound of ice cubes falling into the ice storage bin.

  • Page 30: Cleaning And Maintenance

    11.Put a plastic bag on the unit to resist out dust & dirty. CLEANING & MAINTENANCE WARNING: Before carrying out any cleaning or maintenance operations, unplug the ice maker from the main power supply electricity. (EXCEPTION: Ice maker self-cleaning program). Do not use any alcohol or fume for cleaning/sanitization of the ice maker.

  • Page 31: Interior Cleaning

    water solution such as 28g of dish washing liquid mixed with 7.5L of warm water. Do not use solvent-based or abrasive cleaners. Use a soft sponge and rinse with clean water. Wipe with a soft clean towel to prevent water spotting.

  • Page 32: Ice Making Parts Cleaning

    DO NOT use solent cleaning agents or abrasives on the interior. These cleaners may transmit taste to the ice cubes, or damage or discolor the interior. Ice Making Parts Cleaning During the using, periodically to clean these main system of your ice-maker.

  • Page 33: Ice Making Assembly System Cleaning By Using Nu-Calgon Nickle Safe Ice-Machine Cleaner

    of the evaporator. 4.For the water tank and ice-full detecting plate Also the water tank and the ice-full detecting plate is very important to keep your ice cube hygienic. Put mixture of neutral cleaner & water into a clean water jet, then spray to all the inner surface of tank & the ice detecting plate. Wipe these surfaces as far as possible with a clean cloth.
  • Page 34 every 6 months. 1.Turn off the ice maker. Keep the ice maker connect to the water supply and drainpipe. But shut off the water faucet of main water supply. 2.Open the door and scoop out all of the ice cubes. Either discard them or save them in an ice chest or cooler.
  • Page 35 5.Turn on the power to the ice maker, then press “TIMER CLEAN”button on control panel for more than 5 seconds, to enter the self-Cleaning program. Same as above explanation, the water pump runs for 8 minutes and stops for 3 minutes, one cycle, again one cycle. The total duration time is 30 minutes for one self-cleaning program.

  • Page 36: Cleaning Suggestion

    9.After one self-cleaning program complete, then pull out the drain pipe of the water tank, drain the cleaning solution down to the lower ice storage bin, also shake the unit slightly to drain out all of the water completely. Then install back the drain pipe to the water tank slot tightly. 10.Repeat the step 8-9 again for 2 times.
  • Page 37 Check the main water supply pressure or check the water No water supply supply hose is blocked or not, adding the water pressure or cleaning the hose necessary. Floating ball of the “ ” indicator is on. water level Clean the water tank and the detecting switch is water level detecting switch.
  • Page 38 Water quality is not good or the Clean the water tank, and water tank is very change with new water. dirty Ice cube shape is irregular The little holes on Clean the water dividing pipe, the water make sure all nine holes are dividing pipe is unclogged some blocked...

  • Page 39: Error Indicator

    ERROR INDICATOR a)Ambient temp sensor breakdown Display E1 in digital window. b)The machine not make ice or the gas leak Display E2 in digital window c)The drain pump dose not work , Display E in digital window(Only for the unit witch have drain tank). d)Magnetic control switch cutoff----“Full”...
  • Page 40 Technical Support and E-Warranty Certificate www.vevor.com/support...
