- Page 1 INSTALLATION INSTRUCTIONS...
- Page 2 For additional information View instructions online ruggedradios.com/instructions Call our Tech Department (888) 541-7223...
-
Page 3: What's Included
Sprinter Radio Kit PAGE What’s included? MOBILE RADIO (P.N. G1) (P.N. G4) (P.N. GMR25) ANTENNA MOUNT COMPATIBILITY: MERCEDES-BENZ SPRINTER OPTION 1 2ND GEN (2007-2018) (P.N. MT-ANT-SPRINTER-1) COMPATIBILITY: ANTENNA MOUNT MERCEDES-BENZ SPRINTER 3RD GEN (2018-PRESENT) OPTION 2 (P.N. MT-ANT-SPRINTER-2) ANTENNA ADAPTER FOR A-PILLAR/DITCH LIGHT (P.N. -
Page 4: Installation
Sprinter Radio Kit PAGE Installation TOOLS NEEDED 7mm Socket Wrench or Phillips Screwdriver 10mm Socket Wrench or Open End Wrench 12mm Socket Wrench 13mm Socket Wrench Small Crescent Wrench STEP 1: INSTALL RADIO MOUNT AND RADIO FIGURE A Locate the U-bracket packaged with your radio and determine an appropriate location to mount it in your vehicle. - Page 5 Sprinter Radio Kit PAGE Installation STEP 2: INSTALL ANTENNA MOUNT FIGURE C Antenna Mount Option 1 (MT-ANT-SPRINTER-1): Open the hood and 13mm Socket Wrench secure it in the open position. Using a remove only the front bolt from the passenger side hood hinge. SEE FIGURE C. Align the front hole on the mount with the hole on the hinge and reinstall the bolt.
- Page 6 Sprinter Radio Kit PAGE Installation STEP 3: RUN CABLING FIGURE F Antenna Coax Cable & Radio Power Cable: Route the antenna coax and power cable from the engine compartment into the cab using the rubber passthrough grommet on the passenger side of the engine compartment under the hood hinge.
- Page 7 This completes your installation. If you have any questions, please contact us at (888) 541-7223. Thank you!
- Page 8 DESIGNED IN ARROYO GRANDE, CA BY ENTHUSIASTS FOR ENTHUSIASTS. THIS PRODUCT IS BACKED BY 30 YEARS OF EXPERIENCE WITH ONE GOAL, CONNECTING PEOPLE. RUGGED RADIOS. #RUGGEDRADIOS #RUGGEDRADIOSLIFESTYLE...
