MTDEVAL
Save Settings to File
Load Settings from File
Set Factory Defaults
Parameter
Set Temperature
Temperature Window
P Share
I Share
D Share
Cycle Time
Current Limit
Temperature Protection Delay
Note
When setting the MTDEVAL to factory defaults, the Critical Gain and Critical Period Duration
are not changed, as these are parameters that shall be defined during the oscillation test.
18
Save actual GUI settings and the device information to a XML
file on the PC.
Note
This function saves the information displayed in the GUI to a
file, not the parameters stored in the MTD415x module!
Load settings from a XML on the PC.
Writes the factory default values (see table below) to the
MTD415x module.
Factory Default
25.000 °C
1000 mK
1.000 A/K
0.200 A/(K*sec)
0.100 (A*sec)/K
50 ms
1.00 A
10 s
