- Page 1 USER AND INSTALLATION MANUAL ENGLISH OMEGA BRACKET. SET OF 2 PART02539 ACCESSORIES REV 01-01...
- Page 2 Should you detect any errors or inaccuracies in the manual, we would be grateful if you would inform us. This helps us to further improve our documentation. MAGICFX OMEGA BRACKET - User and Installation Manual ®...
-
Page 3: Table Of Contents
Technical data 1.3. Product identification 1.4. Accessories Safety 2.1. General safety rules 2.2. Indoor & outdoor use 2.3. Rigging 2.4. Safety symbols 2.5. Safety warnings Installation Troubleshooting Maintenance EC Declaration of Conformity MAGICFX OMEGA BRACKET - User and Installation Manual ®... -
Page 4: Introduction
TARGET GROUP This manual is targeted at authorised personnel in the event industry that install and operate the Omega Bracket (Set of 2). Authorised personnel are those who: • Are appointed by their supervisor to install and/or operate the Omega Bracket (Set of 2). -
Page 5: Abbreviations
Omega Bracket (Set of 2) ® Abbreviations REVISION TABLE Doc nr Revision Date Description Author Approved PART02539 01-00 22-04-2024 Initial release NvdE PART02539 01-01 02-05-2024 Added rigging NvdE notice Updated product label Updated DoC MAGICFX OMEGA BRACKET - User and Installation Manual ®... -
Page 6: Description
DESCRIPTION The Omega Bracket (C-T-C 140 mm) Set of 2 is intended for fastening a wide range of products. In combination with a Quick Trigger or Half Coupler, it is ideal for truss mounting. 1.1. MAIN PARTS QUARTER TURN HANDLE... -
Page 7: Product Identification
Manual (PART02302). SAFETY The Omega Bracket (Set of 2) has been designed and constructed in such a manner that it can be used safely. This applies to the use, the circumstances and the regulations as described in this documentation. Reading this documentation and following the instructions are therefore necessary for everyone who is authorised to work with the Omega Bracket (Set of 2). -
Page 8: General Safety Rules
Do not use the Omega Bracket (Set of 2) if alterations have been made other than by or on behalf of MAGIC FX. • The Omega Bracket (Set of 2) may not be used when damaged or if it has fallen before. •... -
Page 9: Safety Warnings
Bracket (Set of 2) can lead to death, serious injury or property damage. Always inspect the Omega Bracket (Set of 2) thoroughly before operation. Do not use the Omega Bracket (Set of 2) if alterations WARNING have been made other than by or on behalf of MAGIC... -
Page 10: Installation
Doughty Half Coupler (100 kg) M10 Materials needed: • 2× Doughty half coupler (MFX3106) • 2× M10×30 Bolt • 2× M10 Spring washer • 2× M10 Washer • 2× M10 Locknut MAGICFX OMEGA BRACKET - User and Installation Manual ®... - Page 11 Do not mount a machine to the truss sideways with the CAUTION Omega Brackets in combination with Doughty Quick Trigger Clamps. Only suspend the machine from the truss with the Quick Trigger Clamps. MAGICFX OMEGA BRACKET - User and Installation Manual ®...
- Page 12 Make sure the structure intended to hold the machine WARNING is calculated for the weight. Overhead rigging requires extensive experience in calculating load limits, installation materials, and performing periodic safety inspection. Only qualified personnel is allowed to perform this. MAGICFX OMEGA BRACKET - User and Installation Manual ®...
- Page 13 The minimal workload of the safety steel and the CAUTION emergency link needs to be calculated by qualified personnel. The machine depicted is an example. The machine NOTICE you install might differ. MAGICFX OMEGA BRACKET - User and Installation Manual ®...
-
Page 14: Troubleshooting
This may include applying protective coatings or installing additional shielding. Do not replace parts yourself; always consult MAGIC FX DANGER if necessary. MAGICFX OMEGA BRACKET - User and Installation Manual ®... -
Page 15: Ec Declaration Of Conformity
: B. Veroude : B. Veroude Country : The Netherlands : B. Veroude Date : 6-2-2020 Date : 30-04-2024 Date : 6-2-2020 : B. Veroude Date : 6-2-2020 Signature Signature Signature Signature MAGICFX OMEGA BRACKET - User and Installation Manual ®... - Page 16 WWW.MAGICFX.EU...
