- Page 1 USER AND INSTALLATION MANUAL ENGLISH ECO2JET ® Bracket PART02443 ACCESSORIES REV 01-01...
- Page 2 Failure to read the manual and to follow the printed instructions may lead to personal injury and/or damage to the product. © 2024 MAGICFX ® All rights reserved. Nothing from this publication may be copied, reproduced and/or published by means of printing, photocopying or by any other means, without the prior written approval of MAGIC FX.
-
Page 3: Table Of Contents
2.4. Safety symbols 2.5. Safety warnings Installation and use 3.1. Mount the ECO2JET BRACKET ® 3.2. Install on stage 3.3. Mount on a truss Troubleshooting Maintenance EC Declaration of Conformity MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 4: Introduction
Are familiar with and abide by the applicable local, national and international laws and regulations. LANGUAGE This document contains the original instructions in English. In case you require other languages please contact MAGIC FX. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 5: Abbreviations
ABBREVIATIONS Abbreviation Description Special effects ECO2JET MAGICFX ECO2JET ® ® ® ECO2JET Bracket MAGICFX ECO2JET Bracket ® ® ® Abbreviations REVISION TABLE Doc nr Revision Date Description Author Approved PART02443 01-00 19-03-2024 Initial release PART02443 01-01 02-05-2024 Added rigging NvdE... -
Page 6: Description
2× M6 ANGLE ADJUSTMENT HANDLE Main parts The ECO2JET Bracket has additional holes that can be used to securely mount the ® ECO2JET in a fixed position using screws. ® MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 7: Technical Data
Doughty Half Coupler (100 kg) M10 Accessories Please contact MAGIC FX for additional possibilities. For information about the accessories of the ECO2JET (MFX1801), refer to the ® ECO2JET User and Installation Manual (PART02302). ® MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 8: Safety
MAGIC FX is not responsible for any rigging equipment WARNING and accessories provided by third party manufacturers. Verify that the Work Load Limit (WLL) of all additional hardware rigging accessories is respected. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 9: Safety Symbols
5mm holes. ® These holes are designed solely to enhance stability and should not be relied upon as the primary method of support and or hanging. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 10: Installation And Use
ECO2JET Bracket to a truss using the proposed truss ® clamps. 3.1. MOUNT THE ECO2JET BRACKET ® Hold the ECO2JET Bracket in place in vertical position. ® MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... - Page 11 Place the angle plate over the bracket with the hole corresponding with the notch on the ECO2JET ® Insert the M5 mounting bolt and the M6 angle adjustment handle. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®...
-
Page 12: Install On Stage
3.2. INSTALL ON STAGE Loosen the angle adjustment handle. Move the loose ECO2JET Bracket to acquire the desired angle of the ECO2JET ® ® MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 13: Mount On A Truss
• 2× M10 Locknut Mount two Doughty half couplers (MFX3106). Materials needed: • 2× Doughty half coupler (MFX3106) • 2× M10×45 Bolt • 2× M10 Washer • 2× M10 Locknut MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... - Page 14 Always use two clamps in motion truss systems WARNING because of unknown accelerations and decelerations. See options A and B. Mounting with a single clamp positioned at the center NOTICE offers angular flexibility. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®...
- Page 15 Only suspend the ECO2JET Bracket from the ® truss. Take the recoil of the ECO2JET into account. Make sure ® CAUTION the construction is prepared for the counter force of firing the effect. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®...
- Page 16 Make sure that the installation complies with all relevant safety requirements, such as creating a safety zone and a free output zone, see Section 2.5. MAGICFX ECO2JET BRACKET — User and Installation Manual ®...
-
Page 17: Troubleshooting
This may include applying protective coatings or installing additional shielding. Do not replace parts yourself; always consult MAGIC FX DANGER if necessary. MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... -
Page 18: Ec Declaration Of Conformity
Address : Schouwrooij 27, 5281 RE BOXTEL : B. Veroude Date : 6-2-2020 Country : The Netherlands Date : 30-04-2024 : B. Veroude Date : 6-2-2020 Signature Signature Signature Signature MAGICFX ECO2JET BRACKET — User and Installation Manual ® ®... - Page 20 WWW.MAGICFX.EU...
