- Page 1 PX344 Driver LED C.V. 4x1A IP User manual...
-
Page 2: Table Of Contents
4 RDM – available parameters..............7 5 Connection scheme..................10 6 Dimensions....................13 7 Technical data....................14 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description Driver PX344 is designed for voltage control of LED diodes. Built-in DMX receiver allows control of 1 – 4 channels. The device is housed in a housing that provides IP65 protection class, and its programming is done exclusively via the RDM protocol. -
Page 4: Safety Conditions
Safety conditions The PX344 device is powered by a safe voltage of 7 – 24V DC, however, during its installation and use, the following rules must be strictly observed: 1. The device may only be connected to 7 – 24V DC with current-carrying capacity compatible with technical data. -
Page 5: Connectors And Control Elements
Connectors and control elements DMX IN +DMX - DMX Out1/ R Out2/ G Out3/ B Out4/ W +DMX - DMX DMX OUT... - Page 6 For easier cable installation, the control module can be removed.
-
Page 7: Rdm - Available Parameters
RDM – available parameters PX344 supports the DMX – RDM protocol. The DMX protocol is designed to allow unidirectional data flow, while its extension – the RDM protocol can transmit information in two directions. This allows for simultaneous receiving and sending of information, which enables monitoring the operation of devices compatible with the RDM protocol and possibly changing the configuration of their operating parameters. - Page 8 change smoothing settings in the range 1 – 5 or disable smoothing, • change the No Signal mode settings – the device's behavior after the • DMX control signal is lost: ◦ 0 – OFF (complete shutdown), ◦ 1 – ON (100% activation), ◦...
- Page 9 Output 100% Curves: linear DALI set output offset – allows you to set the level of switching on the • diodes, adjustable in the range 0 – 10000. Offset = adapted to the LED receiver’s Offset = 0 operating characteristics Jasność...
-
Page 10: Connection Scheme
Connection scheme Connecting the RGBW strip* DMX in LED RGBW strip power supply 7 - 24V DC power supply 7 - 24V DC DMX out... - Page 11 * typical LED strips are powered by 24V DC – then a 24V DC power supply with appropriate power should also be connected to the PX344, in the case of using LED strips powered by a different voltage, a power supply with the same voltage and power adapted to the length of the strip should be connected to the PX344.
- Page 12 The device can be connected to each other NOTE! In the example connection above, there can be up to four devices. NOTE! A cylindrical plug should be placed in unused bushings and then the bushing should be closed to maintain the tightness of the housing.
-
Page 13: Dimensions
Dimensions... -
Page 14: Technical Data
Technical data type PX344 tightness class IP65 DMX channels RDM protocol support number of output channels 1 – 4 interpolated output control resolution 16 bit programmable scenes built-in programs programming only RDM output load capacity total max. 4A Master / Slave mode power consumption max. - Page 15 Podłęże, 06.03.2025 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Driver LED C.V. 4x1A IP Product code: PX344 meets the requirements of the following standards, as well as harmonized...
