- Page 1 PX254 PX254-L0 PX254-CC Driver LED C.V. 3 x 6A Driver LED C.V. 3 x 6A/cc User manual...
-
Page 2: Table Of Contents
Table of Contents 1 Description....................4 2 Safety conditions..................5 3 Connector and control elements.............6 4 Designation of displayed messages............7 5 Button features...................9 6 Group DMX address settings..............9 7 Individual DMX address settings............10 8 Color settings mode................11 9 No DMX signal response................13 9.1 Description of programs..................15 10 Master / Slave function................16 11 White balance..................18... - Page 3 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.3-2 BDO register number 000005972 www.pxm.pl 27.09.2021...
-
Page 4: Description
Description PX254 driver is designed to control the LEDs. Built-in DMX receiver allows to control 3 DMX channels. (R, G, B) directly with the DMX protocol. Wide range of power supply voltage and high current carrying capacity outputs (6A) permit a control of large quantities of LEDs. -
Page 5: Safety Conditions
balance". Thanks to it you can choose color correction for each set of LEDs controlled by the device to achieve at full power the color white. The PX254 is produced in common anode version – it allows LEDs connection on common anode. Driver comes in two versions: standard –... -
Page 6: Connector And Control Elements
6. PX254 should be strictly protected against contact with water and other liquids. 7. All sudden shocks, particularly dropping, should be avoided. 8. The device cannot be turned on in places with humidity exceeding 90%. 9. The device cannot be used in places with temperature lower than 2°C or higher than 40°C. -
Page 7: Designation Of Displayed Messages
Designation of displayed messages DMX address of a device – a basic item in the MENU setting parameters for all channels simultaneously setting parameters for each channel individually DMX address setting control method selection (RGB, Lightness / Color, etc.) no DMX signal response method selection Master / Slave mode settings selection of the control curve setting the linear control curve... - Page 8 DMX address settings for first channel Master mode on / off number of channels being sent in the Master mode white color balance setting red balance green balance blue balance white color balance on / off program playback speed level of steps change smoothness in the program red color during scene programming green color during scene programming blue color during scene programming...
-
Page 9: Button Features
Button features escape – goes back to the previous MENU level or discards changes made previous – scrolls to the previous feature on the same MENU level or decreases the parameter's value next – scrolls to the next feature on the same MENU level or increases the parameter's value enter –... -
Page 10: Individual Dmx Address Settings
Individual DMX address settings The PX254 module has an option that allows for changing individual settings. It enables assigning any DMX address to every output channel. The simplest example of implementation of this function is to control the lightness of one-color LEDs connected to all outputs. In such case, the same address must be assigned to all channels so that all outputs are controlled by one slider on the control panel. -
Page 11: Color Settings Mode
Color settings mode ENTER ENTER NEXT ENTER NEXT NEXT The PX254 driver can operate in different control modes. Depending on the selected mode, the devices takes up a different NEXT numbers of channels, possible modes: NEXT The HSL mode (Hue, Saturation, Lightness) operates on three channels, responsible for hue, saturation and lightness NEXT The 3bd mode (4-channel, 4-byte) allows for setting each color... - Page 12 Description guide of EFF mode settings CHANNEL CHANNEL CHANNEL CHANNEL CHANNEL CHANNEL CHANNEL 7 1 RED 2 GREEN 3 BLUE 4 MODE 5 SPEED 6 FADE BRIGHTNESS <0–7> Program 1 <8–15> Program 2 <16–23> Program 3 <24–31> Program 4 <32–39> Program 5 <40–47>...
-
Page 13: No Dmx Signal Response
Channel 1 – red color Channel 2 – green color Channel 3 – blue color Channel 4 – operating mode selection Channel 5 – speed settings (higher value – quicker changes) Channel 6 – fade settings (higher value – smoother transition) Channel 7 –... - Page 14 ENTER ENTER ENTER 2 x NEXT NEXT PREV ENTER NEXT ENTER NEXT NEXT ENTER NEXT NEXT NEXT NEXT P01 – P18 – choosing a ready program provided in the device software. For each program it is possible to set the speed (SPd) of the effects reproduction on range 0,1 –...
-
Page 15: Description Of Programs
9.1 Description of programs The following tables show the values for each output channel (R, G, B) in programs from 1 up 18 (P01 – P18). The value 255 corresponds to the maximum lightness level on a given channel, 127 – 50% of power level, 0 –... -
Page 16: Master / Slave Function
Step 1 Step 2 Step 3 Step 4 10 Master / Slave function The PX254 module has a built-in DMX-512 receiver and can be controlled from any desktop or controller running in this standard. Moreover, it is equipped with a programmable function of response to no DMX signal (noS). With 18 built-in default programs, it is possible to obtain interesting effects without an external controller. - Page 17 function is active, this is indicated by a fast flashing of the DMX signaling diode. With this solution, it is possible to make a precise synchronization even in very large installations without using an external controller. ENTER ENTER 3 x NEXT ENTER ENTER NEXT...
-
Page 18: White Balance
11 White balance Sometimes, there can be problems with getting white color on the RGB series LEDs. This may be a result of using diodes with different technical parameters. For this reason, the PX254 module is equipped with a white balance function. -
Page 19: Limiting The Output Power
12 Limiting the output power The white balance parameter, apart from its original functionality, can also be used to limiting the output power of the driver. It works linearly and in a percentage way limits the output power of a given channel. For example, if the bLr parameter is set on 50, it means that by the DMX control and no signal mode this value can not be exceeded. -
Page 20: Smooth
13 Smooth The driver is equipped with a smooth option. Smooth feature allows for smooth changes in lightness and color. When it is set to On the transition between successive DMX values sent to the lamp (e.g. corresponding to changes in lightness) are smooth with no visible twitches, which prevents the common light “vibrations”... - Page 21 NOTE! In the L0 version, the smoothing settings are presented below. Information whether the device is the L0 version is displayed during device start-up. By default, the Sth option is enabled at level 003. The options are: • Off – smoothing disabled, 001 –...
-
Page 22: Selection Of Control Curve
14 Selection of control curve The driver has implemented the option of choosing one of three output control curves: linear Lin – the output values is linearly proportional to the control • value, • DALI – dAL, exponential EP1 with exponent 2. •... -
Page 23: Light Control Frequency
15 Light control frequency The Frq function allows for setting the basic control frequency for the LEDs. This function is extremely useful in applications for the television industry. By applying the "flicker free" technology, it is possible to avoid the unpleasant flickering effect which is caused by improper signal synchronization that controls the LEDs. -
Page 24: Screen Saving (Screen Blanking)
16 Screen saving (screen blanking) The device is equipped with a feature that allows for turning off the backlight. This option is marked with the SCr sign. With this feature, the display is turned off after about 60s (if the keys of the device are not pressed). Of course, the device continues its operation without interfering with other parameters. -
Page 25: Restore Default Settings
17.1 Restore default settings To restore the device to its default settings, press and hold the “previous” key while switching on the device. One of the messages that will be displayed will say dFl, which means successful restoring to default settings (the “previous”... -
Page 26: Error Message
NOTE! In the device version L0, restoring the factory settings is available from the device menu. Information whether the device is the L0 version is displayed during device start-up. ENTER 4 x NEXT Pressed ENTER ENTER 17.2 Error message The device is equipped with a built-in memory work control function. If there are problems with the memory operation on the PX254 display, the Err message appears –... -
Page 27: Display Function
18 Display function As the driver should be installed (As far as possible) in a small distance from the controlled LEDs, the lack of space may force the necessity of mounting the device upside-down. In such case the displayed messages become illegible, that does not have the influence on device operation, but makes the programming much more difficult. -
Page 28: Dmx Signal Connecting
19 DMX signal connecting PX254 have to be connected to DMX line in serial mode, with no branches on DMX control cable. That means that DMX line, from the signal source, must be connected to DMX IN pins of PX254 and later, directly from DMX OUT pins to the next device in DMX chain. - Page 29 List of RDM parameters supported by the PX254: Parameter name Description SUPPORTED_PARAMETERS 0x0050 all supported parameters description of additional PARAMETER_DESCRIPTION 0x0051 parameters DEVICE_INFO 0x0060 information concerning the device SOFTWARE_VERSION_LABEL 0x00C0 firmware version of the device DMX_START_ADDRESS * / DMX starting address of the device; 0x00F0 DMX_ADDRESS * Range 1 –...
- Page 30 Parameter name Description DMX_PERSONALITY_ DESCRIPTION / description of individual 0x00E1 PERSONALITY_ operational modes DESCRIPTION DEVICE_HOURS ** 0x0400 operating time counted in hours BALANCE_RED * / value of control level of red channel 0x8011 BALANCE_CH1 * balance BALANCE_GREEN * / value of control level of green 0x8012 BALANCE_CH2 * channel balance...
- Page 31 Parameter name Description programs playback speed settings PROGRAM_SPEED * 0x8025 (playing next steps of program) settings of smooth transition PROGRAM_FADE * 0x8026 between following steps of a program BALANCE ON/OFF * / to activate or deactivate the 0x8027 BALANCE_ENABLE * balance of output channels PWM_FREQENCY * 0x8028 LEDs refresh frequency...
-
Page 32: Programming
21 Programming ENTER ENTER ENTER NEXT NEXT ENTER NEXT NEXT ENTER ENTER NEXT NEXT NEXT NEXT NEXT ENTER NEXT NEXT NEXT NEXT ENTER NEXT NEXT NEXT NEXT NEXT NEXT ENTER ENTER NEXT NEXT NEXT ENTER NEXT NEXT ENTER NEXT NEXT NEXT ENTER NEXT... -
Page 33: Connection Scheme
22 Connection scheme a) for the PX254 controller LED strip RGB INPUT: OUTPUT: max. 32 devices power supply in DMX line 7 - 24 V DC INPUT: OUTPUT: Terminator (resistor 120 Ohm connected between DMX+ and DMX-) Note! The driver PX254 is common anode type device. It is possible to connect lamps with 4-wires cable with a common “+”... - Page 34 b) for the PX254-CC version controller LED strip RGB INPUT: OUTPUT: max. to 32 devices in DMX line power supply 7 - 24 V DC INPUT: OUTPUT: Terminator (resistor 120 Ohm connected between DMX+ i DMX-) Note! The driver PX254-CC is common cathode type device. It is possible to connect lamps with 4-wires cable with a common “-”...
- Page 35 Sample connection of warm and cold white LEDs strips for Dynamic White mode a) for the PX254 warm white LED strip cold white LED strip INPUT: OUTPUT: power supply 7 - 24V DC b) for the PX254-CC version warm white LED strip cold white LED strip INPUT: OUTPUT:...
-
Page 36: Dimensions
23 Dimensions 175 mm... -
Page 37: Technical Data
24 Technical data PX254 type PX254-L0 PX254-CC DMX channels RDM protocol support power supply 7 – 24V DC max. current consumption 30mA for 12V DC power consumption without load 40mA for 24V DC output channel number interpolated resolution of output control... - Page 38 Podłęże, 03.06.2019 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Driver LED C.V. 3 x 6A Driver LED C.V. 3 x 6A/cc Product code: PX254 PX254-L0 PX254-CC meets the requirements of the following standards, as well as harmonised...
