Read the operating instructions prior to commissioning
Installation instructions
Stacking kit
Model
FPE-615
FPE-621
FPE-115
FPE-121
FGE-615
FGE-621
FGE-115
FGE-121
R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEXFUSION PLATINUM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Henny Penny FLEXFUSION PLATINUM

  • Page 1 Read the operating instructions prior to commissioning Installation instructions Stacking kit Model FPE-615 FPE-621 FPE-115 FPE-121 FGE-615 FGE-621 FGE-115 FGE-121 R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M...
  • Page 2 Henny Penny Corporation P.O.Box 60 Eaton,OH 45320 Phone +1 937 456-8400 Fax +1 937 456-8402 Toll free in USA Phone +1 937 417-8417 Fax +1 937 417-8434 www.hennypenny.com Installation instructions...
  • Page 3: Table Of Contents

    Directory of contents 1 Introduction .................  5 1.1 About this manual  ................  5 1.1.1 Explanation of signs  ..................   6 1.2 Use of the unit ...................  7 1.3 Warranty  ....................  7 2 Safety instructions  .............  8 3 Description of the unit  ............  9 4 Scope of delivery ..............  10 5 Installation .................  12 5.1 Preparatory work ...
  • Page 4 Directory of contents Installation instructions...
  • Page 5: 1 Introduction

    Introduction 1 Introduction 1.1 About this manual The installation instructions are part of the unit and contain information on safe installation of the unit. Observe the following notes and adhere to them: • Read the installation instructions completely prior to installation. •...
  • Page 6: Explanation Of Signs

    Introduction 1.1.1 Explanation of signs Imminent danger DANGER Failure to comply will lead to death or very severe injuries. Potential danger WARNING Failure to comply can lead to death or very severe injuries. Dangerous situation CAUTION Failure to comply can lead to slight to moderately severe injuries. Property damage NOTICE Failure to comply can cause property damage.
  • Page 7: Use Of The Unit

    Introduction 1.2 Use of the unit This unit is intended to be used solely for commercial purposes, particularly in commercial kitchens. 1.3 Warranty The warranty is void and safety is no longer assured in the event of: • Improper conversion or technical modifications of the unit. •...
  • Page 8: 2 Safety Instructions

    Safety instructions 2 Safety instructions The unit complies with applicable safety standards. Residual risks associated with operation or risks resulting from incorrect operation cannot be ruled out and are mentioned specifically in the safety instructions and warnings. The installation fitter must be familiar with regional regulations and observe them.
  • Page 9: 3 Description Of The Unit

    Description of the unit 3 Description of the unit Image: Description of the individual parts a Outgoing air pipe holder g Cover panel (right) b Extension for outgoing air pipe h Cover panel (front) c Seal for outgoing air pipe i Plate d Outgoing air pipe diverter j Top Combisteamer unit leg...
  • Page 10: 4 Scope Of Delivery

    Scope of delivery 4 Scope of delivery The following parts are included in the delivery. Prior to the installation check that the parts are complete and undamaged. Scope of delivery Position Figure Designation Article number Quantity Outgoing air 866864 pipe holder Outgoing air 935634 pipe...
  • Page 11 Scope of delivery Position Figure Designation Article number Quantity Lock washer, 6 121033 Installation instructions...
  • Page 12: 5 Installation

    Installation 5 Installation Risk of fatal injury from falling unit DANGER • Do not stand under a suspended load. • Cordon off danger zone in compliance with regulations. Risk of property damage and personnel injury from tipping unit CAUTION • Stay clear of lifted unit. •...
  • Page 13: Preparing The Bottom Combisteamer

    Installation Prerequisite Load-bearing capacity of the floor suitable for the underframe and unit 1. Set up the underframe in accordance with the planning drawing. 2. Level the underframe. 5.1.2 Preparing the bottom Combisteamer Prerequisite Unit unpacked Electrical connection line dead Water supply line disconnected from the supply network Wastewater connection prepared Stacking kit checked for completeness and made ready...
  • Page 14: Preparing The Top Combisteamer

    Installation Image: Outgoing air pipe diverter with locking mechanism on adapter plate (arrow) a Seal b Outgoing air pipe diverter c Adapter plate Prerequisite Adapter plate attached 1. Put the seals onto the outgoing air pipe diverter. 2. Put the outgoing air pipe diverter onto the unit's outgoing air outlet. 3.
  • Page 15: Placing The Combisteamer On The Underframe (Optional)

    Installation Prerequisite Bottom Combisteamer leveled Bottom Combisteamer aligned vertically 1. Position the washer on the unit leg over the upright bolt. 2. Set the front left unit leg to 4.65 inches by screwing it in or out. 3. Set the front right unit leg to 3.86 inches by screwing it in or out. When doing this pay attention to the reinforcement on the adapter plate.
  • Page 16: Attaching The Anti-Tilt Device

    Installation Risk of property damage from improper lowering of the unit NOTICE Take care not to damage the unit's locking device. Image: A Front left unit leg, B front right unit leg a Top Combisteamer unit leg e Upright bolt (dashed line) b Nut f Upright bolt...
  • Page 17: Attaching The Outgoing Air Pipe

    Installation 1. Attaching the anti-tilt device. Image: Anti-tilt device Prerequisite Adapter plate attached The Combisteamer is aligned 1. Move the Combisteamer into the final position. Do not squash the cables and hoses. 2. Press the angles to the wall. If necessary compensate for any unevenness with suitable shims.
  • Page 18: Attaching The Cover Panels

    Installation 3. Put the outgoing air pipe holder on the outgoing air pipe. 4. Fasten the outgoing air pipe holder to the lid of the top Combisteamer with the screw, washer, and lock washer. Outgoing air pipe is attached. 5.6 Attaching the cover panels 5.6.1 Attaching the cover panel on the right Image: Cover panel a Cover panel...
  • Page 19: Attaching The Cover Panel On The Left

    Installation 5.6.2 Attaching the cover panel on the left Image: Cover panel a Cover panel c Adapter plate b Screw d Snap nut Prerequisite Both units are not live Combisteamers connected together Water connection made Cover panel on the right attached 1.
  • Page 20: Assembling The Front Cover Panel

    Installation 5.6.3 Assembling the front cover panel Image: A Hinged on the right (arrow), B Hinged on the left (arrow) a Screw c Plate b Nut d Cover panel Hinged on the right 1. Close the cut-out on the left side of the cover panel. 2.
  • Page 21: Attaching The Front Cover Panel

    Installation 5.6.4 Attaching the front cover panel Image: Cover panel a Screw c Nut b Adapter plate d Cover panel Prerequisite Cover panel on the right attached Cover panel on the left attached 1. Put the nut on the holder. 2.
  • Page 22 Installation Installation instructions...
  • Page 24 Henny Penny Corporation P.O.Box 60 Eaton,OH 45320 Phone +1 937 456-8400 Fax +1 937 456-8402 Toll free in USA Phone +1 937 417-8417 Fax +1 937 417-8434 www.hennypenny.com...
