W70PTO & W70PTOS
70PTOT4 & 80PTOT4
GENERATORS
INSTALLATION AND
OPERATORS MANUAL
COPY YOUR MODEL AND SERIAL NUMBER HERE
No other WINCO generator has the same serial number as yours.
If you should ever need to contact us concerning this unit, it will
help us to respond to your needs faster.
MODEL __________________________________________________
SERIAL NUMBER _________________________________________
PURCHASE DATE _________________________________________
DEALER NAME ___________________________________________
DEALER PHONE # ________________________________________
www.wincogen.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winco W70PTO
Summary of Contents for Winco W70PTO
- Page 1 OPERATORS MANUAL COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as yours. If you should ever need to contact us concerning this unit, it will help us to respond to your needs faster.
-
Page 2: Table Of Contents
Should you experience a problem please follow the PRE-START CHECKS “Troubleshooting Tables” near the end of this manual. The warranty listed in the manual describes what you can GENERATOR PROCEDURES expect from WINCO should you need service assistance in START UP the future. SHUTDOWN MAINTENANCE... -
Page 3: Safety
SAFETY IMPORTANT SAFETY INSTRUCTIONS CAUTION This engine generator set has been designed and Keep the generator and surrounding area clean. manufactured to allow safe, reliable performance. Poor maintenance, improper or careless use can result in A. Remove all grease, ice, snow or materials that create potentially deadly hazards;... -
Page 4: Specifications
Volume 0.875 Pint (gray models) Volts 277/480 1.0 Pint (red models) Phase Three Type SAE 80-90W-140 Amps Power Factor W70PTO Input Speed 1000 RPM Continuous Watts 69,000 Generator Speed 1800 RPM Volts 120/240 Input Shaft 1 3/8” - 6 Spline... -
Page 5: Introduction
If any damage is noted, it is always easiest to by the manufacturer of applicable engines. refuse the shipment and let WINCO take care of the freight claim. If you sign for the unit, the transfer of the The WINCO power take-off generators are designed... -
Page 6: Installation
INSTALLATION Note: PTO mounting holes are .75”. WARNING: PERSONAL INJURY & EQUIPMENT DAMAGE FOUNDATION MOUNTING Trailer may tip over and cause injuries if wheels are not spaced far enough apart. Mount the generator on a foundation if it is to be used as a permanent or standby power source. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS CAUTION: RECOMMENDED CONTACTS Only qualified electricians should install electric wiring. VOLTAGE WIRE INCLUDED Wiring must conform to all applicable national, state, 120/240 1-PH and local codes. (Reference: National Fire Protection 208/240 3-PH 1/0 to #1 Association Manual No. 70, National Electrical Code.) 277/480 3-PH #2 &... -
Page 8: Typical Connection Methods For Generator Power Service
TYPICAL CONNECTION METHODS FOR GENERATOR POWER SERVICE IMPORTANT: When making standby service hook up, make sure load to be transferred to standby generator will not exceed generator rating. TYPICAL HOOK UP FOR TYPICAL HOOK UP FOR SUPPLYING ALL CIRCUITS SUPPLYING ONLY ESSENTIAL CIRCUITS WITH EMERGENCY POWER WITH EMERGENCY POWER To Power Line Master Switch... -
Page 9: Operation
Drive shafts shipped are the hardest to start, normally using 5 to 7 times as much age to flicker. Drive shafts shipped new from Winco are al- new from WINCO are always synchronized and tethered ways synchronized and tethered so they can not be taken 4. -
Page 10: Generator Procedures
GENERATOR PROCEDURES DANGER: PERSONAL INJURY: Power take-off must be disengaged at this time. START UP 4. Couple the tractor to the generator with the drive shaft (tumbling bar). Couple the tumbling bar to the generator 1. Set the manual transfer to mid or normal (up) position. input shaft first, then to the power take-off shaft. -
Page 11: Maintenance
Fine metal dust in the oil does not indicate trou The splined generator input shaft should be cleaned and chips do. Dismantle the gear case and look for lubricated with a thin film of grease before and after each use gears if you find metal chips in the oil. -
Page 12: Cleaning And Inspection
CLEANING & INSPECTION Use a vacuum cleaner or dry low pressure compressed air (regulated at 25-35 PSI) to clean the generator periodically. WARNING: Do NOT clean the generator while it is running. Proceed as follows: 1. Remove control box cover. Vacuum or blow dust or debris from the control box. -
Page 13: Trouble Shooting Tables
TROUBLE SHOOTING TABLES SYMPTOM CAUSE(S) CORRECTIVE ACTION No output voltage 1. Circuit breaker open 1. Reset circuit breakers, replace if defective 2. Defective frequency meter 2. Check output with another meter, replace meter if 3. Short circuit in the load defective. -
Page 14: Wiring Diagrams
WIRING DIAGRAMS 9 ÿ 9 ÿ ! ÿ # $% ÿ &' ( ) W70PTO & W70PTOS BACK VIEW 0 1 2 0 34 5 6 37 8 6 9 ÿ... - Page 15 70PTOT4-03 BACK VIEW OPM-142/F...
- Page 16 70PTOT4-04 & 70PTOT4-17 BACK VIEW OPM-142/F...
- Page 17 80PTOT4-18 BACK VIEW OPM-142/F...
-
Page 18: Warranty Statement
Air cooled units purchased for stock have 1 year to be sold. The warranty to the original retail customer commences on the date of sale of the product to them. All liquid cooled units have 180 days from the Winco invoice to submit a start up date. - Page 19 Standby use is defined as an application where utility power is present -and- the generator set is used as emergency backup during utility power outages. WINCO reserves the right to change or improve it’s products without incurring any obligations to make such changes or improvements on products purchased previously.
- Page 20 225 S. CORDOVA AVE • LE CENTER, MN 56057 Sales: 507-357-6821• sales@wincogen.com Service: 507-357-6831 • service@wincogen.com www.wincogen.com OPM-142/F...
