SET MODBUS ACCESS:

By Pressing the "Set Modbus Access
button from the main window
SW67664 (Fig. 2) the window
Access" appears (Fig. 4).
The window is divided in two parts, the
"Modbus Read" that contains the Modbus
registers/status readable by the Converter
and "Modbus Write" that contains the
Modbus registers/status writeable by the
Converter.
The meaning of the fields in the window
are the follows:
In the field "Slave IP
the address of the Modbus device
you have to read/write is defined;
In the field "Port" the port used for
require the Modbus data is defined;
In the field "Slave ID" is possible
to insert the ID the address of the
Modbus device you
read/write;
In the field "Type" insert the data
type of the Register you would like
to read/write. You can choose between the following:
Coil Status (R/W);
o
Input Status (R);
o
Holding Register (R/W);
o
Input Register (R);
o
In the field "Address" the start address of the register/status to read/write is defined;
In the field "NPoint" insert the number of consecutive registers/status to read/write;
ADFweb.com S.r.l.
"
for
"Set
Address"
have to
User Manual EtherNet/IP / Modbus TCP Master
Document code: MN67664_ENG Revision 1.001
Figure 4: "Set Access" windows
