Key Automation CT20324 Instructions And Warnings For Installation And Use page 2

EN
INDEX
1 Safety warnings
2 Introducing the product
2.1 Description of the control unit
2.2 Description of the connections
2.3 Models and technical characteristics
2.4 List of cables required
3 Preliminary checks
4 Product installation
4.1 Electrical connections
4.2 Disabling the safety devices
4.3 Display during normal operation
4.3.1 Error messages on the display
4.3.2 Error messages on flashing light
4.3.3 Status messages on display
4.4 Autolearning of the travel stroke
4.4.1 Autolearning of the travel stroke and main parameters
4.4.2 Autolearning of the travel stroke and main parameters, with customised decelerations
4.5 Radio remote control management
4.5.1 Memorisation of buttons of a radio remote control
4.5.2 Deletion of a memorised button of a radio remote control
4.5.3 Deletion of the entire receiver memory
Memorisation of a button of a new radio remote control using a radio remote control already saved
4.5.4
in memory
4.6 Factory parameters reset
5 System customisation
5.1 Basic parameters
5.2 Advanced parameters
6 Testing and commissioning the automation system
6.1 Testing
6.2 Commissioning
7 Instructions and warnings for the end user
2
p. 3
p. 4
p. 4
p. 4
p. 4
p. 5
p. 5
p. 6
p. 6
p. 8
p. 8
p. 9
p. 9
p. 9
p. 9
p. 10
p. 10
p. 11
p. 11
p.12
p. 12
p. 12
p. 13
p. 13
p. 13
p. 14
p. 16
p. 16
p. 16
p. 17
