- Page 1 CHILL® CUBE 18K NON-DUCTED ROOFTOP AIR CONDITIONER For Aftermarket Applications MODEL (LIPPERT PN) FACR18VSSA-BL-AM (2024039631) FACR18VSSA-PS-AM (2024039637) INSTRUCTION MANUAL ADB (Required): FACT18MA-PS-AM (2024040311)
-
Page 2: Table Of Contents
Thank you for purchasing this Furrion® product. Before operating your new appliance, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the appliance. Please keep this instruction manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury. -
Page 3: Important Safety Instructions
The refrigerant must never be released into the air. • Fire hazards • Injury WARNING All Furrion product referenced in this manual is to be installed • The electrical power supply must only be connected by a in accordance with local and national codes, including the qualified electrician. -
Page 4: Warning For Using R32 Refrigerant
CAUTION CAUTION • Do not use device for any other purpose than its intended • Turn off he air conditioner and disconnect the power if you use. are not going to use it for a long time. • Do not climb onto or place objects on top of the outdoor •... -
Page 5: Choosing The Proper Location For The Air Conditioner
Roof Thickness The installation of air conditioner is suited for roof thickness from 3 ” (90mm) to 6” (152mm). For other thickness, please contact Furrion or Furrion authorized service agent. Center line of rooftop Keep this air flow area free of... -
Page 6: Preparing Wire Connections
Installing in an Existing Opening 2. Using the roof opening as a guide, cut a matching hole in the ceiling. 1. Unscrew and remove the roof vent. NOTE: Maintain structural integrity. Otherwise damage to 2. Remove all caulking compound around the opening. product and/or RV could occur. -
Page 7: Installation
115VAC Supply NOTE: The wire gauge is generally acceptable per NEC code, refer to rooftop unit nameplate and applicable code for proper 1. Prepare a dedicated 20 amp rated circuit for each air sizing. conditioner unit, protected with a time delay fuse or circuit breaker. -
Page 8: Electrical Work
Electrical Work 3. Connect the insulated duct divider to the mounting frame and seal any cracks or gaps with adhesive-backed aluminum tape WARNING BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. Wire Connection DANGER Electrical Shock Hazard •... -
Page 9: Adb Shroud Installation
ADB Shroud Installation Option B - Make the wire connections using the appropriate wire connector following the below color codes. Black - Hot 1. Reveal the 5 mounting screws inside the Air Distribution White - Neutral Box (ADB) shroud by removing the filter cover and opening the Green/yellow - Ground swivel door, respectively. - Page 10 3. Remove wire mesh filter from the ADB to access the wires in 5. Place loose wires inside the electrical box, and close the the return by removing the two screws and snapping the mesh electrical box panel door. Secure the panel door shut using the out of the mounting frame.
-
Page 11: Operation
OPERATION Operating Panel Diagram NOTE: Different models may have different buttons and indicator lights. Not all the buttons and indicator lights described are available on all units. Please check the operating panel of your unit. The following graphics are for explanatory purposes only. Fan speed GEAR mode SLEEP mode... -
Page 12: Remote Diagram
Remote Diagram Remote Display UP/DOWN/ TURBO button TEMP button Power button TIMER ON MODE button button FAN button TIMER OFF button FOLLOW ME button LED button SLEEP button GEAR SWING button button (optional) Button/ Effect Function Power Button Turns the unit on and off. Toggles between the operational modes of the unit. -
Page 13: Handling The Remote Control
Handling the Remote Control Using the Remote • The remote control must be used within 26.25 feet (8 meters) of the unit. NOTE: Remote not available for all units. • The unit will beep when remote signal is received. NOTE: Remote requires 2 AAA batteries. Some models come •... -
Page 14: Basic Function Operation
Basic Function Operation Advanced Function Operation Auto Mode Operation GEAR Operation 1. Set the unit to AUTO mode by pressing the MODE button 1. Press the GEAR button. The 75% LED will illuminate. In this until “AUTO” is selected. mode, the unit will operate at 75% max current limit. 2. -
Page 15: Operating The Timer Function
Operating the Timer Function To set the Auto-off time Press the TIMER ON button to set the auto-on time of the unit. 1. Press the TIMER OFF button. The remote control LCD Press the TIMER OFF button to set the auto off time of the unit display will read TIMER OFF, the last Auto-off setting time, and the letter “H”... - Page 16 TIMER OFF (Auto-off Operation) The TIMER OFF feature is useful for turning the unit off automatically at a set time, such as after going to bed. The air conditioner will automatically start operating at the set time. Example: To stop the air conditioner after 10 hours - 1.
-
Page 17: Cleaning And Maintenance
The set temperature is Select a lower temperature. too high. The evaporator fan is Contact an authorized service agent or Furrion (see the detail contact info at the damaged. back page of this manual). Not cooling well The condenser fan is Contact an authorized service agent or Furrion (see the detail contact info at the damaged. -
Page 18: Specifications
SPECIFICATIONS FACR18VSSA-**-AM Nominal Cooling (Btu) 18,000 Dehumidification (pint/h) Applicable vehicle length (feet) Refrigerant Charge (Oz) 18.34 Roof top Unit Dimensions (L x W x H) 29” x 29 ” x 14 ” (735mm x 750mm x 369mm) ELECTRICAL Volts/Frequency 115V~/60Hz/1Ph Power Watts (Cooling) 1330 Amps (Cooling) -
Page 19: Notes
NOTES - 19 - CCD-0009328 Rev: 08.12.24... - Page 20 Furrion, LLC (Furrion) are wholly owned subsidiaries of Lippert Components, Inc. (Lippert) Furrion, LLC (Furrion) sont des filiales en propriété exclusive de Lippert Components, Inc. (Lippert) Furrion, LLC: 52567 Independence Ct., Elkhart, IN, 46514 Furrion Innovation Center & Institute of Technology Centre d’innovation et institut de technologie Furrion...
