- Page 1 Horizon Elite Ice Machine Installation Instructions ™ to Ice Storage Bin Top-mount Applications D710, E710, C1010, C1410 Order parts online www.follettice.com self-contained 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01113307R06 www.follettice.com...
- Page 2 CAUTION! § This appliance should be connected by a qualified person in accordance with applicable codes. § If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. §...
-
Page 3: Table Of Contents
Contents Unpack ....................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements .............................5 Docking Assembly Installation .............................6 External Connections ..............................7 Ice Transport Tube Installation ...........................7 Air-cooled ice machines only .............................8 Water-cooled ice machines only ..........................8 Internal Connections ..............................10 Ice transport tube .............................. -
Page 4: Unpack
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ BIN • TOP-MOUNT Horizon 710/1010/1410... -
Page 5: Site Preparation
Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements ➍ 3/8" chassis drain must be used Minimum 8"... -
Page 6: Docking Assembly Installation
Docking Assembly Installation WARNING! § Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. -
Page 7: External Connections
External Connections Ice Transport Tube Installation Hot Water 160 F (71 C) ➊ ➋ ➌ § Install supplied ice transport tube insulation. ➊ § Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers before making connection to ease assembly. -
Page 8: Air-Cooled Ice Machines Only
Air-cooled ice machines only Water-cooled ice machines only ➊ ➊ ➏ ➋ ➋ ➐ ➌ ➌ ➏ Minimum 8" Minimum 8" ➑ radius radius 2 ft. x 1" OD 2 ft. x 1" OD silicone tubing silicone tubing 3/4" barb x 3/4" FPT 3/4"... - Page 9 Chassis drain plumbing - required § Plug must be removed from John Guest fitting. § Route 3/8" drain tubing through knockout in back of docking station and insert fully into John Guest fitting connection at the rear of the machine chassis. Route other end of 3/8"...
-
Page 10: Internal Connections
Internal Connections Air-cooled ice machines – follow steps 5.1 and 5.5. Water-cooled ice machines – follow steps 5.6 through 5.12. Ice transport tube Potable water lines ➋ ➊ ➊ § Slide ice machine into docking assembly ➊ § Insert potable water line into valve ensuring that drain tube is fully seated on barbed drain fitting ➊... -
Page 11: Tds Switch
TDS switch Cooling Lines HIGH CLEAN § Set the TDS switch on the elctrical box. § Install ice machine cooling water lines to docking assembly. – HIGH: for extended service life – LOW: for low-scale water Ice transport tube Potable Water Line ➋... -
Page 12: Cooling Lines And Power
5.10 Cooling lines and power Power cord ➋ ➊ § Remove twist tie. ➊ § Connect cooling water lines to ice machine § Carefully pass plug through opening and plug into (Water "Out" connects to water regulator.) wall outlet. § Water valve is set at the factory. DO NOT remove ➋... -
Page 13: Front Cover
Front Cover Install front cover to ice machine. ➊ ➋ § Slide ice machine cover over machine, ensuring that tabs on back of cover slip under louvers on back ➊ of docking assembly , then tighten two screws through cover. ➋... - Page 14 BIN • TOP-MOUNT Horizon 710/1010/1410...
- Page 15 BIN • TOP-MOUNT Horizon 710/1010/1410...
- Page 16 Maestro, Vision, Ice Manager, Horizon, Horizon Elite are trademarks of Follett Products, LLC. Chewblet, RIDE, Follett are registered trademarks of Follett Products, LLC. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01113307R06 www.follettice.com...
