H-4066
DELUXE VINYL
WORK STOOL
Back Cushion
with Post x 1
1.
Insert glides into legs of five-star base. Turn base
upright. Insert gas lift into center of base.
(See Figure 1)
Figure 1
Gas Lift
Base
Glide
PAGE 1 OF 6
1-800-295-5510
uline.com
Seat Cushion x 1
PARTS
5-Star Base x 1
Glide x 5
ASSEMBLY
2. Insert back cushion post into corresponding slot
in mechanism on bottom of seat. Tighten knob to
secure. (See Figure 2)
Figure 2
Back
Cushion
Post
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Footring x 1
Gas Lift x 1
Seat
Knob
0124 IH-4066
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-4066BL
Summary of Contents for U-Line H-4066BL
- Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-4066 1-800-295-5510 uline.com DELUXE VINYL WORK STOOL PARTS Seat Cushion x 1 5-Star Base x 1 Glide x 5 Footring x 1 Gas Lift x 1 Back Cushion with Post x 1 ASSEMBLY Insert glides into legs of five-star base.
-
Page 2: Stool Adjustments
ASSEMBLY CONTINUED 3. Slide footring onto the gas lift and tighten knob to 4. Slowly lower stool assembly onto the gas lift. Press secure. (See Figure 3) down on seat to secure. (See Figure 4) Figure 3 Figure 4 Footring Stool Knob Assembly... - Page 3 H-4066 800-295-5510 uline.mx SILLA DE ALTA CALIDAD DE VINIL PARA TRABAJO PARTES 1 Asiento 1 Base Estrella 5 Niveladores 1 Reposapiés 1 Pistón de Gas 1 Respaldo con Poste ENSAMBLE Inserte los niveladores en las patas de la base 2. Inserte el poste del respaldo en la ranura estrella.
- Page 4 CONTINUACIÓN DEL ENSAMBLE 3. Inserte el reposapiés en el pistón de gas y apriete la 4. Baje lentamente el ensamble de la silla sobre el perilla para asegurarlo. (Vea Diagrama 3) pistón de gas. Presione el asiento para asegurarlo. (Vea Diagrama 4) Diagrama 3 Diagrama 4 Reposapiés...
- Page 5 H-4066 1-800-295-5510 uline.ca TABOURET DE TRAVAIL DE LUXE EN VINYLE PIÈCES Siège x 1 Base à 5 branches x 1 Patin x 5 Repose-pied x 1 Vérin pneumatique x 1 Dossier avec montant x 1 ASSEMBLAGE Insérez les patins dans les pieds de la base à cinq 2.
- Page 6 ASSEMBLAGE (SUITE) 3. Faites glisser le repose-pied sur le vérin 4. Abaissez lentement le tabouret sur le vérin pneumatique et serrez la molette pour le fixer. pneumatique. Appuyez sur le siège pour le fixer. (Voir Figure 3) (Voir Figure 4) Figure 3 Figure 4 Repose-pied...
