STI Stopper Station SS-2002 Manual

Push buttons key to reset, momentary and turn-to-reset

Advertisement

Quick Links

Stopper Station Series
SS-2002, SS-2005, SS-2009 Push Buttons
Key to Reset, Momentary and Turn-to-Reset
Key Reset Models
SS-2002
Red
SS-2102
Green
SS-2202
Yellow
SS-2302
White
SS-2402
Blue
ALL MODELS COME WITH A COLOR MATCHED SURFACE MOUNT BACKBOX
NOTE: For SS-2XX5/LTUL the enclosed timer is to be used and installed per the enclosed
LT-1UL installation sheet. SS-2XX5/LTUL maximum rating 30 VDC 3A. For access control
installations, power for the LT-1 Timer must be supplied by a power source listed to UL294.
When used for access control, this device shall be used as part of an access controlled
egress door system. It is up to the local AHJ to allow use of this device in place of an auto-
matic sensor. For higher security installations, lower time limits should be used.
Momentary Models
SS-2005
Red
SS-2105
Green
SS-2205
Yellow
SS-2305
White
SS-2405
Blue
ADA
for operation
Turn-to-Reset Models
SS-2009
Red
SS-2109
Green
SS-2209
Yellow
SS-2309
White
SS-2409
Blue

Advertisement

loading
Need help?

Need help?

Do you have a question about the Stopper Station SS-2002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for STI Stopper Station SS-2002

  • Page 1 Stopper Station Series SS-2002, SS-2005, SS-2009 Push Buttons Key to Reset, Momentary and Turn-to-Reset for operation Key Reset Models Momentary Models Turn-to-Reset Models SS-2002 SS-2005 SS-2009 SS-2102 Green SS-2105 Green SS-2109 Green SS-2202 Yellow SS-2205 Yellow SS-2209 Yellow SS-2302 White SS-2305 White SS-2309...
  • Page 2 2 Form C contacts 125/250 VAC, 10 A, 1/2 HP 30 VDC, 6 A...
  • Page 4 BACKBOX PREPARATION (NOT INCLUDED WITH FLUSH MOUNT COVERS) DRILL POINT LOCATIONS PROVIDED DRILL POINT L DRILL POINT L TIONS PR VIDED TOP AND BOTTOM FOR 1/2 in. OP AND B OP AND B OR 1/2 in. CONDUIT FITTINGS. ONDUIT FIT ONDUIT FIT TINGS DRILL AS NEEDED...
  • Page 5: Wire Connections

    WIRE CONNECTIONS THIS SIDE CONTACT SET 2 THIS SIDE CONTACT SET 1 CONTACT SET 1 CONTACT SET 2 STRIP 3/8 in. (9mm) 3.25 in. (82mm) CORRECT METHOD OF INCORRECT METHOD OF INSERTING MULTIPLE LEADS INSERTING MULTIPLE LEADS (1 WIRE EACH (BOTH WIRES ON 4.87 in.
  • Page 6: Installation

    INSTALLATION .75 in. 1.5 in. (19mm) (38mm) 19018 ANCHOR 19018 ANCHOR 19018 ANCHOR (4) PROVIDED (4) PR (4) PR VIDED 71100A-COLOR SURFACE BOX 71100A OR SURF CE B DRILL (4) 3/16 in. DRILL (4) 3/16 in. 19039 SCREW #6 x 1-1/4 in. 19039 SCREW #6 x 1 1/4 in.
  • Page 7 PUSH IN UNTIL BUTTON POPS UP. ALIGN SLOT IN KEY SWITCH IS NOW RESET (CONCAVE SIDE UP) KEY RESET PROCEDURE WITH 2 SLOTS UNDER BUTTON (#2 BUTTON) PART #18061 KEY-TO-RESET SLOT LOCATED UNDER BUTTON PUSH IN UNTIL BUTTON POPS UP. ONCE KEY HAS BEEN INSERTED IN SWITCH IS NOW RESET SLOTS, PUSH KEY, BUTTON WILL...
  • Page 8: Product Dimensions

    Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999 1.56 in. Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only) 2002-5 IS (40mm) E-mail: info@sti-europe.com • Web: www.sti-europe.com 05/11 4.87 in. PUSH (124mm)
